KROFTMAN E500 Assembly Manual

Storage buildings
Hide thumbs Also See for E500:

Advertisement

Quick Links

Download this manual
Loodsen / Lagerhallen / Storage buildings / Hangar de stockage
Kroftman E500
(E509, E512, E515)
Montagehandleiding
Montageanleitung
Assembly manual
Manuel de montage
V1.00KR 201016

Advertisement

loading
Need help?

Need help?

Do you have a question about the E500 and is the answer not in the manual?

Questions and answers

Related Manuals for KROFTMAN E500

Summary of Contents for KROFTMAN E500

  • Page 1 Loodsen / Lagerhallen / Storage buildings / Hangar de stockage Kroftman E500 (E509, E512, E515) Montagehandleiding Montageanleitung Assembly manual Manuel de montage V1.00KR 201016...
  • Page 2 26 + 27...
  • Page 3 GSPublisherVersion 215.0.27.100...
  • Page 4 Aussenmasse markieren Mark outside dimensions Aussenmasse markieren Mark outside dimensions GSPublisherVersion 215.0.27.100...
  • Page 5 BC 9mm Nicht mitgelieferd Not included Butylband (BC) Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Butyl caulking strip, Ø9 mm GSPublisherVersion 215.0.27.100...
  • Page 6 E509 1x7R+1x7L E512 2x7R+2x7L E515 3x7R+3x7L Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Fuß-Profil 50x50x3mm 1275 Base Rail Fuß-Profil 50x50x3mm Base Rail Fuß-Profil 50x50x3mm Base Rail Fuß-Profil 50x50x3mm Base Rail Fuß-Profil 50x50x3mm Base Rail Fuß-Profil 50x50x3mm 2877 Base Rail...
  • Page 7 Ø12 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) MKT B12-85-100/180ev 12x180mm Ø30 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) GA earth anchor, 25 x 1100 (optional) Ø 25 mm 1100 GSPublisherVersion 215.0.27.100...
  • Page 8 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Pfosten 50x50x4mm 2500 Sidepost Dachsparren 50x50x3mm 2830 Rafter Lasche 1 700x146x6,0 Bracket 1 Lasche 2 438x355x6,0 Bracket 2 Bolzen-Satz 2 / Bolt set 2 Flat head bolt M12x75DIN8.8, 50mm straight shaft BO-2 Washer Ø12 M12DIN8.8 hex nut...
  • Page 9 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Sechskant-Bohrschraube 4,8mm (ohne Scheibe) SC-B 4,8x20mm Hex screw galvanized 4.8mm (no rubber washer) GSPublisherVersion 215.0.27.100...
  • Page 10 (SC-A) 25*25*2 (BO-4) (B3) (BO-3) GSPublisherVersion 215.0.27.100...
  • Page 11 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Pfosten 50x50x4mm 2500 Sidepost Dachsparren 50x50x3mm 2830 Rafter Kehlbalken (Links) 25x25x2.5mm 2913 Left Stringer for Collar Tie Kehlbalken (Rechts) 25x25x2.5mm 1113 Right Stringer for Collar Tie Kehlbalken (Vertikal) 25x25x2.5mm Vertical support profile for Collar Tie Lasche 1...
  • Page 12 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Sechskant-Bohrschraube 4,8mm (ohne Scheibe) SC-B 4,8x20mm Hex screw galvanized 4.8mm (no rubber washer) GSPublisherVersion 215.0.27.100...
  • Page 13 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Pfosten 50x50x4mm 2500 Sidepost Dachsparren 50x50x3mm 2830 Rafter Lasche 1 700x146x6,0 Bracket 1 Lasche 2 438x355x6,0 Bracket 2 Bolzen-Satz 2 / Bolt set 2 Flat head bolt M12x75DIN8.8, 50mm straight shaft BO-2 Washer Ø12 M12DIN8.8 hex nut...
  • Page 14 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Sechskant-Bohrschraube 4,8mm (ohne Scheibe) SC-B 4,8x20mm Hex screw galvanized 4.8mm (no rubber washer) GSPublisherVersion 215.0.27.100...
  • Page 15 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Dachpfette 38x38x1.5mm 3015 Purlin Sechskant-Bohrschraube 4,8mm (ohne Scheibe) SC-B 4,8x20mm Hex screw galvanized 4.8mm (no rubber washer) GSPublisherVersion 215.0.27.100...
  • Page 16 GSPublisherVersion 215.0.27.100...
  • Page 17 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Garagentor-Pfosten 50x50x3mm 2793 Garage Door Vertical Garagentor-Befestigungsprofil 50x50x3mm Garage Door-fastening tube Garagentor-Sturz 50x50x3mm 2750 Garage Door Header Pfosten (Rückwand) 50x50x3mm 2894 Back Vertical Tür-Sturz 50x50x3mm Personnel Door Header Dachpfette 38x38x1.5mm 3015...
  • Page 18 MODELNAAM HEAD_DESCRIPTION LENGTH QTY ITM Item Tag Door post left side 2764 LOA00106-06-02-005.PRT Door post right side 2528 LOA00106-06-02-004.PRT Beam above walk door 1061 LOA00106-06-02-009.PRT Bracket B5 LOA00106-06-02-010.PRT SC-B Bohrschraube / Selfdrilling Screw 4.2x16 SC-B.PRT...
  • Page 19 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Sechskant-Bohrschraube 4,8mm (ohne Scheibe) SC-B (D1) 4,8x20mm Hex screw galvanized 4.8mm (no rubber washer) Flachkopf-Bohrschraube 4,8mm SC-C (D2) 4,8x25mm Pancake square drive screw 4.8mm GSPublisherVersion 215.0.27.100...
  • Page 20 MODELNAAM HEAD_DESCRIPTION QTY LENGTH ITM Item Tag U-strip loopdeur 2130 LCA00001-011.PRT BO-7 Käfigmutter / Cage nut / Kooimoer M5/1.2-1.6/H8.3x8.3 KOOIMOER_M5.PRT...
  • Page 21 5.5x19 MODELNAAM HEAD_DESCRIPTION U-strip loopdeur 2130 Bovenligger / Onderligger loopdeur 1058 DIN_7504K_5_5X19_BP3 Sechskant-Bohrschraube / Selfdrilling Screw 5.5x19 BP3 FISCHER-N6X60_30 Slagplug Ø6x60mm...
  • Page 22 MODELNAAM HEAD_DESCRIPTION LENGTE Item Tag U-strip loopdeur 2130.000000 LCA00001-011.PRT DIN_7504K_5_5X19_BP3 Sechskant-Bohrschraube / Selfdrilling Screw 5.5x19 BP3 19.000000 DIN_7504K_5_5X19.PRT...
  • Page 23 MODELNAAM QTY HEAD_DESCRIPTION LENGTH Item Tag Klemstrip loopdeur 2128 LCA00001-012.PRT DIN933_M5x25 Hexagon bolt / zeskant bout DIN933 M5x25 DIN933_M5X25.PRT DIN125A_M5 Unterleg scheibe / washer / sluitring M5 DIN125A_M5.PRT Loopdeur hxb 210x97 RVS beslag LCA00001-005.PRT...
  • Page 24 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Torseitenblech (L-Profil) 40x52x0,5 3000 Trim Garage Door Flachkopf-Bohrschraube 4,8mm SC-C 4,8x25mm Pancake square drive screw 4.8mm GSPublisherVersion 215.0.27.100...
  • Page 25 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Seitenblech rundum Tor (J-Profil) 26/60x22x0,5 3000 Trim Garage Door Seitenblech rundum Tür (J-Profil) 26/60x22x0,5 2100 Trim Personnel Door Seitenblech oben Tür (J-Profil) 26/60x22x0,5 1100 Horizontal Trim Personnel Door Flachkopf-Bohrschraube 4,8mm SC-C 4,8x25mm...
  • Page 26 MODELNAAM HEAD_DESCRIPTION LENGTH Item Tag J-trim 2176 LOA00106-11-002.PRT J-trim 1113 LOA00106-11-003.PRT...
  • Page 27 S4 x 3 S4 x 3 S4 x 3 S4 x 3 S4 x 3 upper screw below rib 1 screw above each rib Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Wand-Trapezblech 900x0,5 3080 Wall Panels Side Sechskant-Bohrschraube (Bleche) SC-A 4,8x25mm...
  • Page 28 S5 x 4 S5 x 4 S5 x 4 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Giebel-Trapezblech 900x0,5 1950 Gable End Panels Giebel-Trapezblech 900x0,5 2900 Gable End Panels Giebel-Trapezblech 900x0,5 1430 Gable End Panels Sechskant-Bohrschraube (Bleche) SC-A 4,8x25mm Self-Drilling Screw (Sheets, trims)
  • Page 29 FS-1B FS-1B Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Fußblech Traufe 89x56x0,5 3100 Eave Trim Flachkopf-Bohrschraube 4,8mm SC-C 4,8x25mm Pancake square drive screw 4.8mm GSPublisherVersion 215.0.27.100...
  • Page 30 S1 S1 S1 S1 170 mm Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Dach-Trapezblech 1090x0,5 2900 Roof Panels Transparente Dachplatte 1090x1,5 1050 Skylight Panels Dach-Trapezblech 1090x0,5 1900 Roof Panels Thin Strips at roof metal sheet (eave trim) FS-1B 1025 Foam, inside closure (selfadhesive)
  • Page 31 1/2 T1 1/2 T1 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Giebelblech 140x150x0,5 2050 Gable Trim Sechskant-Bohrschraube (Bleche) SC-A 4,8x25mm Self-Drilling Screw (Sheets, trims) GSPublisherVersion 215.0.27.100...
  • Page 32 FS-1A FS-1A Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Firstblech (Firstkappe) 283x73x0,5 3150 Ridge Cap Thick Strips at roof metal sheet (ridge cap) FS-1A 1025 Foam outside closure (selfadhesive) Sechskant-Bohrschraube (Bleche) SC-A 4,8x25mm Self-Drilling Screw (Sheets, trims) GSPublisherVersion 215.0.27.100...
  • Page 33 FS-2 (2x) FS-2 (2x) FS-2 (2x) FS-2 FS-2 Länge Teil-Nr. Beschreibung Maß Bild length Part No. Description Size Image (mm) Außeneckwinkel 100x100x0,5 2800 Corner Trim Thick strips at side metal sheet FS-2 Foam outside closure (selfadhesive) Sechskant-Bohrschraube (Bleche) SC-A 4,8x25mm Self-Drilling Screw (Sheets, trims) GSPublisherVersion 215.0.27.100...
  • Page 34 Höhe einkürzen Height adjustment Addieren 400mm add hole 5 3x Schiene Roltor Rail garage door Teile Einkürzen: shorten parts: Einkürzen: 12 17 19 22 23 Shorten: Unterseite Einkürzen Bottom Shorten...
  • Page 35 Alle Wandpanele: All wall panels: S4, S5 en S7...
