Lincoln Series A Manual

It is the responsibility of the Owner/Operator to properly use
and maintain this equipment.
The instructions and Warnings contained in this manual
shall be read and understood by the Owner/Operator prior to
operating this equipment.
It is the responsibility of the Owner/Operator to maintain the
legibility of all Warning and Instruction labels.
The Owner/Operator shall retain this manual for future
reference to important Warnings, Operating and
Maintenance instructions.
JULY - 2011
To order call 1-800-548-1191 or visit www.partdeal.com - info@partdeal.com
One Lincoln Way
St. Louis, Missouri 63120-1578
(314) 679-4200
HYDRAULIC MOTOR
DO NOT exceed the stated maximum working pressure of
the hydraulic motor or of the lowest rated component in your
system.
DO NOT alter or modify any part of this equipment.
DO NOT operate this equipment with combustible fluids.
DO NOT attempt to repair or disassemble the equipment while
the system is pressurized.
TIGHTEN all fluid connections securely before using this
equipment.
ALWAYS read and follow the fluid manufacturer's
recommendations regarding fluid compatibility, and the use of
protective clothing and equipment.
CHECK all equipment regularly and repair or replace worn or
damaged parts immediately.
IMPORTANT: Failure to heed these warnings including
misuse, over pressurizing, modifying parts, using incompatible
chemicals and fluids, or using worn or damaged parts, may
result in equipment damage and/or serious personal injury, fire,
explosion, or property damage.
Maximum Delivery
Pump Type Pump Tube Ratio Pressure
POWER- 84981
Master 84982
III 84983
84984 1.5:1 2250 psi (155 bar)
84985
84986
84987
84976 2.5:1 3750 psi (258 bar) 1500 psi (103 bar)
84977
84978 4:01 6000 psi (412 bar)
84979
84991 3:01 4500 psi (310 bar)
84992
84993 4.5:1 6750 psi (466 bar)
84994
84995 5:1 7500 psi (517 bar)
84996
84997 7:1 7000 psi (483 bar) 1000 psi (69 bar)
84998
PILE 84900 0.8:1 1200 psi (83 bar)
DRIVER 84901 1:1 1500 psi (103 bar)
III 84902 1.5:1 2250 psi (155 bar)
84904 1:1 1500 psi (103 bar) 1500 psi (103 bar)
84921 0.4:1 600 psi (41 bar)
84922
84923 0.2:1 300 psi (21 bar)
Copyright 2011
Printed in U.S.A.
Model 85300
Series "A"
Maximum Hydraulic
Inlet Pressure
-A50
Section
- 87D
Page
FORM 404258
