INSTALLATION GUIDE
Step 8
Place the kit panel in
the dash opening.
Step 9
Slide the metal support sleeve into the
radio opening and fasten with locking
tabs. (Right Photo)
Connect all wiring harnesses and slide
in the Double DIN stereo until it locks
into place. (Right Photo)
Step 11
Snap-in the double DIN trim ring.
MZ2351B 01/16
4
IN-DASH INSTALLATION KIT FOR
2005-12 MERCEDES BENZ SL CLASS
Tool Required
KIT CONTENTS
•
PRT (Panel Removal Tool)
1.
Metal support sleeves
•
Screwdriver
2.
Brackets
3.
Kit panel
4.
Double Din Trim Ring
This premium installation kit is for 2005-12 Mercedes Benz SL Class vehicles with base model radio (dash modification
required). Included are all the parts you need to mount your car stereo or CD player into your vehicle's dash. Refer to
individual instruction in this manual to remove your vehicles factory radio and assemble the kit.
MZ2351B
VEHICLES
VWA3B
Antenna Adapter
(Sold Separately)
MZ2351B 01/16
Advertisement
Table of Contents
Related Manuals for Scosche MZ2351B
Summary of Contents for Scosche MZ2351B
- Page 1 Included are all the parts you need to mount your car stereo or CD player into your vehicle’s dash. Refer to Snap-in the double DIN trim ring. individual instruction in this manual to remove your vehicles factory radio and assemble the kit. MZ2351B 01/16 MZ2351B 01/16...
- Page 2 (Right Photo) Push opening. Test fit and adjust the side cup holders back in. clips so the nose of the Aftermarket stereo is flush with dash kit panel when snapped into place. MZ2351B 01/16 MZ2351B 01/16...
