Infinova V1421 Series Installation & Operation Instructions

Explosion-proof camera housing

Advertisement

Quick Links

V1421 Series
Explosion-proof Camera Housing
Installation/Operation Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the V1421 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Infinova V1421 Series

  • Page 1 V1421 Series Explosion-proof Camera Housing Installation/Operation Instructions...
  • Page 3 Infinova. Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and user documentation for all Infinova products are available on our web site www.infinova.com...
  • Page 4 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. Unplug the power supply when the device is not to be used for an extended period of time.
  • Page 5: Table Of Contents

    Table of Contents Chapter I Product Description...................1 Chapter II Product Model ....................2 Chapter III Features......................3 Chapter IV Explosion Proof Outline.................4 Chapter V Specifications ....................5 Chapter VI Product Dimension and Installation Demonstration......6...
  • Page 7: Chapter I Product Description

    Chapter I Product Description Explosion-proof housing is used worldwide for those environments containing dangerous explosive gases. Its design perfectly meets the requirements in terms of installation in dangerous area, explosion proof and dust proof. The V1421 Explosion-proof housing is explosion-proof housing that meet stringent explosion-proof requirements.
  • Page 8: Chapter Ii Product Model

    V1665-W1 Adjustable Wall Mount Bracket, 316 Stainless Steel Housing model is presented as V1421-XXXX, of which “V” stands for Infinova. 1421 represents the explosion proof series products from V1400-V1499 and 1421 belongs to explosion proof series products. The detailed definition is shown as follows:...
  • Page 9: Chapter Iii Features

    Chapter III Features For explosive gas atmospheres part 2: suited for the dangerous sites with explosive air mixture division 1 and division 2, flammable gas, steam classification A, B, C, and temperature Ⅱ classification T1-T6 Toughened glass used for explosion-proof housing front window and stainless steel used for body and base.
  • Page 10: Chapter Iv Explosion Proof Outline

    Chapter IV Explosion Proof Outline When the explosive gas mixture blows up inside pan/tilt, the explosion-proof housing should not be damaged and the explosive flame inside will not cause other surrounding explosive mixtures to blow up via explosion-proof joint surface. In the process of pan/tilt structure design, we have fully taken housing strength, structure, temperature and other respects into consideration to make it would not spark under normal application to ensure the security and reliability of product.
  • Page 11: Chapter V Specifications

    Chapter V Specifications V1421 General Electrical Electrical Parameter: 24VAC, 60/50Hz, <1A; 110VAC/240VAC, 60/50Hz, <250mA Power Consumption: 30W (maximum) Mechanical Construction: 316 Stainless Steel Environmental Rating: IP66 Window Glass: Diameter 67mm toughened glass Cable Connection: 1 cable port, connected to housing rear cover; cable diameter 10mm. External Dimensions: 6.46"...
  • Page 12: Chapter Vi Product Dimension And Installation Demonstration

    Chapter VI Product Dimension and Installation Demonstration 6.1 Housing Dimension (Unit: mm) Figure 6-1 Side View Figure 6-2 Front View Figure 6-3 Rear View 6.2 Housing base mount holes position Figure 6-4 Figure 6-5...
  • Page 13 6.3 Bracket Mount Dimension (Unit: mm) Figure 6-6 Figure 6-7 6.4 Installation Process and Demonstration 1. Firstly fix wall mount bracket to the desired wall via four installation holes. Then secure the screws in the upper and lower adapter. Figure 6-8 2.
  • Page 14 the cable hole on housing base the hole between lower adapter and wall mount bracket the hole on lower part of wall mount bracket Figure 6-9 3. After that, adjust the screws fixed between upper and lower adapter and the screws between lower adapter and wall mount bracket to provide a good angle of view of camera within the housing.
  • Page 16 Shenzhen Infinova Limited, China is a registered trademark owned by Infinova. © 2010 Infinova V1.2 1005...
