1.2 Range of application The Kabola KB-Series are designed to generate heat for the heating of water and for a central heating system. The boilers can also be used for the generation of domestic hot water generated by a compact brazed heat exchanger.
In this chapter we emphasis the safety-related points for operating the boiler. 2.1 General safety Warning: Although Kabola Heating Systems designs and produces its products according to the current safety standards, it is possible that dangers may present themselves, which could lead to injuries or damage to the boiler, if the safety instructions in this manual are not complied with.
Store the boiler and accompanying parts in a dry place; Store the boiler standing up; Store the boiler on a firm horizontal base. Figure 1 Instruction manual Kabola KB-Series version 6, 2018...
Use an earthed plug socket for connecting the 230 Volt AC versions to the power supply. Hint: As a rule of thumb for the ventilation openings, take 2,5 times the diameter of the flue gas outlet. Instruction manual Kabola KB-Series version 6, 2018...
It is possible to use the boiler when the domestic water side is not connected KB-20 / 40 / 45 / 50 / 75 Instruction manual Kabola KB-Series version 6, 2018...
Page 9
5. The numbers A and B you will find on the housing of the three-way valve Note: There must always be a thermostat mounted on the Calorifier to communicate with the KB series (available at your Kabola supplier with number: 9-i025) Instruction manual Kabola KB-Series version 6, 2018...
The boiler has got a high efficiency, and the burner will start even when there is no heat demand, this is done to avoid that there is a lot of condensation in the boiler. Condensation will short the life time of the boiler Instruction manual Kabola KB-Series version 6, 2018...
Page 11
Always install a drain with tap directly on the boiler See Figure 4.a Figure 4.a Your Kabola supplier can provide you with all components which may be required for installation such Cowls; Flexible piping; Single and double walled chimney pipes;...
(green arrow). Remove the bridge from T1 and T2 and connect the 2-core cable of the room thermostat to T1 and T2, as indicated on the sticker in the connector. Figure 6.2 Instruction manual Kabola KB-Series version 6, 2018...
Page 13
Before you connect the room thermostat with Frost Guard, use a 4-core insulated wire 0,75 mm2. Remove the right plug (green arrow) which you can find at the backside of the Kabola dashboard (figure 12). Connect the 4 wires of the room thermostat at T1 and T2 and S3 and B4 in connection A (figure 11) at the backside of the dashboard as shown on the sticker inside the connector.
See manual from the circulation pump. Attention: When locking pump couplings are supplied with the boiler, the adjusting grooves must point towards the pump. Venting mode: Turn switch on 12 o’clock Operating mode: Turn switch at +/-position 3 Instruction manual Kabola KB-Series version 6, 2018...
5. Open the valve on the oil filter; 6. Disconnect the power from the motor to the oil burner (only Kabola engineer) 7. Use the startup cable, and connect with this cable the power to the motor from the oil pump 8.
Numbers Explanation Photo Rest position (boiler is on stand-by) Circulation pump stopped Room thermostat demands heat. Circulation pump operating Circulation pump further running time. Circulation pump operates for ± 3 minutes KB-series Combi-Calorifier Instruction manual Kabola KB-Series version 6, 2018...
Page 17
Boiler is heating to keep domestic water on temperature. Blinking dot = Hot water out Burning dot = Hot water stand-by The number (19) on the right side of the display shows the current boiler water temperature Instruction manual Kabola KB-Series version 6, 2018...
1. If the tap is visible at the display of the room thermostat, than the tap water is switched on. If not, it’s switched off. Please switch on. 2. The display on the Kabola dashboard won’t show the flashing dot anymore, if correct. 3. Put the room thermostat on a low temperature.
Spare parts must be ordered through your Kabola supplier. For warranty purposes only original spare parts must be used. When ordering spare parts, state the type of boiler and its serial number. Your Kabola supplier will then be able to supply the correct parts. In Appendix B, the main spare parts are listed.
Pump not connected to electricity Connect pump supply Rotor of pump is stuck Turn pump with your hand (see pump manual) When problems with the boiler will not disappear, call an engineer from Kabola. Instruction manual Kabola KB-Series version 6, 2018...
Page 27
Knee coupling 1” out x 22 mm 17-R125 3-way valve 24 VAC (v8044c1065) 10-J004 Coupling 1 “out x 22 mm 17-R149 Coupling ½” ins. x 15 mm 17-R157 Knee coupling ½” x 15 mm 17-R068 Instruction manual Kabola KB-Series version 6, 2018...
Page 28
Spareparts list model 2016- 2017 Instruction manual Kabola KB-Series version 6, 2018...
Kabola Heating Systems BV Placotiweg 1 E 4131 NL Vianen The Netherlands decIare under our own responsibility that the product: Kabola KB20/KB40/ KB45/ KB50/ KB75 combi 230V to which this declaration relates complies with the fol/owing standards 303-1, 303-2, 304, 50081-1, 50082-1.
