Installation Manual
HPNFC-RT
WARNING: DO NOT LIFT FIXTURE BY CABLES.
Do not attempt to install or use the HPNFC-RT
fixture without reading the installation instructions
and safety labels completely.
This could result in permanent damage to both the fixture and the cables. Damage resulting from grasping cables and/or putting
undue pressure on the cable connections will not be covered under the warranty!
FAILURE TO ADHERE TO THESE INSTRUCTIONS COULD RESULT IN SERIOUS
INJURY OR PROPERTY DAMAGE.
DO NOT MODIFY, ALTER OR ATTEMPT TO SERVICE THE HPNFC-RT
DOING SO WILL VOID THE WARRANTY.
Advertisement
Table of Contents
Related Manuals for Boca Flasher HPNFC-RT
Summary of Contents for Boca Flasher HPNFC-RT
- Page 1 FAILURE TO ADHERE TO THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE. DO NOT MODIFY, ALTER OR ATTEMPT TO SERVICE THE HPNFC-RT DOING SO WILL VOID THE WARRANTY.
-
Page 2: Electrical Specifications
Introduction: The Boca HPNFC-RT is a line voltage fixture that eliminates the need for secondary transformers, making installation contractor friendly. The housing is a clear anodized aluminum with a durable finish making it weather and abrasion resistant. It is UL Listed for dry, damp or wet location (model dependent). - Page 3 (clip edge or hole) and space the clips according to the length of each fixture (see figure A). Clip placement: Boca Flasher recommends clips to be installed 1.5” from end cap. 2. Snap in the first light fixture into the clips (see section 2, installing fixtures into clips). Snap the 2nd. light fixture into adjacent clips ensuring that the connections will mate (male to female, see figure B).
- Page 4 90° bend. 3” Arc and 6” Arc Bracket Installation Screw Information: 1. Screws not provided by Boca Flasher. 2. Boca Flasher recommends wide washer flat head Philips #8 screw (not to exceed .418” in diameter). 3. Length of screw will vary depending on mounting surface.
- Page 5 Installation Instructions HPNFC-RT 3. CLIP POSITIONING Fixed Mounting Clip FIXTURE LENGTH FIXTURE LENGTH Swivel Mounting Clip Arc Mounting Clip FIXTURE LENGTH FIXTURE LENGTH FIXTURE LENGTH FIXTURE LENGTH 4. CONNECT DMX CABLES TOGETHER AS SHOWN ON JOB SPECIFIC DRAW- Rotate fixture to see bottom and...
- Page 6 Installation Instructions HPNFC-RT Installation of clips for light fixtures with TWIST LOCK Connections 1. Light fixtures that have twist lock connections on each end may be installed in areas where the surface plane may be at slightly different levels between light fixtures. Also, the light fixtures do not have to be in straight alignment and can be laid out to different angles and patterns.
- Page 7 Installation Instructions HPNFC-RT 4. CONNECT FIXTURES TO POWER Recommended Install - Option 1 CLASS-1 120/277V NEMA 4R 12V - CLASS-1 12V - CLASS 2 (8 outputs) 4. CONNECT FIXTURES TO POWER Recommended Install - Option 2 CLASS-1 NEMA 4R 120/277V...
- Page 8 • Do not use attachments not recommended by Boca Flasher. • Never operate the HPNFC-RT if it has a damaged cord, cable or plug, if it is not working properly, if it has been dropped or damaged, or dropped into water. If the seal appears to be damaged/broken/torn return the fixture to a service center for examination or repair.
