Page 1
DSP2022-S SCSI Disk Drive Installation Guide EK-2022S-IG-001 Digital Equipment Corporation...
Page 2
June, 1992 The information in this document is subject to change without notice and should not be construed as a commitment by Digital Equipment Corporation. Digital Equipment Corporation assumes no responsibility for any errors that may appear in this document.
DSP2022-S SCSI Disk Drive Installation Guide 1 Scope of Information This guide supplies information needed to configure and install your Model DSP2022-S 2.5-inch Small Computer System Interface (SCSI) disk drive. The tasks you need to perform are listed in order in the table of contents. The specifications for the disk drive are found on the last page.
2 DSP2022-S SCSI Disk Drive Installation Guide Locate the SCSI Connector Locate the SCSI 50-pin connector shown at the rear of the drive in Figure 1 . This connector is used for cable installation later. Note that the pins of the SCSI connector are divided into two pin fields: one for the SCSI interface...
DSP2022-S SCSI Disk Drive Installation Guide 3 Note Pin Status of the Vendor-Specific Field The vendor-specific pin field consists of pins A1–A8. These pins are used for testing at the factory, setting the SCSI ID address remotely, and supply power to an external drive activity light emitting diode (LED).
DSP2022-S SCSI Disk Drive Installation Guide 5 Locate Jumper Connector J1 Locate jumper connector J1 on the electronic component side of the drive, shown in Figure 2. Note that connector J1 contains eight jumper pairs numbered 0 through 7. Your drive comes with all jumpers in place.
6 DSP2022-S SCSI Disk Drive Installation Guide Learn the Jumper Functions The jumper functions on the SCSI drive are described in Table 3. These jumpers allow you to set the device address, disable automatic spin-up, change the delay time before spin-up, and enable drive power for an external SCSI terminating resistor.
DSP2022-S SCSI Disk Drive Installation Guide 7 Set the SCSI Device Address Jumpers 0, 1, and 2 are used to set the SCSI device address. Table 4 shows the jumper IN or OUT status for setting the SCSI device address. IN means jumpers are in place and OUT means jumper are removed.
8 DSP2022-S SCSI Disk Drive Installation Guide Set the SCSI Address Remotely When jumpers 0, 1, and 2 are left in place for a device address of 0, the drive will use the remote active encoded SCSI device address (ID) number on the vendor-specific connector at the rear of the drive.
DSP2022-S SCSI Disk Drive Installation Guide 9 Provide SCSI Bus Termination The SCSI bus only needs termination resistors at the beginning and end of the bus. Since this drive does not have a SCSI bus terminating resistor on it, bus terminating resistors must be located external to the drive.
10 DSP2022-S SCSI Disk Drive Installation Guide Figure 4 Bottom Mounting Holes 4.000 in 101.60 mm .165 in MOUNTING HOLE SCREW (4) 4.19 mm M3 x 0.05 2.420 in 61.47 mm 1.375 in 1.500 in 34.93 mm 38.10 mm CXO-3495A-MC_R...
DSP2022-S SCSI Disk Drive Installation Guide 11 Use the Drive Mounting Guidelines Use this list of drive mounting guidelines to prevent mounting problems. • The drive may be mounted in any orientation. • Mounting screws should not penetrate the mounting holes beyond the depths given in this list.
12 DSP2022-S SCSI Disk Drive Installation Guide Drive Specifications The performance and environmental specifications for your disk drive are listed in Table 6. Table 6 Drive Specification Summary Formatted Storage 220,000,000 bytes Average Seek Time Less than 10 milliseconds Typical spin up time Less than 12.5 seconds...
