Demo Board Manual --- DB-C
Micro Power Step-Up DC/DC Converter
AP3015
Content:
3. Schematic of the Demo Board
August. 2006 Rev. 1.2
1
BCD Semiconductor Manufacturing Limited

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP3015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Diodes AP3015

  • Page 1: Table Of Contents

    Demo Board Manual --- DB-C Micro Power Step-Up DC/DC Converter AP3015 Content: 1. Description 2. Specification 3. Schematic of the Demo Board 4. PCB Layout 5. Photo View of the Demo Board 6. PCB Dimensions 7. BOM 8. Test Result August.
  • Page 2: Description

    Description The AP3015 is a step-up DC/DC converter, which can be used for positive and negative output LCD/OLED bias supply. In fact, it is a standard boost circuit, where the AP3015 works as the driver and control device. The AP3015 features a wide input voltage range. The operation voltage is ranged from 1.2V to 12V.
  • Page 3: Pcb Layout

    Demo Board Manual --- DB-C Micro Power Step-Up DC/DC Converter AP3015 Schematics of the PCB SS14 10uF 10uF SS14 Cout3 Cout4 SS14 AP3015/A SS14 Cout1 Cout2 SHDN 4.7u 470K 180K Note: Cout2 and Cout4 are backup. Figure 1 PCB Layout Figure 2 August.
  • Page 4: Photo View Of The Demo Board

    Demo Board Manual --- DB-C Micro Power Step-Up DC/DC Converter AP3015 Photo View of the Demo Board Figure 3 PCB Dimensions 41mm 68.5mm August. 2006 Rev. 1.2 BCD Semiconductor Manufacturing Limited...
  • Page 5: Bom

    Demo Board Manual --- DB-C Micro Power Step-Up DC/DC Converter AP3015 Item Quantity Location Part Footprint AP3015 SOT23-5 10uF, Sumida: CDRH5D28RNP-100NC 4.7uF, X7R Ceramic 1206 Cout1, Cout 3 10uF, X7R Ceramic 1206 C1, C2 1uF, X7R Ceramic 1206 10pF, X7R Ceramic...
  • Page 6 3) Efficiency 80.0 77.5 75.0 72.5 70.0 67.5 65.0 62.5 AP3015 DB-C Output Capability & Efficiency 60.0 Vo1=20V, Vo2=-20V, L=10uH Vin=4.2V 57.5 Vin=2.5V 55.0 Output Current (+mA) Note: The Max. Output Capability is ±8mA @ Vin=2.5V and ±12mA @Vin=4.2V. The recommended maximum Output Capability is ±6mA @ Vin=2.5V and ±10mA @Vin=4.2V.
