Page 1: Table Of Contents
For household use Vacuum Cold & Hot All-in-One Blender Product Number: TMV3000SEA Table of Contents Instruction ……………　 1～4 Safety Warnings Manual …　 5～8 Part names and functions …………………… Specifications Thank you for your purchase. Before using this product, Using the vacuum ………...
Page 2: Safety Warnings
Safety Warnings Detailed information on cleaning the appliance can be found in the section Maintenance. ● Before using this product, please read these precautions and use the product correctly. ● The precautions shown below are provided to ensure safe product use and to prevent harm to the user and those nearby, as well as to prevent property damage.
Page 3 Safety Warnings Do not move the appliance during operation. Caution Do not use in an unstable place. Please plug and unplug the power Never perform no-load running. cord only after confirming that the Do not use the unit with ingredients of an power is OFF.
Page 4 Safety Warnings When Using the Vacuum Function If foreign matter is sucked into the main body along with air during vacuum processing or vacuum storing, a failure may occur. Please Caution use the product by complying with the following instructions. Potential foreign matter To prevent failures sucked into the main body...
Page 5 Safety Warnings When Using the Heat Processing Function Please follow the precautions below, because the entire bottle set reaches high temperatures. Warning The Heat Processing Bottle is only to be used with this appliance. • Always process volumes at or below the maximum volume of the processing bottle.
Page 6: Part Names And Functions
Part names and functions First, please check to see if the package has all the necessary parts and accessories. The seal material is already attached to the applicable parts. Main body Arm cover (w/ suction port) Suction port Vacuum arm (not removable) Safety switch Indicator...
Page 7 Part names and functions Control panel Timer display lamp Error notification lamp Rotation level display lamp (Please see pp. 29–30) Selection course lamp Display Dial Pulse button Cancel/Release window The outside edge turns. Start/Stop button button The center is the selection button. Vacuum Heat Course...
Page 8 Part names and functions When you use the blender for the first time or when using it after it has been stored for a while, please wash all parts other than the main body before use. (Please see pp. 31–36) Vacuum Processing Bottle Set Tumbler set Two sets included.
Page 9: Specifications
• Spatula • Cleaning brush The specifications of the product and its parts are subject to change without notice. Name of product Vacuum Cold & Hot All-in-One Blender Product number TMV3000SEA Power source 220-240V~ 50-60Hz Length of cord 1.2m Power...
Page 10: Using The Vacuum Processing Function
Using the vacuum processing function Unusable ingredients (causes of failure) ★Ingredients with ★Hard or dry ingredients ★Sticky ingredients a temperature · Frozen food (excluding fruit) higher than 40℃ · Commercially available ice ★Meat or fish · Dried bonito or dried soybeans ★Flour such as ·...
Page 11: Processing Function
Using the vacuum processing function Advice on processing To prevent the unit from going idle liquids such as water are Preparing without adding necessary, but when ingredients themselves provide enough moisture water or other liquids you can perform processing without any liquid. ·...
Page 12: Processing Function
Using the vacuum processing function Vacuumize the interior of the vacuum processing bottle and process with the vacuum blending function. Initial oxidation can be curbed and the progress of oxidation can be delayed by removing air before stirring the ingredients. Add the prepared ingredients (please see p.
Page 13: Processing Function
Using the vacuum processing function * Vacuum: A state of pressure that is lower than atmospheric pressure Cover it securely. *If there are foreign objects or moisture on the cover set, wipe the set off. (1) Attach the container cover, and place the (2) Press down on the container gasket in the middle.
Page 14: Processing Function
Using the vacuum processing function Select a course and process. · After the air has been removed from inside the bottle, the appliance will stir until the timer reaches 0, and stop automatically. (Regular rest periods are included during stirring.) ·...
Page 15 Using the vacuum processing function Remove the bottle set from the main body after the cutter has fully stopped rotating. *When stirring is insufficient, after stopping the appliance (before removing the vacuum arm), use the pulse button or Vacuum arm set it to manual mode to use.
Page 16: Using The Vacuum Storage Function
Using the vacuum storage function This function is used for the later storage of smoothies, etc., already made using the vacuum blending function. Freshness can be maintained since substances are stored by vacuumizing* the tumbler internally. This has no anti-bacterial effect. You must store the smoothie in a refrigerator. Depending on the ingredient combination, the food may separate during storage.
Page 17: Using The Vacuum
Using the vacuum storage function * Vacuum: A state of pressure that is lower than atmospheric pressure Slowly pour the smoothie made with the vacuum blending function into the tumbler so that it does not foam, and place the cover. *When vacuum-storing Rotating leftover liquid again, clean...
Page 18: Using The Vacuum
Using the vacuum storage function Vacuum-store the contents. (1) Turn the dial to switch on the smoothie course lamp (2) Press the Start/Stop button to store. · The vacuum arm will disconnect after the air has been removed from inside the tumbler and it has been made into a vacuum.
Page 19: Storage Function
Using the vacuum storage function Attach the tumbler cover cap. (1) Align the protrusions on the (2) Rotate the tumbler cover cap in tumbler cover cap with the the direction of the arrow in the grooves on the tumbler cover. illustration.
Page 20: Using The Heat Processing Function
Using the heat processing function You can choose from three courses to process. ● Soy milk course: for processing ingredients that froth easily when heated or stirred, such as legumes and corn. ● Soup course: for smooth ingredients that do not froth easily, and for making soup using hard ingredients that need to be stewed for a long time.
Page 21: Processing Function
Using the heat processing function Place the prepared ingredients (please see p. 9) into the heat processing bottle, first solids, then liquids. Heat *Always add liquid. Without liquid, the ingredients processing bottle will burn and may damage the appliance. Minimum amount: 800ml C o ld C o ld 2 0 0 0...
Page 22: Processing Function
Using the heat processing function Fold the vacuum arm, and mount the bottle to the main body in the direction shown in the diagram. Fold Col d 20 00 17 50 15 00 12 50 100 0 Failure warning: Do not mount the bottle at an angle. This may damage the main body.
Page 23 Using the heat processing function When operation has stopped, wear oven mitts to prevent burning, and remove the bottle set from the main body by lifting it straight upward. *When stirring is insufficient, use the pulse button or set it to manual mode to use.
Page 24: Using The Mixing Processing Function
Using the mixing processing function This function stirs the contents without turning the interior of the bottle into a vacuum. With this function, you can make smoothies or other mixes using things that cannot be used in vacuum processing, such as difficult-to-dissolve powders, warm ingredients, and ingredients that froth easily.
Page 25 Using the mixing processing function Course Operation procedures Smoothie course (1) Turn the dial to switch on the lamp for the course you will use. Frozen course (2) Press the Start/Stop button to process. 1.Turn the dial to switch on the , and press the center of the dial to select.
Page 26: Using The Powderizing Function
Using the powderizing function With this function, you can crush hard objects and turn them into powder. The powderizing function can be used for 1 minute at a time. Less than 1 minute After using it for 1 minute continuously or in total, please only use it again after allowing the appliance to rest for at least 30 minutes.
Page 27: Powderizing Function
Using the powderizing function lace the cover, mount to the main body with the vacuum arm folded down, and turn on the power. (Please see pp. 19-21) Select the powderizing course to process. Turn the dial and switch on the powderizing course lamp Press the Start/Stop button to process.
Page 28: Using The Pulse Button
Using the pulse button With this function, the cutter rotates only while the pulse button is being pressed. This function is useful when a smoothie has started to separate, Less than 1 minute or for adding more stirring for a short period of time. You can also make crushed ice with the pulse button.
Page 29: Using The Stirring Rod
Using the stirring rod With the stirring rod, you can mix in ingredients that have stuck to the inside of the bottle during processing. The stirring rod cannot be used during heat processing. This may cause burning. Press the Start/Stop button to stop operation. Press When the rotation comes to a complete stop, remove the heat processing bottle cover cap and mount the stirring rod.
Page 30: About Error Notification
About error notification Check the number displayed, then press the Cancel/Release button to cancel. (When it cannot be cancelled, turn the power switch to OFF. One lamp is blinking. Bottle Unable to Unable to Temperature mounting create a process abnormality error vacuum Check number...
Page 31: About Error Notification
About error notification Turn the power switch OFF, and pull out the power plug from the outlet. Remove the bottle set/tumbler set from the main body. Check the following causes and respond accordingly. *If the appliance still cannot be fixed, ask for help at the store. Display Cause Response...
Page 32: Maintenance
Maintenance •Please never forget to turn OFF the power and pull out the power plug from the outlet before you begin product maintenance. •If the bottom surface of any bottle, or the electrodes in the main body get wet, this will damage the appliance. Do not get it wet, or splash water on it.
Page 33 Maintenance Maintenance procedures for the main body Squeeze out a soft cloth soaked in soapy water or a neutral detergent diluted with water and wipe down the main body. Avoid water exposure Please be careful not to get the main body wet because it cannot be washed with water.
Page 34 Maintenance Maintenance procedures for each bottle How to remove each part Vacuum processing bottle set ● Vacuum processing Remove the vacuum processing bottle cover bottle cover cap from the vacuum processing bottle. Remove the vacuum processing bottle cover cap from the bottle cover that has been Float removed, and remove the float.
Page 35 Maintenance Maintenance Wash each part with a sponge using neutral detergent, and rinse it well with water or lukewarm water (lower than 40˚C). Prohibition Please wipe the cover after shaking Do not get the bottom of the bottle wet. it well because water easily pools Do not splash with water.
Page 36 Maintenance Maintenance procedures for the tumbler set How to remove each part (1) Remove the tumbler cover cap from (2) Press the PUSH portion of the releasing the tumbler cover by rotating it in the mechanism, and remove by pulling from direction of the arrow in the illustration.
Page 37 Maintenance Maintenance Wash each part with a sponge using neutral detergent, and rinse it well with water or lukewarm water (lower than 40 ℃ Water may enter between the exterior surface and the interior surface of the tumbler when they are not closed tightly or when the tumbler is soaked in water, etc.
Page 38: Troubleshooting
• When processing has been suspended by pressing the Cancel/Release button after stirring has started. • After removing the vacuum arm when vacuum processing has been completed. In order to download this user manual, please visit the TESCOM website below. ▶ http://www.tescom-japan.co.jp/global/...
