TDT MF1-M-Mono Configuration Manual page 3

System 3
To configure the MF1 for closed-field:
1.
2. Ensure the blue o-ring is in place at the base of the desired tip, as shown.
3. Insert one of the tips into the groove on the CF adapter. Ensure the tip is
4. Attach a BNC to RCA adapter to the BNC amplifier port of your source
For Closed Field Configuration Only
If desired, the provided stand can be attached to the speaker using a thumbscrew.
•
Ensure black o-ring is in place on back of CF adapter, as shown.
Attach the CF adapter to the front of the speaker using three of the
provided 1/4 x 4-40 hex screws.
bottomed in its socket. If using the tube tip, gently insert the tube into the
narrow end of the tip.
device.
Attach the CF filter to the RCA cable.
Connect the MF1 to the amplifier using the RCA cable (with CF filter
attached).
CF Filter
MF1 Multi-Field Magnetic Speakers
