In the Box
Force Pro×1
Adapter×1
Screw×2
Introduction
Employing industry-leading communication technologies and control algorithms, the Force Pro is
a camera movement control system that allows operators to control gimbals remotely with
incredible accuracy. By precisely synchronizing operator movement with camera movement, the
Force Pro allows operators to masterfully capture complicated shots more intuitively than ever.
Force Pro supports dual-frequency 2.4 GHz and 5.8 GHz wireless transmission. It also supports a
wired connection, which can prevent interference with other equipment on a film set.
The screen and buttons make it easy to set up parameters on the Force Pro and gimbal. Featuring
a 4750 mAh battery that offers up to 5 hours of operating time, the Force Pro has enough power
for an entire shoot.
The Force Pro is currently only compatible with the Ronin 2, with support for more devices coming
soon. It can be mounted on a tripod or used handheld with the adapter.
Antenna×2
USB-C Cable×1
User Guide×1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Force Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for dji Force Pro

Summary of Contents for dji Force Pro

  • Page 1 The screen and buttons make it easy to set up parameters on the Force Pro and gimbal. Featuring a 4750 mAh battery that offers up to 5 hours of operating time, the Force Pro has enough power for an entire shoot.
  • Page 2 6. Back button Press once to go back to the previous menu. 7. Sleep button Press and hold the button to enable and disable sleep mode. The Force Pro is unable to control the gimbal while in sleep mode. 8. C1 button Customizable button.

  • Page 3: Installation

    Charge and update the firmware of the Force Pro. 15. Power/record button Press to turn on/off the Force Pro (press and hold for eight seconds to turn it off mandatorily). Press once to check the battery level when powered off. Press once to start/stop recording video when powered on.
  • Page 4 Activation Press and hold on the power button to turn on the Force Pro. Activation is required when using it for the first time. Download the DJI Assistant 2 software, and then connect the Force Pro to your computer. Launch...
  • Page 5 3. Linking is successful when the Ronin 2 parameters are displayed on the screen of the Force Pro. For the wired connection, connect the DC IN or DC OUT port on the Force Pro to the Ronin 2 using a dedicated cable (sold separately).
  • Page 6 : Displays the remote controller signal strength. 9. Calibration notice ：Compass calibration is required. 10. Force Pro battery level : Displays the current battery level of the Force Pro. 11. Axes control speed display Displays the control speed for the three axes.

  • Page 7: Gimbal Settings

    Restore force setup: Restores the Force Pro to its default settings. More Access log file: Internal storage is built into the Force Pro for recording data. If the gimbal is acting abnormally, contact DJI Support. If the provided solutions are not successful, DJI Support will request log files for further analysis.
  • Page 8 Basic: The Auto tune, Stiffness, Strength, Filter, and Control values for the tilt, roll, and pan axes can be set independently. Refer to the Ronin 2 user manual for details. More: Set power-on position, fine tune the pan or tilt axis, and test the balance for three axes. SmoothTrack Settings for the pan, roll, and tilt axes can be set independently.
  • Page 9 Motor: Displays the power, angle, and temperature of the motors. Device: Displays the connection status with other devices. Log: Displays any abnormal status information of the gimbal. System Settings General: Includes the Calibrate System, Binding, operating Wi-Fi frequencies and gimbal working modes.

  • Page 10: Updating Firmware

    Charging Use the provided USB-C cable to charge the Force Pro. Connect the DC IN port during usage to power the Force Pro. Connect the DC OUT port to use the Force Pro to power the connected device. Updating Firmware Connect the USB-C port on the Force Pro and the DJI Assistant 2 and follow the onscreen instructions to update the firmware.
  • Page 11 FCC Compliance Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received,including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
