- Page 1 EIA-485 / RS-232 Communications Adapter Installation and Operation Manual Model: RSC-1 1098 Washington Crossing Road Washington Crossing, PA 18977 USA www.morningstarcorp.com...
- Page 2 Technical Specifi cations Mounting Power Input Voltage 8V - 16V The RSC-1 can be mounted on standard 35 mm DIN rail. Four Self Consumption 8 - 16 mA (4) tabs are molded into the bottom of the case. Slide the RSC-...
- Page 3 A low-profi le serial ribbon cable is included with the RSC-1. Use a Null Modem serial crossover cable to connect a PC (or other DCE serial device) to the RSC-1. A Null Modem cable is not included. Step 4 - EIA-485 Bus Power The EIA-485 network requires external power.
- Page 4 Address. Addresses can be programmed using Morningstar’s MSView PC software. Status LED Indication Note • Do not wire more than 128 RSC-1 adapters on a single No bus power or Check EIA-485 bus EIA-485 network (RSC-1 is 1/4 Unit Load) reverse polarity power & polarity •...
- Page 5 The EIA-485/RS-232 Communications Adapter (RSC-1) is warranted to be free from defects in material and workmanship for a period of TWO (2) years from the date of ship- ment to the original end user. Morningstar will, at its option, repair or replace any such defective products.
