Step 3: Cable Path feed through examples directly down to Switcher Looper.

Switcher Looper Set up:

1) Connect the effects pedals to the Accel programmable switch as shown under one of the "Typical
Configuration Drawings" in this user's manual, (pages 12 and 13). Make sure to use a 9V input at least 350mA.
2) Reference the "Over View section (pages 5 – 7) for component and feature identification.
3) Power up switcher.
For this unit to function properly use only a 9V power supply between 350 - 500mA.
(Warning: Use only a 9V power supply. Do not use more than a 9V power supply, this will over heat the
switcher and will not be covered under warranty)
Switcher Looper Overview
5
