SWITCHER / LOOPER PEDAL BOARD
Features:
- Easy Setup
- Clean cable routing
- Rugged Lightweight Aluminum Design
- Accel Power Source 8 Power Supply Mounting Holes
- Universal Power Supply Mounting Bracket for other
manufacturer's Power Supplies (Sold Separately)
- Universal Power Supply Mounting with 3M Dual Lock.
- Links to other Modular XTA series Accel Pedal Boards.
- Dimensions:
22.00" (56cm) L x 14.50" (37cm) W x 2.90" (7.37cm) H
- Instant recall (no latency).
- True bypass design.
- 8 loops in total, 7 series loops and 1 separate loop.
- 2 dedicated foot switches (latch type).
- Individual Tuner/Mute switch.
- Master bypass access.
- Store up to 80 presets, 4 presets per banks, 20 banks.
- Programmable Live/Rehearsal mode:
(Active Bank Setup Mode "ABS").
- Factory Reset.
- Intuitive operation.
USER'S MANUAL
Read this manual before using your FX22 Command Center Pedal Board in order to
ensure proper and safe operation.
Advertisement
Table of Contents
Summary of Contents for Accel FX22 Command center
- Page 1 - Store up to 80 presets, 4 presets per banks, 20 banks. - Programmable Live/Rehearsal mode: (Active Bank Setup Mode “ABS”). - Factory Reset. - Intuitive operation. USER’S MANUAL Read this manual before using your FX22 Command Center Pedal Board in order to ensure proper and safe operation.
-
Page 2: Table Of Contents
1. Keep these instructions – The safety and operating instructions should be retained for future reference. 2. All warnings, cautions and instructions should be adhered too for safe operation of your FX22 Command Center. 3. Follow all operating and use instructions for safe operation of this unit. - Page 3 Introduction The Accel FX22 Command Center Switcher combines two great products together for a clean and easy to setup pedal board. This pedal board is primarily designed to switch multiple guitar effects pedals at the same time along with some amp switching functions using a single footswitch.
- Page 4 Caution: If you are using an Accel power supply or plan on purchasing a FX Pedal Board Universal Power Supply mounting bracket. Make sure you cut out around the holes you plan to use for power supply mounting.
-
Page 5: Switcher Looper Set Up
Switcher Looper Set up: 1) Connect the effects pedals to the Accel programmable switch as shown under one of the “Typical Configuration Drawings” in this user’s manual, (pages 12 and 13). Make sure to use a 9V input at least 350mA. -
Page 6: Bank Dn
(1) BANK DN BANK DOWN switch 1(SW1); In “Recall Mode”, press this switch to decrease the bank number. In “Program Mode”, hit this switch to shift the programming between loop1~4 (“L” in LCD Display ) and loop5~8 (“H” in LCD Display). To toggle between “... -
Page 7: Loop On/Off Indicator
(7) LOOP on/off indicator The indicator is on when a loop is engaged. (8) FS1/FS2 (Footswitch indicators) The indicator is on when FS1/FS2 is open, off when FS1/FS2 is latched. (9) INPUT Connects to Guitar. A plug (adapter) is shipped installed in this INPUT location, since there is now a guitar input on the side of the FX22. -
Page 8: Primary Functions
Primary Functions:... -
Page 9: Secondary Functions
Secondary Functions:... - Page 10 Restoring Factory Presets: Specifications Dimensions ..................480(L) x60(W)X52(H) mm Weight ..........................1000g Power Supply ..................DC9V (Negative Center) Current Drain ......................max. 350mA Signal Flow Chart...
-
Page 11: Operational Flow Chart
Operational Flow Chart... -
Page 12: Typical Setup Configuration Diagrams
Typical Setup Configuration Diagrams... -
Page 14: Glossary
Limited 1 Year Warranty This warranty covers any defects in your new Accel FX22 Power Supply. This is a 1 year warranty for the original registered purchaser. Accel will fix or replace any defective units within the first 1 years from the purchase date. Fixing or replacing the unit will be at Accels discretion.
