Product: Transponder Reader
Order Code: TR22A01KNX - TR22A11KNX
Application Program ETS: EEL_RDT1_10 Transponder Card Reader
Transponder Reader
TR22A01KNX
TR22A11KNX
Product Handbook
Pagina 1 di 24

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR22A01KNX and is the answer not in the manual?

Questions and answers

Summary of Contents for Eelectron TR22A01KNX

  • Page 1 Transponder Reader TR22A01KNX TR22A11KNX Product Handbook Product: Transponder Reader Order Code: TR22A01KNX - TR22A11KNX Application Program ETS: EEL_RDT1_10 Transponder Card Reader Pagina 1 di 24...
  • Page 2: Table Of Contents

    Index Pag. General Introduction......................3 Technical data ......................... 4 Wiring Diagram ........................5 Operating and display elements..................5 Dimension drawing....................... 5 Mounting and wiring hints....................6 Product and functional overview .................. 7 Parameters ..........................9 Parameter window “General Configurations”............9 Parameter Window “Relay 1 Configuration”...
  • Page 3: General Introduction

    As of year 2005, Eelectron applies to KNX association, fulfilling his requirements with the main goal of giving a contribution to the diffusion of the world’s only open Standard for home and building automation.
  • Page 4: Technical Data

    2. Technical data The Transponder Reader TR22A01KNX is an EIB/KNX wall Transponder Reader mounting device suitable to access control application. This device can be used in any kind of building (Hotel, Hospital, Offices, Parking, etc..) where the access control application is required.
  • Page 5: Wiring Diagram

    2.1 Wiring Diagram Bassa tensione max. 60 V ac/dc 2A Alimentazione 12/24 V ac/dc Out 1 Out 2 Input 2 Input 1 (11) Interfaccia BUS KNX / EIB 2.2 Operating and display elements Connections: 1 Power Supply 12/24 Vcc/ac Power Supply 12/24 Vcc/ac 3 OUT 1 terminal relay 1 (NO) 4 OUT2 terminal relay2 (NO) 5 COM Outputs...
  • Page 6: Mounting And Wiring Hints

    2.4 Mounting and wiring hints The device may be used for permanent indoor installations in dry locations within wall boxes. Requirements for installation The device must not be connected to 230V cables. • The prevailing safety rules must be heeded. •...
  • Page 7: Product And Functional Overview

    3. Product and functional overview The Transponder Reader - TR22A01KNX/TR22A11KNX is an EIB/KNX wall mounting device suitable to access control application. This device can be used in any kind of building (Hotel, Hospital, Offices, Parking, etc..) where the access control application is required.
  • Page 8 With this application program the followng functions can be parametrized and configured: Application Program: EEL_RDT1_10 Transponder Card Reader Max number of group addresses: 35 Max number of group address associations: 32 General Single or Multiple (max 4) user groups identification •...
  • Page 9: Parameters

    4. Parameters Parameter window “General Configurations” Fig. 1: Parameter Window “General Configurations” Access Send Mode • Options: Single Access Different Access Option “Single Access”: enables the 1 bit object (“Valid Access”) that is sent to the bus in case a valid access has been identified by the reader. With this option only one single group of users are managed in the range of passwords admitted.
  • Page 10 Grant Date Control • Options: Option “ON”: enables expiration date control during transponder card or key reading. Option “OFF”: disables expiration date control Grant Days Control • Options: Option “OFF”: the days of week allowed for entrance are not checked. Option “ON”: enables the days of week control.
  • Page 11: Parameter Window "Relay 1 Configuration

    4.2 Parameter Window “Relay 1 Configuration” The Relay 1 configuration parameters are shown in the next window: Fig. 2: Parameter Window “Relay1 Configuration” Function Options: General Purpose Door Open Option “General Purpose”: Relay 1 is controlled only by the “Relay 1” (1 bit) communication object as normal independent binary output channel.
  • Page 12 Mode Option: Normal Timing Option “Normal” : the Relay1 will be switched ON by sending an ON command and will be switched OFF by sending an OFF command within the associated object “Relay 1”. The status of the relay contact can be inverted by parameter setting “Contact”: Normally Close”.
  • Page 13 TimeBase Options: 250ms, 500ms, 1Sec, 1Min, 1Hour Factor Options: 0…10…255 Fig. 4: Timing Mode (e.g. for electrical lock pulse operating control). 13 di 24 Pagina...
  • Page 14: Parameter Window "Relay 2 Configuration

    4.3 Parameter Window “Relay 2 Configuration” Relay 2 differs from Relay 1 only for the first parameter setting “Function”. The Relay 2 configuration parameters are shown in the next window: Fig. 5: Parameter Window “Relay 2 Configuration” Function Opzioni: General Purpose Courtesy Light Option “General Purpose”: Relay 2 is controlled only by the “Relay 2”...
  • Page 15: Parameter Window "Input 1 Configuration

    4.4 Parameter Window “Input 1 Configuration” Parameters associated to Input1 channel are the same as ones associated to Input 2. Fig. 6: Parameter Window “Input 1 Configuration” Mode Options: Rising ON Rising OFF Falling ON Falling OFF Rising ON / Falling OFF Rising OFF / Falling ON Toggle ON/OFF Toggle OFF/ON...
  • Page 16 Behaviour: “Rising On”: A rising edge causes a logic “1” to be transferred to the communication object. A falling edge does not alter the object value. “Rising Off”: A rising edge causes a logic “0” to be transferred to the communication object.
  • Page 17 Fig. 7: Parameter Window “Input 1 Configuration” with Cyclic Send enabled (ON). Cycling Send Time (Min) Options: 1…10…255 The cyclic time for sending telegrams repeatedly on the bus with Input1 current value is specified here. The time units are minutes. Note: please see Inputs timing diagrams in “Appication Notes”.
  • Page 18: Communication Objects

    5 Communication Objects EIB/KNX communication objects provided within application program “EEL_RDT1_10 Transponder Card Reader” are shown next: Fig. 8: Communication Objects (some objects are visible if enabled by specific parameter setting). Function Name Type Flag On/Off Relay 1 / Door Unlock EIS1, 1bit C,R,W,T DPT 1.001...
  • Page 19 Funzione Nome Tipo Flag On/Off Relay2 / Courtesy Light EIS1, 1bit C,R,W,T DPT 1.001 This object is received from the bus to control the output relay 2. In case the “Courtesy Light” function is enabled this object is named “Courtesy Light” and controls the relay 2 to be switched ON/OFF.
  • Page 20 Funzione Nome Tipo Flag Set Plant ID Build Number EIS10, 2byte C,W,T DPT 7.001 The object “Build Number” is used to identify the installation or the building where the transponder readers are installed. This code avoid any possible risk of using the same card for entrance in two different buildings.
  • Page 21 Funzione Nome Tipo Flag 18, 19 ON/OFF/Toggle Input X EIS1, 1bit C,R,T DPT 1.001 Telegram Values “0” OFF “1” ON The switching telegrams of inputs 1 or 2 are sent via the group addresses associated to these objects. It is possible to select which signal edge detected at the input channels generate On or Off telegrams via the parameters of the corresponding inputs.
  • Page 22: Application Notes

    6 Application Notes Examples of timing diagrams for Inputs 22 di 24 Pagina...
  • Page 23 Examples of timing diagrams for Outputs 23 di 24 Pagina...
  • Page 24 LED4 green = “Room Service Call” or any other alarm; Any information inside this manual can be changed without advice. This handbook can be download freely from the website: www.eelectron.com Exclusion of liability: Despite checking that the contents of this document match the hardware and software, deviations cannot be completely excluded.
