Niles SCW-2 Installation & Operation Manual

Wall-mounted, volume control for speakers and headphones

Enlarged version

I N S T A L L A T I O N & O P E R A T I O N G U I D E

SCW-2

Wall-Mounted, Volume Control

for Speakers and Headphones

OFF

INTRODUCTION

The Niles SCW-2 is a wall-mounted stereo volume control for remote

speakers and headphones. The unit is ideal for both home and commer-

cial sound installations. A ten position rotary switch controls the volume

of the system. Use of an auto transformer instead of an L-Pad assures min-

imal internal power dissipation with virtually no power wasted as heat. A

front panel headphone jack and a speaker/headphone selector switch are

provided.

www.nilesaudio.com

Niles Audio Corporation

12331 S.W. 130 Street Miami, Florida, 33186 Tel: (305) 238-4373 Fax: (305) 238-0185

its products, Niles reserves the right to change product specifications without notice. Niles, the Niles logo

and Blending High Fidelity and Architecture are registered trademarks of Niles Audio Corporation.

Printed in USA 10/96 DS 00017 A

L E N D I N G

I G H

I D E L I T Y

A N D

R C H I T E C T U R E

Table of Contents

Do you have a question about the SCW-2 and is the answer not in the manual?

Page 1 © 1999 Niles Audio Corporation. All Rights Reserved. Note: Because Niles believes in constantly improving its products, Niles reserves the right to change product specifications without notice. Niles, the Niles logo and Blending High Fidelity and Architecture are registered trademarks of Niles Audio Corporation.
Page 2 Again, adjust the volume for a comfortable listening level. With the slide in the off (full left) position, neither speakers nor headphone are operative. NOTE: The SCW-2 is a common ground device. Do not attempt to use it with BLACK BLACK bridged amplifiers or other amplifiers that require separate left and right chan- nel ground returns.
