- Page 1 ACHILLES DIVERSITY RECEIVER MODULE USER MANUAL Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...
-
Page 2: Table Of Contents
Contents Features ..........................3 Specifications ........................3 Usage ........................... 4 Logo Screen ....................... 4 Screen Savers ......................4 Untra Search ......................4 Manual Search ......................5 Favorites ........................5 Event Mode ....................... 5 Band Scan ........................5 ... -
Page 3: Features
Features Built-in OSD Built-in Microphone Built-in Multi – directional Button Built-in Lap Timer, Event Mode, Model Find & Flip Screen Functions Integrated USB Port for Updates FW Easy to Read OLED Display Compatibility: ... -
Page 4: Usage
Usage Logo Screen When powering on the goggles, the OLED screen will display the Logo and the name of True-D. Screen Savers Show current Band, Channel number, frequency, temperature, battery, sign etc. Three Screen Savers that you can choose to display and exchange them by push button to left. -
Page 5: Manual Search
Manual Search Push button to Up/Down: scroll through the channels. Hold Mode button for about 2s, the pop-up will display: Save: save your desired channel Sort: search channel follow Band/Freq Exit: exit and search channel again ... -
Page 6: Model Find
Warning by buzzer when signal lower than the configured level. The options are as follows: OFF, 10%, 20% and 30%. Pilot Mic: Turn ON/OFF microphone on Achilles module. Flip Screen: Flip display of OLED Screen on Module. The options are as follows: ON/OFF... -
Page 7: Factory Reset
OSD: Turn ON/OFF OSD on goggles. OSD RES: Select video format to display on goggles. The options are as follows: PAL/NTSC. Factory Reset: Reset your settings to the original default when holding Mode button. Kerveros Give the best possible signal when you are using from a low quality VTx, bad antennas or on a bad environment. -
Page 8: Support
The reseller you purchased your product from handles the first line of support. If you encounter any problems with your Furious FPV products, please contact them first on issues involving equipment from other brands and general support for Furious FPV products.
