Summary of Contents for Furious FPV PIGGY OSD FOR KISS FC
- Page 1 PIGGY OSD FOR KISS FC USER MANUAL Please contact us if you need further assistance: Tech support: tech@furiousfpv.com Sales support: sales@furiousfpv.com Website: http://furiousfpv.com/...
-
Page 2: Specifications
Specifications: Item name: Piggy v2 Power input: 5V WxLxH : 23.5 x 23.5 x 2.5 mm Super light weight: 1.1 gr New chip use low power consumption and work better Compatible with all flight controllers that run KISS ... - Page 4 Diagram illustrates connections of Piggy V2 with KISS FC *Note: You need Piggy OSD for KISS FC version or you can flash firmware Piggy V2 BetaFlight to Kiss FC with FTDI Using VTX Tramp HV Using VTX TBS Unify Pro...
- Page 5 Using VTX FX FX799T...
- Page 6 How to set up Piggy OSD: - How to set up OSD with TX: To access the in-built OSD menu in MW-OSD, disarm your quadcopter first. THROTTLE MIDDLE YAW RIGHT PITCH FULL To navigate through menu in the OSD: ...
- Page 7 How to set up Piggy OSD via Furious FPV FTDI Furious FPV FTDI is compulsory in order to set up Piggy V2 Tool FTDI : https://goo.gl/Th6x25 Step 1: Download Furious FPV FTDI driver and MW-OSD software *Note: If you use Furious FPV FTDI, you can install the next steps Download: MW-OSD GUI R1.6...
- Page 8 Step 4: Same below picture...
- Page 9 Step 5: Right-click My Computer icon and select Manage. Connect FTDI tool to computer via USB and click Device Manager. In the Ports (COM & LPT) appearances Silicon Labs CP210x USB to UART Bridge then your installers completed successfully *Note: If your computer has not java application, You need to follow steps 6–10 for you connect to your computer Step 6: Download and run Java application.
- Page 11 How to set up OSD with MW OSD: Step 1: Connect Piggy V2 to the computer via FTDI tool *Note: Remove everything and only use piggy module when you connect to FTDI tool...
- Page 12 Step 2: Open the application MW_OSD_GUI Step 3: Choose the COM port on MWOSD R1.6 to connect your FTDI with the computer and wait until MWOSD load complete. You can turn on/off functions that you want to show on your goggles/display.
- Page 13 Step 4: Click Write to write your OSD configuration to Piggy V2 Flash firmware Piggy v2 Betaflight to KISS FC/Raceflight FC and vice versa. Firmware: https://goo.gl/pFhp8z Xloader: https://goo.gl/IKJveN After installing driver and running Xloader to flash firmware, connect FTDI tool with Piggy v2 as instructed and select as below: Step 1: Select Firmware on your computer Step 2: Select Duemilanove/Nano (ATmega328)
- Page 14 Thanks for using our product...
