SOUL CALIBUR ll

Game PCB Kit

Connections

and

Adjustments

Part No 90500138

Issue 1

Table of Contents

Need help?

Do you have a question about the SOUL CALIBUR II and is the answer not in the manual?

Questions and answers

Summary of Contents for NAMCO SOUL CALIBUR II

Page 1 SOUL CALIBUR ll Game PCB Kit Connections Adjustments Part No 90500138 Issue 1...
Page 2 Page 2...
Page 3 NOTICE is a term to describe a copyright protection technology created by Sony Group. This mark does not necessarily guarantee compatibily with other products bearing the “MagicGate” trademark. is a trademark of Sony Corporation. est une terme décrivant une technique de protection de copyright créée par Sony Group.
Page 4: Table Of Contents
Contents KIT CONTENTS ....................... 5 SPECIFICATIONS ....................7 CABINET CONNECTIONS (Standard Jamma) ............7 CABINET CONNECTIONS (JVS Standard) ............. 11 FITTING THE DONGLE & MEMORY CARD ............12 FITTING THE CD-ROM DISC .................. 13 ADJUSTMENTS AND SETTINGS ................15 Option Switches ......................15 Test Mode ........................16 6-2-1 Display Test ......................
Page 5: Kit Contents
KIT CONTENTS i r c y t i b i l t s i e l t b i l Page 5...
Page 6 SPECIFICATIONS COMPATIBILITY: JAMMA STANDARD (with JAMMA (B) PCB) JAMMA VIDEO STANDARD (JVS) PCB INPUT POWER: +5v (±5%) @ 7A (Min), +12v (±5%) @ 2A (Min) Temperature +5ºC to +45ºC OPERATING Humidity 10% to 85% (no condensation) ENVIRONMENT: MONITOR ORIENTATION Orientation Horizontal (Landscape) AND SIGNAL: Horizontal Frequency...
Page 7: Specifications
CABINET CONNECTIONS (Standard Jamma) Option Switches PCB Rack Assy CD-ROM Drive Video Cable Power Cable Audio Cable Data Cable Jamma (B) PCB Volume Control Page 7...
Page 8 The JAMMA (B) PCB is connected to the game cabinet with a 56way Edge Connector (standard JAMMA) and 4 and 10way AMP EI Connectors. JAMMA (B) PCB JAMMA 56way Connector 10way AMP EI Connector 4way AMP EI Connector Note: Supplied in the Kit is an Amp EI connector to 48way extender card adaptor loom for cabinets with an existing 48way connector, and an AMP EI connector with flying leads loom for cabinets without a 48way connection.
Page 9 Connections for Standard JAMMA Cabinet o i t ) - ( c t i c t i i t s i t s i t s i t s i t s i t s ) - ( i t s i t s Connector Loom c t i...
Page 10 Adaptor for Earlier Tekken Series Cabinets with 48way Edge Connector (Part No 69200067) r o t ) + ( r a l i z i r a l i z i t t u t t u Page 10...
Page 11: Cabinet Connections (Jvs Standard)
CABINET CONNECTIONS (JVS Standard) JVS Power Supply Adaptor Video Connector Audio Connectors Data I/O Connector Page 11...
Page 12: Fitting The Dongle & Memory Card
FITTING THE DONGLE & MEMORY CARD The dongle and memory card included in this kit is limited to this game only. DO NOT insert this Dongle in other games. Inserting the Dongle in other games may cause damage. Ensure that the power is switched OFF before inserting the Dongle. Dongle cover Pozi head screw (M3x10)
Page 13: Fitting The Cd-Rom Disc
FITTING THE CD-ROM DISC • The CD-ROM Disc must be inserted with the power switched on. To prevent an electric shock, accident or injury, do not touch any parts other than those specified below. • The supplied CD-ROM Disc is designed exclusively for this product. Never use the CD-ROM Disc in any other product.
Page 14 Place the CD-ROM Disc on to the tray, ensuring that the label side (printed surface) is facing away from the Tray. CD-ROM DISC Ensure that the CD-ROM Disc is securely placed on the tray, with the label side facing away from the tray Tray Press the Eject button to retract the Tray in to the unit.
Page 15: Adjustments And Settings
ADJUSTMENTS AND SETTINGS The Game PC Board Assy is fitted with 4 Option Switches. Option Switches The JAMMA (B) PCB has the Volume Control fitted. JAMMA (B) PCB Volume Control Option Switches Switch 1 is used to change between Test Mode and Game Mode. ON: Test Mode OFF: Game Mode Switch 2 is used to set the output level of the video signal.
Page 16: Test Mode
Test Mode To enter Test Mode set the Test switch in the cabinet (if fitted) to ON, or if no Test switch is fitted to the cabinet, set Option switch 1 ON Note: The test mode is activated only when the cabinet Test switch or Option switch 1 is moved from OFF to ON.
Page 17 6-2-1 Display Test This test allows the following checks and adjustments to be made. Colour Edit Adjust contrast and brightness of each colour to match video output from the PCB to the Monitor. Note: This adjustment should only be made if the correct picture quality cannot be achieved by using the normal monitor adjustments.
Page 18: Colour Edit
6-2-2 Colour Edit Ensure that the Colour Edit Adjustment Box is showing. (Press P1 Button 3 if the Adjustment box is not displayed. Use the Joystick UP/DOWN to step to the required adjustment. (Contrast, Brightness (red), Brightness (green), Brightness (blue)). Use the Joystick LEFT/RIGHT to adjust the value.
Page 19: Interlace
6-2-4 Interlace Interlace Mode: This mode provides more detailed and smoother graphics than the non-interlaced mode. This is achieved by shifting the picture display a half line in the vertical direction every other frame scan, so doubling the vertical resolution without changing the horizontal/vertical frequency.
Page 20: Input Test (Switch Test)
6-2-5 Input Test (switch test) Select Input Test from the Main Test Menu. The following screen is displayed. P2 Start switch P1 Start switch INPUT TEST Start Start Service Service Service switch on the cabinet (if fitted) Down Down Left Left Right Right...
Page 21: Game Options
6-2-6 Game Options Select Game Options from the Main Test Menu. The following screen is displayed. G A M E O P T I O N S < D e f a u l t s i n G r e e n > >...
Page 22: Coin Options
6-2-7 Coin Options Select Coin Options from the Main Test Menu. The following screen is displayed. COIN OPTIONS Defaults in Green > Start cost : 1 COIN to START Continue cost : 1 COIN to CONTINUE Coin chute 1 mechanical value : 1coin count as 1 COIN Coin chute 2 mechanical value : 1coin count as 1 COIN...
Page 23: Sound Test
6-2-8 Sound Test Select Sound Test from the Main Test Menu. The following screen is displayed. SOUND TEST POSITION:off Displays which speaker is playing SPEAKER:stereo Displays monaural/stereo setting Check Sound : P1-Button 1 How to activate test sound Select SOUND mode : P1-Left / Right How to change stereo/monaural setting EXIT...
Page 24: S - (Bookkeeping)
6-2-10 A. D. S - (Bookkeeping) This screen is used to display bookkeeping data such as: Total Coins, Game Ratios and Playing Times etc. Select Bookkeeping from the Main Test Menu and press P1 Button 1 to display the information. Press P1 Start Button to return to the Main Test Menu screen.
Page 25 Page 25...
Page 26 Copies of Namco Game Manuals can be downloaded from our website: www.namco.co.uk They are located under Components Distribution For all Parts or Technical Support contact: Brent Electronic, Namco House, Units 5-8, Acton Park Estate, The Vale, London. W3 7QE www.brentelectronic.co.uk...
