Appendix B: Lower Robot Bottom View
50
Lower Robot - Bottom View
Front Transport Cart Eye Hooks
Front Caster Wheels
Motor Pully Set Screws
Allen wrench sizes
Super Motors= 1/8"
Standard Motors- 3/32"
Motor Pully
Drive Belt
Wheel Pully
Rear Caster Wheels
Rear Transport Cart Eye Hooks
