MAXIMATOR GPLV 2 Assembly Instructions Manual page 17

Designation
SPLV 3
MPLV 4
GPLV 5
Air Amplifiers
Figure
Revision 11.2011
Technical Description
Brief characteristics
K Output capacity 230 I
at 6 bars primary pressure and
15 bars operating pressure
K Operating time 50%
K Selective pressure increase
upstream of an individual
consumer.
K Once final pressure has been
reached - no energy
consumption.
K Output capacity 50 I
at 6 bars primary pressure and
16 bars operating pressure
K Operating time 50%
K Selective pressure increase
upstream of an individual
consumer.
K Once final pressure has been
reached - no energy
consumption.
K Output capacity 360 I
at 8 bars primary pressure and
30 bars operating pressure
K Operating time 50%
K Selective pressure increase
upstream of an individual
consumer.
K Once final pressure has been
reached - no energy
consumption.
/min
N
/min
N
/min
N
13
