INSTALLING THE NETRONIX™ THIAMIS™ 1000
GSM/GPS COMMUNICATION MODEM IN
This guide will help you quickly install the Netronix™
Thiamis™ 1000 GSM/GPS Communication Modem into
the Environmental Enclosure Model 8535.
Unpacking Netronix Thiamis
GSM/GPS Communication
Modem (801901)
1. Unpack the Netronix Thiamis GSM/GPS
Communication Modem (801901) for the
Environmental Enclosure (8535) and verify that all
the items listed in the following table are present.
2. Contact
TSI
immediately if items are missing
or broken.
Qty.
Item Description
1
Adapter Plate
4
4-40 x 5/16" LG Pan Head
Screws
1
Power Cable
1
Spare Fuse
6-32 x 3/16" LG Pan
2
Head Screws
_______________
TSI and TSI logo are registered trademarks of TSI Incorporated. DustTrak is a trademark of TSI Incorporated.
Netronix and Thiamis are trademarks of Netronix Inc. Digi and XStream are trademarks of Digi International.
THE ENVIRONMENTAL ENCLOSURE
Reference Picture
INSTALLATION GUIDE
Qty.
Item Description
1
Netronix Thiamis GSM/GPS
Communication Modem
1
RS232 to USB Converter
Cable
1
Netronix Environet Quick
Start Guide
1
Environet Account Creation
Form
1
GSM/GPS Antenna
(not used)
MODEL 8535
Reference Picture
