ScorpionTrack 5
ST55 Installation Guide
.
Scorpion Automotive Ltd
Drumhead Road, Chorley North Business Park, Chorley, Lancashire, PR6 7DE, UK.
t: +44 (0)1257 249928 f. +44 (0)1257 249 938
w. www.scorpionauto.com
ScorpionTrack 5 (ST55) can only be installed by
Scorpion trained and approved installers who have
attended a Scorpion Category 5 training course
w. www.scorpiontrack.com
Advertisement
Table of Contents
Related Manuals for SCORPION ST55
Summary of Contents for SCORPION ST55
- Page 1 ScorpionTrack 5 ST55 Installation Guide ScorpionTrack 5 (ST55) can only be installed by Scorpion trained and approved installers who have attended a Scorpion Category 5 training course Scorpion Automotive Ltd Drumhead Road, Chorley North Business Park, Chorley, Lancashire, PR6 7DE, UK.
- Page 2 ScorpionTrack 5 Thatcham Category 5 Stolen Vehicle Tracking System Please Note. The ST55 must be installed to Thatcham TRI guidelines. The ST55 is recognised by the insurance industry under Thatcham Certificate number TQA422. Prior to installation of the ScorpionTrack 5 unit it is imperative that the product, customer and vehicle registration have been completed on-line.
- Page 3 Driver Cards Before installing the ScorpionTrack 5 unit, please ensure that the installer has both driver cards and that both are fully charged (the cards will arrive fully charged but will run down over time). To check that the cards are fully charged place each one into the charging dock which can be powered up using either the power adaptor supplied with the kit or with any 5 volt micro-USB lead.
-
Page 4: Installation Guidelines
Installation Guidelines 1. Unit Install Wherever possible please avoid fitting the ScorpionTrack 5 unit near to vehicle ECU’s or radio receivers and amplifiers. Make sure that the unit is not shielded by metal or carbon fibre when installed as this will affect the range of the built in Radio Frequency antenna for the driver cards. - Page 5 4. Permanent 12v or 24v power supply (+30) Red Wire Connect the permanent power supply to either 12 or 24 volt using the in-line 5 amp link fuse (supplied) using soldered or approved crimp connections. It is also important to check that the supply is a constant feed and does not time out due to on board vehicle power management.
- Page 6 6. Crank Inhibit (Immobilisation) Black/Blue wires (2 wires) The starter circuit is the ONLY circuit that Thatcham permit an installer to cut. The cut must only prevent the vehicle from starting and must not prevent it from running. Under no circumstances must any other cut be made including ignition, fuel or any other engine run cut.
- Page 7 If interference is an issue then try one of the following in order to establish the root cause of the problem: Move the position of the ST55 unit Move the position of the earth connection...
- Page 8 card is allocated a number and this number will be reflected in the text and will be on a sticker on the card. Driver card not found. The text will display the unique card number that has not been recognised. There could be a number of reasons for this: The card is not present.
- Page 9 Text examples of a normal installation process: 1. Once set up on-line, the installer will received this text Vehicle CK66UDL is now ready for fitting with the Scorpion Track unit 3611023643 2. Once installed and powered up, the installer will receive this text CK66UDL Installed! Lat: 55.8257...
- Page 10 Vehicle CK66UDL Keys: 011489D6 paired battery ok, 011489E1 paired battery low. If the installer receives a text stating that one or both driver card batteries are low, they will need to charge the card/s. This will take around 30 minutes to charge from fully flat.
-
Page 11: Troubleshooting Guide
11. Troubleshooting Guide Issue Things to Check… Contact Tracking Support on 01257 249928 option No LED on unit Ensure ignition is on and GPS antenna has clear If LEDs are flashing but no sight-of-sky. text received. Cover the green LED and count the flashes on the red LED –...
