Operating instructions
Fieldbus interface PFA
Module subrack BGT
Contents
Fieldbus interface PFA
Module subrack BGT . . . . . . . . . . . . . . . . . . . . . . . . .
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking the usage . . . . . . . . . . . . . . . . . . . . . . . . . 
Installing the BGT. . . . . . . . . . . . . . . . . . . . . . . . . . . 
Wiring the BGT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Setting the PFA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Installing the PFA . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Replacing the PFA . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Labelling the PFA . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Manual operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Faults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Logistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
BGT SA-8U/DP connection diagram . . . . . . . . . 0
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
E
DK
S
N
P
GR
www.docuthek.com
Safety
Please read and keep in a safe place
Please read through these instructions carefully
before installing or operating. Following the installation,
pass the instructions on to the operator. This unit must
be installed and commissioned in accordance with the
regulations and standards in force. These instructions can
also be found at www.docuthek.com.
Explanation of symbols
• ,  ,  ,  ... = Action
= Instruction
Liability
We will not be held liable for damage resulting from non-
observance of the instructions and non-compliant use.
Safety instructions
Information that is relevant for safety is indicated in the
instructions as follows:
DANGER
Indicates potentially fatal situations.
WARNING
Indicates possible danger to life and limb.
CAUTION
Indicates possible material damage.
All interventions may only be carried out by qualified gas
technicians. Electrical interventions may only be carried
out by qualified electricians.
Conversion, spare parts
All technical changes are prohibited. Only use OEM spare
parts.
Changes to edition 06.
The following chapters have been changed:
-
BGT SA-9U/1DP connection diagram
-
Certification
GB-1
