Summary of Contents for JBSystem Battle4-USB
-
Page 3: Safety Instructions
To protect the environment, please try to recycle the packing material as much as possible. Check the contents: Check that the carton contains the following items: BATTLE4-usb Mixer Power Cable Operating instructions SAFETY INSTRUCTIONS: CAUTION: To reduce the risk of electric shock, do not remove the top CAUTION cover. - Page 4 In this manual we talk about “line inputs”. This is a global name for inputs with a level up to 2V. This includes tuners, videos, CD-players, etc. Both USB connections will be detected as a sound card on your computer. These connections are bidirectional (play/record music simultaneously) JB SYSTEMS BATTLE4-usb...
-
Page 5: Controls And Functions
Leds VU meter should never be continuously on. This means your signal will be distorted, what can damage your sound system ! 15. [POWER] LED: this LED will be lit when the power of the unit is switched on. JB SYSTEMS BATTLE4-usb... - Page 6 CD, phono, etc. At the same time you can record your mix on your computer with the same USB connection! 35. PHONO/USB SWITCH: This switches make it possible to select the Phono input or the USB input for channel 2 and/or for channel 3. JB SYSTEMS BATTLE4-usb...
-
Page 7: Specifications
+12dB / -26dB Dimensions: 237(W) x 315(D) x 105(H) mm (buttons included) Weight: 3,3 kg The information is subject to change without prior notice You can download the latest version of this user manual on our website: www.jb-systems.eu JB SYSTEMS BATTLE4-usb...
