- Page 1 VELOCITY POWER 11500 Enjoy it. Operating and Installation Instruction...
-
Page 2: Installation And Connection Instructions
Disclaimer • In no event shall Blaupunkt be liable for any direct, indirect, punitive, incidental, special consequential damages, to property or life, improper storage, whatsoever arising out of or connected with the use or misuse of our products. -
Page 3: Specification
MPA 480 FUNCTION CONTROLLING DIAGRAM LINE INPUT CH 3/CH 4 CH 1 CH 3 PROTECT BASS EQ LOW PASS HIGH PASS GAIN CH MODE X-OVER LOW/BP FULL HIGH 12dB 30Hz 150Hz 10Hz 4KHz 0.2V POWER CH 2 CH 4 CH 1/CH 2... -
Page 4: Speaker Connection
MPA 480 WIRING DIAGRAM Speaker Connection Batter y 2 ~ 4 ohms 2 ~ 4 ohms 2 ~ 4 ohms 2 ~ 4 ohms CH 1 CH 2 CH 3 CH 4 FUSE GROUND +12V Speaker & Subwoofer Bridged Connection... - Page 5 MPA 680 FUNCTION CONTROLLING & WIRING DIAGRAM REMOTE LINE INPUT CH 5/CH 6 PROTECT CH 1 CH 3 CH 5 X-OVER BASS EQ LOW PASS HIGH PASS GAIN FULL LOW /BP POWER 12dB 30Hz 250Hz 10Hz 4KHz 0.2V HIGH CH 3/CH 4 CH 1/CH 2 HIGH PASS GAIN...
- Page 6 MPA 680 WIRING DIAGRAM Speaker Connection 2 ~ 4 ohms 2 ~ 4 ohms 2 ~ 4 ohms 2 ~ 4 ohms 2 ~ 4 ohms 2 ~ 4 ohms Batter y CH 6 CH 5 CH 4 CH 3 CH 2 CH 1 GROUND...
- Page 7 MPA 11500 FUNCTION CONTROLLING & WIRING DIAGRAM LINE INPUT REMOTE PROTECT BASS BOOST SUB SONIC LOW PASS GAIN MODE MASTER OUTPUT SLAVE MASTER INPUT OUTPUT 12dB 15Hz 55Hz 30Hz 250Hz POWER SLAVE INPUT SUBWOOFER GROUND +12V FUSE SPECIFICATION Power • Voltage Supply 14.4V •...
- Page 8 MPA 11500 WIRING DIAGRAM Speaker Connection Batter y SUBWOOFER GROUND +12V FUSE...
- Page 9 PARALLEL WIRING DIAGRAM SET MASTER OUTPUT REMOTE LINE INPUT PROTECT BASS BOOST SUB SONIC LOW PASS GAIN MODE MASTER OUTPUT SLAVE MASTER INPUT OUTPUT 12dB 15Hz 55Hz 30Hz 250Hz POWER SLAVE INPUT SUBWOOFER GROUND +12V FUSE SET SLAVE INPUT LINE INPUT REMOTE PROTECT BASS...
- Page 10 MPA AMPLIFIER STANDARD WIRING DIAGRAM CH 3/CH 4 LINE INPUT CH 1 CH 3 PROTECT BASS EQ LOW PASS HIGH PASS GAIN X-OVER CH MODE LOW/BP FULL 12dB 30Hz 150Hz HIGH 10Hz 4KHz 0.2V POWER CH 2 CH 4 CH 1/CH 2 X-OVER BASS EQ LOW PASS...
- Page 11 Examine if your wiring diagram is correct by referring to Diagram 1 & Diagram 2 in case of device operation or performance failure. The following table indicate other possible problems and solutions. Refer an authorized Blaupunkt dealer if problem persist. Problem...
- Page 12 1 121 18 009 02 01 1 121 18 010 02 01 Designed and engineered by Blaupunkt Competence Center 1 121 18 011 02 01...
