3P Volume Filter VF12
Operating and assembly instructions
Item No. 1000950
Rainwater filter conforming to DIN 1986:
for roof areas up to 42,334 ft² with a rain intensity of 4"/hour. Filter
for installation into a pilot shaft (Ø 78" or Ø 98") The lamella units
with fine filter can be removed easily for cleaning Material:
Stainless steel
Advertisement
Related Manuals for 3P Technik VF12
Summary of Contents for 3P Technik VF12
- Page 1 3P Volume Filter VF12 Operating and assembly instructions Item No. 1000950 Rainwater filter conforming to DIN 1986: for roof areas up to 42,334 ft² with a rain intensity of 4”/hour. Filter for installation into a pilot shaft (Ø 78” or Ø 98”) The lamella units...
- Page 2 Please carefully read and follow the instructions for the assembly and handling of your rainwater filter, the 3P volume filter VF12. Contents: Technical data ...................... 02-03 Method of functioning and areas of use ................ 04 Assembly instructions – installation ................05 Installation instructions ....................
- Page 3 Technical data 3P Volume Filter VF12 Rainwater Inlet to Inlet to the supply sewer cistern 1 x 12” 1 x 12” 1 x 12” 30.7” 42.1” 30.7” 47.2” 23.6” 10.8” 34.6” Screen mesh size min. shaft Ø in mm 0,390 / 0,980...
- Page 4 4. Cleaned water flows into the cistern 5. Dirt is washed into the sewer Areas of use: 3P Volume Filter VF12 - installation...
-
Page 5: Assembly Instructions
Assembly instructions 3P Volume Filter VF12 - installation Installation It is recommended to have the filter installed in the factory. For installation in the shaft, we recommend pushing short sleeve pieces corresponding to the specified diameters from the outside through the hole into the appropriate filter connections. - Page 6 Assembly instructions 3P Volume Filter VF12 - installation Wastewater outlet: Base of drain pipe = shaft bottom 12” Outlet to the cistern: Base of outlet pipe = 8.26” 10” from shaft bottom 2 x rainwater inlet: Base of inlet = 31.89”...
- Page 7 High security due to bypass installation, hence larger roof areas can also be connected. Rainwater inlet Outlet into Cistern the sewer overflow Rainwater supply Outlet into the cistern Cleaning the filter Check the function of the volume filter VF12 regularly and clean it as required! Removal of the lamella unit:...
- Page 8 Obvious defects must be reported immediately, unrecognisable or concealed defects immediately upon their discovery, in both cases in writing. 3P Technik is liable for repairs and deliveries of new items to the same extent as for the original contractual item. In the case of delivery of new items the warranty period begins again from the start, but only to the extent of the new delivery.
