Summary of Contents for Promax CV-100
- Page 1 USER’S MANUAL 99 Washington Street Melrose, MA 02176 800.517.8431 TestEquipmentDepot.com OPTICAL TO RF ADAPTOR CV-100 - 0 MI1791 -...
- Page 2 SAFETY NOTES Read the instruction manual before using the equipment, mainly "SAFETY RULES" paragraph. The symbol on the equipment means "SEE USER’S MANUAL". In this manual may also appear as a Caution or Warning symbol. Warning and Caution statements may appear in this manual to avoid injury hazard or damage to this product or other property.
-
Page 3: Table Of Contents
¡Error! Marcador no definido. 3 OPERATING INSTRUCTION..........5 3.1 Description of the controls and elements ....5 3.2 Connecting with the FIELD METER......6 3.3 Practical applications........... 7 4 MAINTENANCE ..............9 4.1 Cleaning recommendations ......... 9 11/10 CV-100... -
Page 4: General Information
CV-100 1 GENERAL INFORMATION 1.1 Description The CV-100 is an optical to RF signal adaptor that allows TV Analysers and Satellite with optical links. This adaptor covers the full RF band for FI satellite, terrestrial and CATV. It includes a DC power output to provide power to the optical LNB of the satellite antenna. - Page 5 Temperature range: om 5 °C to 40 °C. Maximum relative humidity: 80% (up to 31° C), decreasing lineally up to 50% at 40° C. Mechanical features Dimensions 77 mm W x 85 mm H x 28 mm D. Weight 150 g. 11/10 - 2 - CV-100...
-
Page 6: Safety Rules
Any change on the equipment should be carried out by qualified personnel. Use for the signal inputs / outputs, specially when working with high levels, appropriate low radiation cables. Follow the cleaning instructions described in the Maintenance Paragraph. 11/10 - 3 - CV-100... - Page 7 Symbols related with safety: 11/10 - 4 - CV-100...
-
Page 8: Operating Instruction
1.- RF Output / Power Input. 2.- LNB Power Output. 3.- ON / OFF LED Instrument Indicator. 4.- Optical Fibre Input 5.- ON / OFF Switch HIGH: No Attenuator (ATT=0 dB). LOW: Attenuator (ATT=20 dB). OFF: Instrument stopped. 11/10 - 5 - CV-100... -
Page 9: Connecting With The Field Meter
3.2 Connecting with the FIELD METER. Figure 2.- 11/10 - 6 - CV-100... -
Page 10: Practical Applications
3.3 Practical applications. Connection between SATELLITE signal over FIBRE OPTIC to FIELD METER through CV-100 adaptor. Figure 3.- Connection between DIGITAL TERRESTRIAL signal over FIBRE OPTIC to FIELD METER through CV-100 adaptor. Figure 4.- 11/10 - 7 - CV-100... - Page 11 11/10 - 8 - CV-100...
-
Page 12: Maintenance
The cover should be cleaned by means of a light solution of detergent and water applied with a soft cloth. Dry thoroughly before using the system again. 4.2 Not replaceable fuses by user. F001: 2.5 A T 125 V 11/10 - 9 - CV-100...
