Installation, Operation and Maintenance Manual
Please read and save these instructions for future reference. Read carefully before attempting to assemble,
install, operate or maintain the product described. Protect yourself and others by observing all safety
information. Failure to comply with instructions could result in personal injury and/or property damage!
General Safety Information
Only qualified personnel should install this unit.
Personnel should have a clear understanding of these
instructions and should be aware of general safety
precautions. Improper installation can result in electric
shock, possible injury due to coming in contact with
moving parts, as well as other potential hazards.
Other considerations may be required if high winds
or seismic activity are present. If more information
is needed, contact a licensed professional engineer
before moving forward.
1. Follow all local electrical and safety codes, as well
as the National Electrical Code (NEC), the National
Fire Protection Agency (NFPA), where applicable.
2. The rotation of the propeller is critical. It must
be free to rotate without striking or rubbing any
stationary objects.
3. Motor must be securely and adequately grounded.
4. Do not spin fan propeller faster than the maximum
cataloged fan rpm. Adjustments to fan speed
with Variable Frequency Drives (VFD) may affect
motor load. If the fan RPM is changed, the motor
current should be checked to make sure it is not
exceeding the motor nameplate amps.
5. Do not allow the power cable to kink or come in
contact with oil, grease, hot surfaces or chemicals.
Replace cable immediately if damaged.
6. Verify that the power source is compatible with the
equipment.
DANGER
Always disconnect power before working on or near
a unit. Lock and tag the disconnect switch or breaker
to prevent accidental power up.
CAUTION
When servicing the unit, motor may be hot enough
to cause pain or injury. Allow motor to cool before
servicing.
CAUTION
Precaution should be taken in explosive
atmospheres.
Document 480189
Model GJ
Jet Fan
1
Advertisement
Table of Contents
Related Manuals for Greenheck GJ
Summary of Contents for Greenheck GJ
-
Page 1: General Safety Information
Document 480189 Model GJ ® Installation, Operation and Maintenance Manual Please read and save these instructions for future reference. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. -
Page 2: Handling And Lifting
INSPECTION MAINTENANCE DURING Fan model GJ is to be lifted using a minimum of four (4) STORAGE — points on the fan housing or attach two suitable chains/ While in storage, inspect fans once per month. Keep a straps around the entire fan housing, one near each duct record of inspection and maintenance performed. -
Page 3: Installation
Airflow Decals This is the label Propeller for a model Clearance Wheel Blade GJ-AU. Rotation Interior of tube Prop Cut Diameter for Std and High Temp Minimum Tip Minimum Tip Outer Inner Clearance for Clearance for... -
Page 4: Silencer Installation
Mounting Field Performance Adjustments The performance of a GJ fan can be adjusted The fan should be mounted either rigidly or through through the use of a Variable Frquency Drive (VFD) or the use of vibration isolators. If vibration isolators adjusting the fan pitch. -
Page 5: Maintenance
Maintenance Infrequent Use WARNING Infrequent use is defined as a fan that is used Disconnect and secure to the “Off” position all less than once per month or is used in emergency electrical power to the fan prior to inspection situations only. -
Page 6: Troubleshooting
Troubleshooting Problem Cause Corrective Action Propeller Rubbing Adjust motor plate. Tighten motor plate after centering Housing propeller in housing. Replace defective bearing(s). Lubricate bearings. Excessive Noise Bearings Tighten collars and fasteners. Clean all dirt off propeller. Check propeller balance, Propeller Unbalance rebalance in-place if necessary. -
Page 7: Maintenance Log
Maintenance Log Date _________________ Time______________ AM/PM Date _________________ Time______________ AM/PM Notes: __________________________________________ Notes: __________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ Date _________________ Time______________ AM/PM Date _________________ Time______________ AM/PM Notes: __________________________________________ Notes: __________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ Date _________________ Time______________ AM/PM... -
Page 8: Our Commitment
Our Commitment As a result of our commitment to continuous improvement, Greenheck reserves the right to change specifications without notice. Specific Greenheck product warranties are located on greenheck.com within the product area tabs and in the Library under Warranties. ®...
