GB
Transmitter programming procedure
1.
After 3 seconds, the roller shutter will begin to move downwards
as it is being programmed.
1.
When the required intermediate position has been
reached, keep the STOP button depressed and, if
necessary, correct the position with the UP or DOWN
button. Release the STOP button when the exact
position has been reached.
The intermediate position will now be saved in the receiver.

2.2) Setting the ventilation position from the lower end limit

To set the ventilation position, move the roller shutters
to the lower end limit.
1.
After 3 seconds, the roller shutter will begin to move downwards
as it is being programmed.
1.
When the required ventilation position has been
reached, keep the STOP button depressed and, if
necessary, correct the position with the UP or DOWN
button. Release the STOP button when the exact
position has been reached.
The ventilation position will now be saved in the receiver.
Note: When using a SELVE-radio-drive as a receiver only the
intermediate position can be programmed.
2.
Next, press the STOP button
> 3 sec.
and then the DOWN button as
well, and keep them both
depressed.
2.
> 3 sec.
Next, press the STOP button
and then the UP button as well,
and keep them both depressed.
