- Page 1 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij MC60-TE-A Kit User Guide GSM/GPRS/GNSS Module Series Rev. MC60-TE-A_Kit_User_Guide_V1.0 Date: 2016-07-22 www.quectel.com...
- Page 2 QUECTEL OFFERS THE INFORMATION AS A SERVICE TO ITS CUSTOMERS. THE INFORMATION PROVIDED IS BASED UPON CUSTOMERS’ REQUIREMENTS. QUECTEL MAKES EVERY EFFORT TO ENSURE THE QUALITY OF THE INFORMATION IT MAKES AVAILABLE. QUECTEL DOES NOT MAKE ANY WARRANTY AS TO THE INFORMATION CONTAINED HEREIN, AND DOES NOT ACCEPT ANY LIABILITY FOR ANY INJURY, LOSS OR DAMAGE OF ANY KIND INCURRED BY USE OF OR RELIANCE UPON THE INFORMATION.
-
Page 3: About The Document
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide About the Document History Revision Date Author Description 2016-07-22 Tiger CHENG Initial MC60-TE-A_Kit_User_Guide Confidential / Released 2 / 23... -
Page 4: Table Of Contents
Figure Index ..............................5 Introduction ............................6 1.1. Safety Information ........................6 Product Concept ..........................8 2.1. MC60-TE-A Top and Bottom View................... 8 Interface Application of MC60-TE-A ....................10 3.1. SIM2 Card Interface ......................10 3.2. Test Points ..........................11 MC60-TE-A Accessories Assembly .................... - Page 5 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Table Index TABLE 1: PINS OF SIM2 CARD INTERFACE................... 10 TABLE 2: PINS OF TEST-POINT .......................11 TABLE 3: PIN DEFINITION OF THE 60-PIN DIP CONNECTOR.............. 21 TABLE 4: RELATED DOCUMENTS ......................
- Page 6 FIGURE 3: SIM2 CARD INTERFACE ......................10 FIGURE 4: TEST POINTS ..........................11 FIGURE 5: MC60-TE-A TOOLKIT ACCESSORIES .................. 13 FIGURE 6: CONNECTION BETWEEN MC60-TE-A AND GNSS/GSM ANTENNA ........14 FIGURE 7: S101/S102 SWITCH STATUS ....................15 FIGURE 8: J107 SHORT CIRCUIT CONNECTION .................. 16 FIGURE 9: POWERGPS TOOL .........................
-
Page 7: Introduction
MC60-TE-A interface specifications, electrical and mechanical details and know how to use it. MC60-TE-A kit is intended to be used in combination with GSM EVB kit for MC60 module testing and evaluation. For detailed description of GSM EVB, please refer to document [6]. - Page 8 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Cellular terminals or mobiles operating over radio frequency signal and cellular network cannot be guaranteed to connect in all conditions, for example no mobile fee or with an invalid SIM card. While you are in this condition and need emergent help, please remember using emergency call.
-
Page 9: Product Concept
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Product Concept 2.1. MC60-TE-A Top and Bottom View Figure 1: MC60-TE-A Top View MC60-TE-A_Kit_User_Guide Confidential / Released 8 / 23... - Page 10 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Figure 2: MC60-TE-A Bottom View A: Serial selector switch B: GSM antenna interface C: GNSS antenna interface D: BT antenna interface E: LED indicator F: SIM2 card interface...
-
Page 11: Interface Application Of Mc60-Te-A
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Interface Application of MC60-TE-A 3.1. SIM2 Card Interface Figure 3: SIM2 Card Interface Table 1: Pins of SIM2 Card Interface Signal Description Connect to Ground Not connected... -
Page 12: Test Points
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide SIM_RST SIM card reset Ground SIM_VDD Power supply for SIM card Ground Ground 3.2. Test Points Figure 4: Test Points Table 2: Pins of Test-point Signal... - Page 13 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide GNSS_TXD Transmit data PCM_IN/SPI_CLK Reserved PCM_CLK/SPI_CS Reserved GNSS_VCC_EN GNSS power enabled PCM_SYNC/SPI_MISO Reserved PCM_OUT/SPI_MOSI General purpose input/output port GNSS_RXD Receive data I2C_SCL28 Reserved I2C_SDA28 Reserved MC60-TE-A_Kit_User_Guide...
-
Page 14: Mc60-Te-A Accessories Assembly
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide MC60-TE-A Kit Accessories Assembly Figure 5: MC60-TE-A Toolkit Accessories A: GNSS Antenna B: CD C: GNSS Antenna Patch Lead MC60-TE-A_Kit_User_Guide Confidential / Released 13 / 23... -
Page 15: Illustration
MC60-TE-A Kit User Guide Illustration MC60-TE-A kit is intended to be used in combination with GSM EVB kit for MC60 module testing and evaluation. The connection between MC60-TE-A and GNSS/GSM antenna can refer to the following figure. Figure 6: Connection between MC60-TE-A and GNSS/GSM Antenna 5.1. -
Page 16: Communicate With Gsm Part Of Module
(1) If the main UART is used for communication with MC60’s GSM part, please turn the Switch S101 and S102 to ON state on MC60-TE-A, and then connect the main UART of EVB to PC’s USB port with the USB to UART converter cable. This is the recommended method. Switch status description is available in the above figure. -
Page 17: Communicate With Gnss Part Of Module
5.3.1. Use Main UART (1) Turn the Switch S101 and S102 to ON state on MC60-TE-A, and then connect the main UART of EVB to PC’s USB port with the USB to UART converter cable. This is the recommended method. -
Page 18: Firmware Upgrade Through The Main Uart Port
(4) Insert the plug of the 5V power adapter. Turn the Switch S202 to ON state on the EVB. The LED D503 on the EVB and the LED D102 on MC60-TE-A will be lighted, and NMEA data will be output. -
Page 19: Compatible Design And Applications
Figure 10: Using a Passive Antenna When testing the BT function, the built-in Bluetooth antenna of MC60-TE-A is recommended to be used. In this case, Resistor R108 (0 ohm, 0402 package) is mounted, while Resistor R104 (0 ohm, 0402 package) is not mounted. - Page 20 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Figure 11: Using the Built-in Bluetooth Antenna Figure 12: Using an External Bluetooth Antenna MC60-TE-A_Kit_User_Guide Confidential / Released 19 / 23...
-
Page 21: 60-Pin Assignment
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide 60-pin Assignment Figure 13: DIP Connector of MC60-TE-A MC60-TE-A_Kit_User_Guide Confidential / Released 20 / 23... - Page 22 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Table 3: Pin Definition of the 60-pin DIP Connector Pin NO. Pin Name Pin NO. Pin Name VBAT VBAT VBAT VBAT VBAT ADC0 VRTC VDD_EXT NETLIGHT...
- Page 23 Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide SPK1P MICP SPK1N MICN SPK2P MICP MICN MC60-TE-A_Kit_User_Guide Confidential / Released 22 / 23...
-
Page 24: Appendix A References
Produkt dostpny w sklepie www.Soyter.pl <--- kliknij GSM/GPRS/GNSS Module Series MC60-TE-A Kit User Guide Appendix A References Table 4: Related Documents Document Name Remark Quectel_MC60_AT_Commands_Manual AT commands manual Quectel_GSM_UART_Application_Note Serial port application note Quectel_MC60_Hareware_Design Hardware design Quectel_GSM_FW_UPGRADE_AN01 Firmware upgrade application note...
