- Page 1 CP6925 CPCI 16 Channel Gigabit Ethernet Switch 6U Board, PICMG 2.16 Doc.ID: 35008, Rev. 1.0 November 27, 2006 User Guide...
-
Page 2: Imprint
Disclaimer Copyright © 2006 Kontron AG. All rights reserved. All data is for information purposes only and not guaranteed for legal purposes. Information has been carefully checked and is believed to be accurate; however, no responsibility is assumed for inaccuracies. Kontron and the Kontron logo and all other trademarks or registered trademarks are the property of their respective owners and are recognized. -
Page 3: Table Of Contents
CUSTOMER SPECIFIC CP6925 Preface Table of Contents Revision History ......................ii Imprint ........................ii Disclaimer ........................ii Table of Contents ...................... iii List of Tables ......................v List of Figures ......................vii Proprietary Note ......................ix Trademarks .......................ix Environmental Protection Statement .................ix Explanation of Symbols .....................x For Your Safety ......................xi... - Page 4 Ethernet Operational Status LEDs ..........2 - 9 2.4 Power Supply ..................2 - 10 Installation ................3 - 3 3.1 Safety Requirements ................3 - 3 3.2 CP6925 Installation Procedures ..............3 - 4 3.3 Standard Removal Procedures ..............3 - 5 3.4 Software Installation ................3 - 5 Page iv...
-
Page 5: List Of Tables
CUSTOMER SPECIFIC CP6925 Preface List of Tables System Relevant Information ..............1 - 5 Main Specifications ................1 - 10 Applied Standards .................. 1 - 11 Related Publications ................1 - 11 CompactPCI Bus Connector J1 Pinout ............ 2 - 6 CompactPCI Bus Connector J3 Pinout ............ - Page 6 CUSTOMER SPECIFIC Preface CP6925 This page has been intentionally left blank. Page vi Doc.ID: 35008, Rev 1.0...
-
Page 7: List Of Figures
CUSTOMER SPECIFIC CP6925 Preface List of Figures CP6925 Application System Interfacing Diagram ........1 - 6 CP6925 System Level Interfacing Diagram ..........1 - 7 CP6925 Front Panel ................1 - 8 CP6925 Board Layout (Top View) ............1 - 9 CP6925 Board Level Interfacing .............. - Page 8 CUSTOMER SPECIFIC Preface CP6925 This page has been intentionally left blank. Page viii Doc.ID: 35008, Rev 1.0...
-
Page 9: Proprietary Note
Kontron reserves the right to change, modify, or improve this document or the product de- scribed herein, as seen fit by Kontron without further notice. -
Page 10: Explanation Of Symbols
CUSTOMER SPECIFIC Preface CP6925 Explanation of Symbols Caution, Electric Shock! This symbol and title warn of hazards due to electrical shocks (> 60V) when touching products or parts of them. Failure to observe the pre- cautions indicated and/or prescribed by the law may endanger your life/health and/or result in damage to your material. -
Page 11: For Your Safety
However, the life expectancy of your product can be drastically reduced by improper treatment during unpacking and installation. Therefore, in the interest of your own safety and of the correct operation of your new Kontron product, you are requested to conform with the following guidelines. -
Page 12: General Instructions On Usage
CP6925 General Instructions on Usage In order to maintain Kontron’s product warranty, this product must not be altered or modified in any way. Changes or modifications to the device, which are not explicitly approved by Kontron and described in this manual or received from Kontron’s Technical Support as a special han- dling instruction, will void your warranty. -
Page 13: Two Year Warranty
As a result, the products are sold “as is,” and the responsibility to ensure their suitability for any given task remains that of the purchaser. In no event will Kontron be liable for direct, indirect or consequential damages resulting from the use of our hardware or software products, or documentation, even if Kontron were advised of the possibility of such claims prior to the pur- chase of the product or during any period since the date of its purchase. - Page 14 CUSTOMER SPECIFIC Preface CP6925 This page has been intentionally left blank. Page xiv Doc.ID: 35008, Rev 1.0...
-
Page 15: Introduction
CUSTOMER SPECIFIC CP6925 Introduction Chapter Introduction Doc.ID: 35008, Rev 1.0 Page 1 - 1... - Page 16 CUSTOMER SPECIFIC Introduction CP6925 This page has been intentionally left blank. Page 1 - 2 Doc.ID: 35008, Rev 1.0...
-
Page 17: System Overview
• Information on the distinctive features of Kontron CompactPCI boards, such as function- ality, hot swap capability. In addition, an overview is given for all existing Kontron Com- pactPCI boards with links to the relating data sheets. -
Page 18: Board Overview
RJ45 connector at the front panel. It supports 10, 100, and 1000 Mbit/s data transfer rates. The purpose of the CP6925 is to connect up to 14 Gigabit Ethernet nodes on the backplane using the J3 and J5 connectors. In addition, two Gigabit Ethernet uplink channels are provided on the J6A/B connectors. -
Page 19: System Relevant Information
System Relevant Information SUBJECT INFORMATION System Configuration The CP6925 may be used in any CompactPCI PICMG 2.16 PSB system. Board Location in the System The CP6925 board may only be installed in a fabric slot. Hot Swap Compatibility The CP6925 is not Hot Swap capable. -
Page 20: Application System Interfacing
CUSTOMER SPECIFIC Introduction CP6925 1.4.1 Application System Interfacing Figure 1-1: CP6925 Application System Interfacing Diagram Application System (AS) CompactPCI PSB System CP6925 CP6925 NODES NODES Processes Processes Page 1 - 6 Doc.ID: 35008, Rev 1.0... -
Page 21: System Level Interfacing
CUSTOMER SPECIFIC CP6925 Introduction 1.4.2 System Level Interfacing Figure 1-2: CP6925 System Level Interfacing Diagram CompactPCI PSB System CompactPCI PSB System CP6925 LP01...08 LP09...14 GIGABIT ETHERNET SWITCH LP01...08 LP09...14 J6A/B J3 and J5 provide fabric interfacing to the PSB for the BP nodes... -
Page 22: Front Panel
CUSTOMER SPECIFIC Introduction CP6925 1.4.3 Front Panel Figure 1-3: CP6925 Front Panel LEGEND FOR THE LEDS: COLOR FUNCTION Activity green Blinks when activity takes place on the corresponding link: LP01 to LP14, channels 15 and 16 Speed LED off Link speed is 10 Mbits/s... -
Page 23: Board Layout
CUSTOMER SPECIFIC CP6925 Introduction 1.4.4 Board Layout Figure 1-4: CP6925 Board Layout (Top View) TXRX TXRX TXRX TXRX Doc.ID: 35008, Rev 1.0 Page 1 - 9... -
Page 24: Technical Specifications
CUSTOMER SPECIFIC Introduction CP6925 Technical Specifications Table 1-2: Main Specifications TYPE SPECIFICATIONS Controller Broadcom® BCM5396, 16-port Gigabit Ethernet Switch with integrated SerDes/ SGMII interfacing, operates in unmanaged mode, layer 2 Ethernet 14 channels of fabric three speed Ethernet: 10/100/1000 Mbit/s... -
Page 25: Applied Standards
CUSTOMER SPECIFIC CP6925 Introduction Applied Standards The Kontron Modular Computers’ CompactPCI module CP6925 complies with the require- ments of the following standards: Table 1-3: Applied Standards TYPE STANDARD Emission EN55022, EN61000-6-3 Immunity, Industrial Environment EN61000-6-2 Immunity, IT Equipment EN55024 Electrical Safety... - Page 26 CUSTOMER SPECIFIC Introduction CP6925 This page has been intentionally left blank. Page 1 - 12 Doc.ID: 35008, Rev 1.0...
-
Page 27: Functional Description
CUSTOMER SPECIFIC CP6925 Functional Description Chapter Functional Description Doc.ID: 35008, Rev 1.0 Page 2 - 1... - Page 28 CUSTOMER SPECIFIC Functional Description CP6925 This page has been intentionally left blank. Page 2 - 2 Doc.ID: 35008, Rev 1.0...
-
Page 29: General Information
General Information The CP6925 is designed as a 16 channel Gigabit Ethernet Switch board with interfacing for front panel connectors as well as supporting fabric interfacing on the J3 and J5 backplane con- nectors. -
Page 30: Cp6925 Board Level Interfacing
CUSTOMER SPECIFIC Functional Description CP6925 Figure 2-1: CP6925 Board Level Interfacing CP6925 LP09...14 LP01...08 POWER M AG GIGABIT ETHERNET SWITCH TXRX M AG M AG LP09...14 LP01...08 A J6 B Page 2 - 4 Doc.ID: 35008, Rev 1.0... -
Page 31: Interfaces
A proper mating is further assured by the use of color coded keys for 3.3 V and 5 V operation. In the case of the CP6925 there is no keying required as only power (3.3V or 5V) is provided to the CP6925 via J1. -
Page 32: Compactpci Bus Connector J1 Pinout
CUSTOMER SPECIFIC Functional Description CP6925 2.3.1.2 CompactPCI Connector J1 Table 2-1: CompactPCI Bus Connector J1 Pinout ROW Z ROW A ROW B ROW C ROW D ROW E ROW F 3.3V V(I/O) 3.3V 3.3V 3.3V V(I/O) 3.3V 3.3V 3.3V V(I/O) 3.3V... -
Page 33: Compactpci Bus Connector J3 Pinout
CUSTOMER SPECIFIC CP6925 Functional Description 2.3.1.3 CompactPCI Connector J3 Table 2-2: CompactPCI Bus Connector J3 Pinout ROW Z ROW A ROW B ROW C ROW D ROW E ROW F LP8_DA+ LP8_DA- LP8_DC+ LP8_DC- LP8_DB+ LP8_DB- LP8_DD+ LP8_DD- LP7_DA+ LP7_DA-... -
Page 34: Compactpci Bus Connector J5 Pinout
CUSTOMER SPECIFIC Functional Description CP6925 2.3.1.4 CompactPCI Connector J5 Table 2-3: CompactPCI Bus Connector J5 Pinout ROW Z ROW A ROW B ROW C ROW D ROW E ROW F LP14_DA+ LP14_DA- LP14_DC+ LP14_DC- LP14_DB+ LP14_DB- LP14_DD+ LP14_DD- LP13_DA+ LP13_DA-... -
Page 35: Gigabit Ethernet
Functional Description 2.3.2 Gigabit Ethernet Figure 2-3: Dual Gigabit Ethernet Connector J6A/B The CP6925 board includes two 10Base-T/100Base- TX/1000Base-T Ethernet ports. The Ethernet connectors are realized as RJ45 con- nectors. The interfaces provide automatic detection and switching between 10Base-T, 100Base-TX and 1000Base-T data transmission (Auto-Negotiation). -
Page 36: Power Supply
CP6925 Power Supply The CP6925 is designed to be able to generate its own 3.3V power from the 5V input power from the backplane. If required, 3.3V power, however, can be obtained from the backplane. This can be especially advantageous in systems where it is necessary to balance the power supply loading. -
Page 37: Installation
CUSTOMER SPECIFIC CP6925 Installation Chapter Installation Doc.ID: 35008, Rev 1.0 Page 3 - 1... - Page 38 CUSTOMER SPECIFIC Installation CP6925 This page has been intentionally left blank. Page 3 - 2 Doc.ID: 35008, Rev 1.0...
-
Page 39: Safety Requirements
Installation Installation The CP6925 has been designed for easy installation. However, the following standard precau- tions, installation procedures, and general information must be observed to ensure proper in- stallation and to preclude damage to the board, other system components, or injury to personnel. -
Page 40: Cp6925 Installation Procedures
5. Connect all external interfacing cables to the board as required. 6. Ensure that the board and all required interfacing cables are properly secured. The CP6925 is now ready for operation. For operation of the CP6925, refer to appropriate CP6925 specific software, application, and system documentation. -
Page 41: Standard Removal Procedures
Warning! Care must be taken when applying the procedures below to ensure that neither the CP6925 nor system boards are physically damaged by the application of these procedures. 2. Ensure that no power is applied to the system before proceeding. - Page 42 CUSTOMER SPECIFIC Installation CP6925 This page has been intentionally left blank. Page 3 - 6 Doc.ID: 35008, Rev 1.0...
