Summary of Contents for micro-trak SafeGuard ISOmod

  • Page 1 BLOCKAGE MONITOR Proudly built in the U.S.A. by:...
  • Page 2: Table Of Contents

    SafeGuard™ - Simple, Powerful, Trusted Protection. If you do encounter a problem that cannot be corrected by reviewing this manual, consult your dealer or distributor, or contact Micro-Trak® for assistance. Toll Free in U.S. or Canada: (800) 328-9613 or (507) 257-3600 Fax: 507-257-3001 www.micro-trak.com •...
  • Page 3: Overview

    Implement Switch. This circuit silences the audible alarm and also enables the review of recorded screen information. (See page 11) Micro-Trak makes an Implement Switch (P/N 18541) with an integral magnetic mount designed to easily connect to the ISOmod wiring harness.
  • Page 4: System Layout

    Wiring Harness P/N 19690 SafeGuard ISOmod™ ISOBUS Micro-Trak Tap Cables M/P 150 (Generic) - P/N 18894 Ampseal 16 (John Deere™) - P/N 18895 Delphi MP630 (Great Plains/Dickey-John™) - P/N 18896 Delphi GT280 (Case™) - P/N 18897 Deutsch™ DTM (in-cab) Kit - P/N 18944 (includes power cable) Deutsch™...
  • Page 5: Sensor Configuration & Numbering

    Sensor Configuration & Numbering The SafeGuard ISOmod system has 2 separate networks - labeled Net 1 & 2 on the harness; each has a separate left and right side. Dual networks simplify monitoring when applying 2 different products at the same time. On-screen configuration infor- mation references any network and side (L/R) that is connected at start-up.
  • Page 6: Isomod Installation

    ISOmod Installation Place the ISOmod™ enclosure in selected location, mark holes, drill, and secure with 1/4” fasteners (not included). Mounting holes are 4” apart on center. (See below) Connect ISOmod™ wiring harness to sensors. Sensors are numbered starting with farthest Left as #1 and continuing sequentially to the Right. The open connectors on the last sensors on all network branches must have a termination cap (included).
  • Page 7: Sensor Installation & Location

    Sensor Installation & Location Mount the sensors vertically with the outlet at the top. See sensor measurements on page 19 for hole spacing. Sensors must be mounted plumb for correct operation. Sensor leads are daisy-chained together directly or with the use of extension cables.
  • Page 8 Manifold style installation Sensors are joined together using u-clips, like standard visual ball monitors. The sensor with 3” leads would be used to minimize excess cabling between sensors. Liquid can be fed to sensor groups via cap and plug fittings, or a Tee fitting designed to link two sensors with a flow inlet.
  • Page 9: Implement Switch

    ISObus network. 12345 (example) - SafeGuard will only react to Implement Switch information originating from a Micro-Trak ISOmod. If that signal is available, a button with the last 5 digits of the ISOmod serial number will be visible.
  • Page 10: Isobus Connection

    Micro-Trak IBIC Cable - P/N 18921 Operation When the system is turned on, SafeGuard ISOmod searches for sensors installed on the data line. If the number of sensors it finds is different than the last power-up, it will notify the user with an on-screen message.
  • Page 11: On Screen Display

    On Screen Display The SafeGuard ISOmod is designed to integrate into serial networks that use ISOBUS standards - ISO 11783. The appearance of the on-screen display will vary depending on the brand of Virtual Terminal that is used. The system is also designed to run along side, and in the background, with other programs on the VT.
  • Page 12: On Screen Navigation

    HOME screen. Note: Section Setup is only available when SafeGuard is configured for Section Control and a Micro-Trak Dual ISOmod Rate Controller is also connected to the ISOBUS network. SECTION SETUP ENABLE/DISABLE CH.
  • Page 13: Home Screen

    Home Screen Home Screen for system. System is actively monitoring for blockages. To About Screen To Message Help Screen To Configuration Screen Network #1 Name Volume Increase Volume Decrease & Run/Hold Status Network #2 Name Record Current Screen About Screen Displays system information.
  • Page 14: Configuration Screen

    To Channel 2 Setup Section Control If a Micro-Trak Dual ISOmod is also connected to the ISOBUS network, SafeGuard sensors can be grouped and assigned to respond to Section Control messages. This means that as sections are individually controlled on the Dual ISOmod, SafeGuard will selectively turn off sensors to prevent false alarm readings.
  • Page 15 Section Control cont. Assign sensors to available sections. Sensors are assigned in ascending numerical order - refer to page 5 for numbering schemes. In the example shown, Sensor 1 is assigned to Section 1, Sensor 2 is assigned to Section 2, Sensors 3 & 4 are assigned to Section 3, and so on.
  • Page 16: Channel Setup

    Channel Setup Screen (Channel 1 shown.) To Home Screen To Configuration Screen Channel Name To Channel 2 Setup Section Control See Page 14 To Channel 1 Sensor Total Sections Enable/Disable See Page 14 Sensor Enable/Disable Screen Sensor Enable/Disable - Press icon to toggle. System is NOT actively monitoring for blockages.
  • Page 17: Diagnostic Screen

    Diagnostic Screen To Home Screen To Configuration Screen Disconnect Note: Information shown here is an example only. Your SafeGuard ISOmod will have specific identity information. Disconnect: This softkey will disconnect the SafeGuard from the ISObus, effectively turning it off. Message Help Screen...
  • Page 18: Troubleshooting

    Troubleshooting Sensors Not Detected Several sensors in a row missing - Check connection between last good sensor and first bad sensor. Bypass first bad sensor in string with extension cable or adjacent sensor leads to troubleshoot. Single sensors not detected - Isolate or verify bad sensor by bypassing suspect sensor with extension cable or sensor leads.
  • Page 19: Sensor Measurements

    Sensor Measurements 4 21/32 IN. [118.23 mm] Sensor Measurements with Tee fitting 4 21/32 IN. [118.23 mm]...
  • Page 20: Sensor Parts

    Sensor Parts Important Note: Pre-2017 2017-after E ective Jan.1 2017, GRAY BLACK SafeGuard™ sensor plugs changed from gray JWPF to black Amphenol. Be certain to check vintage prior to ordering repl. parts. Cartridge Retainer SafeGuard Sensor Kit: P/N 18514 Includes sensor body, green cartridge, cartridge retainer, O-ring, and 2 U-clips.
  • Page 21: Optional Fittings

    Optional Fittings Plug with FKM (Viton® Cap - straight hosebarb with stainless steel U-clip type) O-ring P/N 18620 - 3/4” P/N 18515 - 1/4” FPT P/N 18621 - 1” P/N 18516 - 3/8” FPT P/N 18517 - 3/4” FPT Cap with stainless steel Tee Fitting with FKM Plug - straight hosebarb with U-clip...
  • Page 22: Parts List

    Parts List Part # Description 02000 SafeGuard™ ISOmod™ Kit 01994 Liquid Blockage Sensor Kit w/3" leads 01995 Liquid Blockage Sensor Kit w/20" leads 01996 Fumigant Blockage Sensor Kit w/3" leads 01997 Fumigant Blockage Sensor Kit w/20" leads 18687 Pink Cartridge 18723 Pink Cartridge - bulk pack 25 18724...
  • Page 23 Parts List cont. Part # Description 18896 Delphi MP630 (Great Plains™/Dickey John™) Tap Cable 18897 Delphi GT280 (Case™) Tap Cable 18944 Deutsch DTM Tap Cable (in-cab) Kit (includes power cable) 18945 Deutsch DT Tap Cable (in-cab) Kit (includes power cable) 18950 Deutsch DT Tap Cable (in-cab) Kit (includes power adapter) 18921...
  • Page 24 Parts List cont. Part # Description 18517 Plug, 3/4” FPT w/FKM (viton® type) O-ring 18520 Plug, 3/4” FPT w/FKM (viton® type) O-ring - bulk pack 25 18550 Plug, 3/4” FPT w/FKM (viton® type) O-ring - bulk pack 50 18622 Plug, 3/4” straight hosebarb w/FKM (viton® type) O-ring 18637 Plug, 3/4”...
  • Page 25: Warranty

    (60) days from the date‐of‐purchase for refund of the purchase price. Doc: MTS Warranty Statement_010119a Rev 2_01012019 MAIL and UPS: Micro-Trak® Systems, Inc. ATTN: Service Department P.O. Box 99 111 East LeRay Avenue Eagle Lake, MN 56024-0099 We thank you for your purchase, and hope that we can be of service to you in the future.
  • Page 26 This page intentionally left blank.
  • Page 27 This page intentionally left blank.
  • Page 28 Toll Free in U.S. or Canada: (800) 328-9613 or (507) 257-3600 Fax: 507-257-3001 www.micro-trak.com • trakmail@micro-trak.com P/N 18844 Copyright © 2019 Micro-Trak Systems Inc. 012819...
