Studiomaster Professional ELAN Series Instruction Manual

Professional loud speakers

ELAN SERIES

•

Thank you for purchasing the Studiomaster Professional ELAN SERIES Professional Loud Speakers.

•

To ensure maximum performance and safety, please follow this instruction manual carefully.

•

Please retain this manual for future reference.

•

For any complaint, feedback or testimonials please contact our Distributor / dealer.

6. Technical Specifications

Professional Loud Speakers

Table of Contents

Need help?

Do you have a question about the ELAN Series and is the answer not in the manual?

Page 1 ELAN SERIES Professional Loud Speakers • Thank you for purchasing the Studiomaster Professional ELAN SERIES Professional Loud Speakers. • To ensure maximum performance and safety, please follow this instruction manual carefully. • Please retain this manual for future reference. •...
Page 2 1. Warranty Information Unpacking As part of our system of quality control, every Studiomaster Professional products is carefully inspected before leaving the factory to ensure flawless appearance. After unpacking, please inspect for any physical damage. In the event that damage has occurred, immediately notify your dealer 2.
Page 3 We recommend that your cable should be no smaller than 14 guage. For cables of length 100-250ft use cables no smaller than 12 guage. 2) Matching amplifier To get the maximum performance from your ELAN Series Loudspeaker, Audioplus recommends the following guidelines. 3) Carefully Monitored Application: For carefully monitored applications, where the peak transient capability must be maintained, the amplifier should be capable of delivering twice continuous power rating of the speaker.
Page 4: Specifications
6. Specifications: ELAN 155 ELAN 181 Model 2-way Speaker Sub-Woofer Type Power Output 950 / 1900 800 / 1600 (RMS / Peak) Watts 40-20000 40-150 Frequency Response (Hz) Impedance (Ω) 98.1 Sensitivity (1w @1m) dB 126.5 Max SPL (dB) 2 x15” Woofer 3” Voice Coil 1 x18”...

Elan 155Elan 181
