- Page 1 LINK SW4X1-4KUHD 4 x 1 4K HDMI Switcher User Manual Version: V1.0.0...
- Page 2 Important Safety Instructions 1. Do not expose this apparatus to 6. Clean this apparatus rain, moisture, dripping or only with dry cloth. splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus. 7. Unplug this apparatus 2.
- Page 3 Warnings of FCC This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
Table of Contents Introduction ...................... 2 Overview ....................2 Features ....................2 Package Contents ..................2 Specifications .................... 3 Panel Description ..................5 Top Panel ..................5 Front Panel ..................6 Rear Panel ..................6 Installation and Wiring..................7 Installation ....................7 Wiring ....................... -
Page 5: Introduction
Introduction Overview LINK SW4X1-4KUHD features HDMI 2.0 and HDCP 2.2 compatibility and supports resolutions up to 4K@60Hz 4:4:4 8bit, enabling four Ultra HD sources to be switched to one Ultra HD display. It also allows control through top panel button, IR remote and automatic switch. -
Page 6: Specifications
Specifications Video Input 4 x HDMI IN (Type-A female connector) Output 1 x HDMI OUT (Type-A female connector) Input/Output Signal Type HDMI, HDCP 2.2 VESA: 640x480 , 800x600 , 1024x768 1280x768 , 1280x800 , 1280x960 1280x1024 , 1360x768 , 1366x768 1400x1050 , 1440x900 , 1600x900... - Page 7 General Operating Temperature 0° C to 45° C (32° F to 113° F) Storage Temperature -20° C to 70° C (-4° F to 158° F) Humidity 10% to 90%, non-condensing Human-body Model: ESD Protection ± 8kV(Air-gap discharge)/ ± 4kV(Contact discharge) Power Consumption 1.735W (Maximum)
-
Page 8: Panel Description
Panel Description Top Panel Name Description Power LED On: The switcher is powered on. (Red) Off: The switcher is powered off. HDMI In 1-4 On: The HDMI source is selected. LED (Red) Off: The HDMI source is not selected. On: An HDMI display is connected to the switcher. -
Page 9: Front Panel
Front Panel Name Description IR extension port. Connect ONLY the IR Ext. provided extension cable w/ red connector HDMI In 4 Connect to an HDMI source. HDMI Out Connect to an HDMI display. Connect to the power supply provided for DC 5V DC 5V power input. -
Page 10: Installation And Wiring
Installation and Wiring Installation Note: Before installation, please ensure the device is disconnected from the power source. Steps to install the device in a suitable location: Remove the four screws that secure the side panels to the device. Position and install the mounting brackets with the four mounting screws mentioned above. -
Page 11: Wiring
Wiring Warnings: Before wiring, disconnect the power from all devices. During wiring, connect and disconnect the cables gently. Steps for device wiring: Connect HDMI IN Connect HDMI source devices to HDMI IN (1-4) of the switcher using high-quality HDMI cables (e.g. PC, Blu-ray player, Apple TV, STB, etc.). Connect HDMI OUT Connect an HDMI display device to HDMI OUT of the switcher (e.g. -
Page 13: Control Of The Switcher
Control of the Switcher You can choose to control SW4X1-4KUHD at your convenience through top panel button, IR remote or automatic switch function. Top Panel Button Control IR Remote Control The switcher can be controlled by the IR remote provided. Point the remote directly at the IR extension cable connected to the "IR Ext."... -
Page 14: Automatic Switch Control
Button IR Codes Description 0x02 0x0a Switch to next active source input (Cycle 14). Switch to previous active source input (Cycle 0x02 0x08 41). Switch to source input 1. 0x02 0x04 Switch to source input 2. 0x02 0x05 Switch to source input 3. 0x02 0x06 Switch to source input 4. -
Page 15: Troubleshooting
Troubleshooting Troubleshooting Steps Power: Please make sure the source, display devices and switcher are powered on. Indicator: Please make sure all LED indicators of the switcher are normal according to user manual. Devices: Please make sure picture can be shown normally when connecting source to display device directly. -
Page 16: Warranty Terms And Conditions
Warranty Terms and Conditions For the following cases LINK shall charge for the service(s) claimed for the products if the product is still remediable and the warranty card becomes unenforceable or inapplicable. The original serial number (specified by LINK) labeled on the product has been removed, erased, replaced, defaced or is illegible. - Page 17 WWW.MSTRBRAND.COM...
