Summary of Contents for Hisense HM618

  • Page 1 HM618 PadPOS User Guide...

  • Page 2: Safety Precautions

    Safety Precautions Do not subject the device to severe impact or drop it from heights.  Do not use the device in extreme hot or cold, dusty or damp conditions. Do not expose it  to direct sunlight. Avoid using the device near strong magnetic fields. ...
  • Page 3 Please follow responsible procedures for battery disposal.  If the power adaptor disconnected from the device, the device will remain operable as  long as the battery has sufficient charge. The power adaptor is a CLASS II apparatus with double insulation, and no external ...

  • Page 4: Listening Cautions

    Listening Cautions This product respects the current regulations for limiting the output volume of consumer  audio devices to a safe level. By listening to your device with headphones or earbuds at high volumes, you run the risk of permanent damage to your ears. Even if you get used to listening at high volumes and it seems normal to you, you still risk the possibility of damaging your hearing.

  • Page 5: Features & Functionality

    Features & Functionality Tablet Front view Indicates the battery-charge status. Power indicator Capture a front view picture or record videos. Front camera Support muli-touch. Tounch screen...
  • Page 6 Top view Connect to headsets. Combo audio jack Capture voice which can provide sound input to Built-in microphone make calls using. web-based apps, audio recording.
  • Page 7 Left-side view Connects to the AC power adapter. AC power apdapter jack Connects to USB devices. USB 3.0 port Connects to USB devices. Micro USB port Accommadate micro SD card. Micro SD card slot Increases or decreases the volum level. Volum button Press and hold on to turn on or turn off the devices.
  • Page 8 Bottom view Attaches the table to the dock keeping the tablet Dock latch fixed in place. Connects the tablet to the dock . Pogo pin connector Connects the tablet to a TV or an external display . Micro HDMI port...
  • Page 9 Rear view Swipes Magnetic cards. Magnetic card reader Contactless integrated circuit card. Non-contact card reader Press the button to scan. Scan button Captures pictures or videos. Rear camera Built-in ports. Port cover Provides audio output. Speaker Lock the tablet on the multifunctional dock. Lock latch...
  • Page 10 Dock(optional) Attach the tablet to the dock Top view Rear view Dock Attaches the table to the dock. Dock latch keeping the tablet.fixed in place. Connects the tablet to the dock Pogo pin connector Connects to the AC power adapter. AC power apdapter jack Connects to USB devices.
  • Page 11 Multifunctional dock(optional) Attach the tablet to the dock Top view Rear view Multifunctional dock Cover for printer.(not supplied). Printer cover Inserts a key to lock the tablet. Keyhole Attach the tablet to the dock Dock latch keeping the tablet fixed in palce Connects the tablet to the dock.

  • Page 12: Basic Connections

    Basic Connections Charging the tablet Notes:  If using the tablet for the first time, or after a long period of idle time, charge the battery for more than half an hour before turning it on, to ensure system stability. ...

  • Page 13: Inserting A Microsd Card

    Inserting a micro SD card Open the port cover on the left. Pick up a micro SD card. Align the micro SD card so that the pins are pointed toward the card slot. Push the micro SD card into the card slot until it locks into place. Removing a micro SD card Touch the Tray button in the notification area in the lower-right corner of the screen.
  • Page 14 Connecting the Base Connector Place the base connector on an even plane like the top of a desk Connect the tablet to the base connector, aligning the Pogo pin jack and the positioning slots. To separate the tablet from the base connector, hold the base connector with one hand, then grab the top edge of the tablet and drag it apart.

  • Page 15: Basic Operation

    Basic Operation Turning On the Tablet Note: This device has been equipped with Windows 10 system at the factory, so user need not perform Windows setup again before using for the first time. Press and hold the Power button to turn on your tablet. The lock screen appears. Now the tablet is ready for use.

  • Page 16: Connecting To A Wireless Network

    Turning On/Off screen Usually, user can press once the power button to turn on/ off the screen display Optionally, user can also use the Start menu: Touch the Start button to bring up Start menu. Touch Power → Sleep to turn off the screen. Connecting to a wireless network Turning On/Off Wi-Fi Touch Wi-Fi icon...
  • Page 17 Gestures Your tablet has a multi-touch display. You can touch the screen to operate the tablet. Finger Gesture You can do Select items on the screen, including options, entries, Touch images, and icons. Tap gently on the display with your fingertip.

  • Page 18: Locking The Screen Orientation

    Locking the screen orientation For optimal viewing experience, the screen orientation changes automatically to portrait or landscape format depending on how you hold the tablet. You can disable automatic screen rotation and lock the screen in portrait or landscape mode. Note: Some apps may not support automatic screen rotation and are designed to work only in one orientation.

  • Page 19: Maintenance

    Maintenance Cleaning Your Tablet Caution: Before you clean your tablet, disconnect all the cables and turn off the tablet. Clean your tablet with a soft cloth dampened with water. Do not use liquid or aerosol clean- ers, which may contain flammable substances. 1.

  • Page 20: Major Specifications

    Major Specifications Note: The following specifications may contain technical inaccuracies or typographical errors. We reserves the right to improve and/ or change specifications at any time without prior notice. Item Descriptions View the system information for details* You can view details as follows: Open the Control Panel, and select →...

  • Page 21: Fcc Statement

    Hisense. Any unauthorized distribution of this manual is expressly forbidden. Hisense may find it necessary to modify, amend or otherwise change or update this manual. We reserve the right to do this at any time, without any prior notice. All specifications and features are subject to change without notice.
