Prism Remote Unit and RF Module
Installation Guide • FWPP-504-02 • May 2017
NETWORK
SeRF II
FAN
CRAFT
DC POWER
NOKIA
CDIU
CDIU
CPRI PORT 1
CRAFT
REF
PATH A
PATH B
OUT
CONFIG
PWR
CPRI PORT 2
CDIU
NOKIA
CPRI PORT 1
CRAFT
REF
PATH A
PATH B
OUT
CONFIG
PWR
CPRI PORT 2
NOKIA
CPRI PORT 1
CRAFT
REF
PATH A
PATH B
OUT
CONFIG
PWR
CPRI PORT 2
PWR
REV
FWD
RF OUT
REF IN
STATUS
FWD NOT TO
EXCEED +6 dBm
PWR
REV
FWD
RF OUT
REF IN
STATUS
FWD NOT TO
EXCEED +6 dBm
Advertisement
Table of Contents
Related Manuals for CommScope FlexWave
Summary of Contents for CommScope FlexWave
- Page 1 ® FlexWave Prism Remote Unit and RF Module Installation Guide • FWPP-504-02 • May 2017 NETWORK NOKIA NOKIA CDIU CDIU SeRF II CPRI PORT 1 CRAFT CPRI PORT 1 CRAFT PATH A PATH A PATH B PATH B CONFIG CONFIG...
- Page 2 ISCLAIMER This document has been developed by CommScope, and is intended for the use of its customers and customer support personnel. The information in this document is subject to change without notice. While every effort has been made to eliminate errors, CommScope disclaims liability for any difficulties arising from the interpretation of the information contained herein. The information contained herein does not claim to cover all details or variations in equipment, nor to provide for every possible incident to be met in connection with installation, operation, or maintenance. This document describes the performance of the product under the defined operational conditions and does not cover the performance under adverse or disturbed conditions. Should further information be desired, or should particular problems arise which are not covered sufficiently for the purchaser's purposes, contact CommScope. CommScope reserves the right to change all hardware and software characteristics without notice. OPYRIGHT © 2017 CommScope, Inc. All Rights Reserved. All trademarks identified by ® or ™ are registered trademarks or trademarks, respectively, of CommScope, Inc. This document is protected by copyright. No part of this document may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical photocopying, recording, or otherwise without the prior written permission of CommScope. THER RADEMARKS Names of other products mentioned herein are used for identification purposes only and may be trademarks and/or registered trademarks of their respective companies.
-
Page 3: Table Of Contents
Option C: ProAx Connector (Legacy AC-Powered PRUs) ..........................67 Connect the Antenna Cable .....................................71 Determine the Circuit Breaker or Fuse for the PRU ..............................72 Power Consumption......................................73 Power Consumption Tables....................................74 ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page iii... - Page 4 Specifications ........................................121 Standards Certification.......................................123 DCCS Global Technical Support...................................124 Telephone Helplines.......................................124 Online Support ........................................124 DCCS Technical Training .....................................125 Accessing FlexWave User Documentation ................................126 Accessing Prism User Documentation..................................126 Accessing Spectrum User Documentation ................................126 ® FlexWave Prism Remote Unit and RF Module Installation Guide...
-
Page 5: Document Overview
RF Modules are ordered separately and must be installed in a Prism Remote Unit in the field. Table 1 lists the Prism Remote Unit chassis and Table 2 through Table 8 on page 3 list the Prism RF Modules that this installation guide supports. Table 1. Supported FlexWave Prism Remote Unit Chassis Catalog Number Description F P 1 - X X XX X X XX X X XR U... - Page 6 Table 6. Supported Dual SuperDART, Single Bay, Non-Diversity RF Modules Catalog Number Description FWP-741S000MOD 20W 1800 GSM FWP-841S000MOD 20W 1900 PCS FWP-A41S000MOD 20W 2100 AWS FWP-941S000MOD 20W 2100 UMTS ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 2 © May 2017 CommScope, Inc.
-
Page 7: Document Revision History
FWPP-504-01 July 2016 The initial release of this installation guide (FWPP-504-01) was released when CommScope acquired TE Connectivity’s telecom, enterprise and wireless business, which included the FlexWave Prism product line. CommScope document FWPP-504-01 replaced TE document TECP-77-275. FWPP-504-01 also added support for the HDM TDD RF Modules FWP-T4MT000MOD-L (20W 2500 TDD Low, MIMO, 2496.5-2571.5 MHz) and... -
Page 8: Abbreviations Used In This Guide
Internet Protocol Volts, Alternating Current Local Area Network Watt Lead Covered Wireless Communications Services Light-Emitting Diode Wavelength Division Multiplexer LVDS Low-Voltage Differential Signaling ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 4 © May 2017 CommScope, Inc. -
Page 9: Overview Of Prism Remote Units
E M O T E N I T S FlexWave PRUs control RF emissions, interface with the FlexWave Prism Host Unit II and perform the optical to electrical conversion for transport to the antennas. The PRU is an environmentally-sealed unit designed for outdoor use that houses the electronic assemblies such as the Digital/Analog Radio Transceiver (DART) board and the Power Amplifier, and seals out dirt and moisture. The PRU uses fans located on the top of each unit to cool its chassis. The antenna cable connectors, fiber connectors, AC or DC power connector, and the unit status indicator are located on the bottom of the unit. A PRU supports or provides the following basic functions: Receives on the forward path the digitized spectrum from the Host and converts the spectrum back into an • RF signal to be distributed via an externally mounted antenna system. On the reverse path, the PRU digitizes the designated RF spectrum and digitally transports it over single mode fiber or Millimeter Wave (MMW) to the Host. Provides RF interface (antenna port) for the antennas. • Accepts either AC or DC power input. • ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 5... -
Page 10: Prism Remote Unit Components
SeRF Module DC Power switches for RF Modules Cable connectors Main AC/DC Power switch for the chassis Figure 1. Prism Remote Unit Components ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 6 © May 2017 CommScope, Inc. -
Page 11: Ports And Connectors
Overview of Prism Remote Units ORTS AND ONNECTORS Make sure you refer to the section that describes the PRU deployed in your installation. "Bottom of an AC-Powered Quad-Bay PRU” on page 8 and "DC-Powered Quad-Bay PRU” on page 9 shows the differences between an AC-powered and a DC-powered PRU. The differences will be the same for Single-Bay, Dual-Bay, and Tri-Bay chassis. Additionally, for both the AC-Powered and DC-Powered PRUs: The number of Antenna connectors on the bottom of a PRU corresponds to the number of RF Module bays in • that PRU model, where there are two Antenna connectors per bay. For example: There are four RF Module bays in a Quad-Bay PRU, so there are eight Antenna connectors. – There is one RF Module bay in the Single-Bay PRU, so there are two Antenna connectors. – The Single-Bay PRU only has one Fiber connector whereas the other three PRU models have two. • ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 7... -
Page 12: Bottom Of An Ac-Powered Quad-Bay Pru
LAN Extension of the Host Unit Network that provides access to the Prism Network Connector port for access and monitoring via an up to a 100 Mbps IP back-haul connection to remote devices. ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 8 © May 2017 CommScope, Inc. -
Page 13: Dc-Powered Quad-Bay Pru
Connector (shown) • Fiber Pass-Through • ProAx connectors that provide four BX5 connectors (Legacy PRUs) Dual-Ground Ground connector Grounds the PRU. connector ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 9... -
Page 14: Remote Unit Status Led
WARNING: HIGH LEAKAGE CURRENT. EARTH CONNECTION ESSENTIAL BEFORE CONNECTING SUPPLY Bo om of an AC-Powered PRU Bo om of a DC-Powered PRU ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 10 © May 2017 CommScope, Inc. -
Page 15: Serf Module Leds
ALARM, SYNTH, and STATUS LEDs, after which the LEDs begin normal operation. Additionally, an active SeRF Synthesizer failure causes the same LED sequencing approximately every minute until the SeRF failure clears. ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 11... -
Page 16: Overview Of Rf Modules For Prism Remote Units
RF M ODULE IGITAL NALOG ADIO RANSCEIVERS Each RF Module can support any of the following Digital/Analog Radio Transceiver (DART) combinations: one Classic DART or one Single SuperDART • two Classic DARTs (i.e., the 6.5W 800/900 ESMR Module, Non-Diversity, Classic) • two Classic DARTs—Diversity • two Single SuperDARTs—Diversity • one Dual SuperDART • one or two sets of Tx and Rx Boards (HDM). • Each RF Module will have up to two 6-timeslot DARTs or one 12-timeslot DART per RF Module. The DART type determines the maximum number of links, where there can be up to eight Classic DARTs or Single SuperDARTs that support 35 MHz each, or up to 4 Dual SuperDARTs that support up to 75MHz each. ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 12 © May 2017 CommScope, Inc. - Page 17 This requires 12 fiber slots when full-band passband is selected for these Single SuperDARTs in Host Unit DART positions 1 and 3. ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 13...
-
Page 18: Rf Module Types
1900 PCS DL SuperDART 2100 AWS DL SuperDART 2100 UMTS DL SuperDART RF M ODULE YPES The Remote Unit RF Modules are available in the following formats, and as described in the following sections: "Single- and Dual-Bay RF Modules with Classic or SuperDARTs” on page 15 • "HDM RF Modules” on page 16 • "Legacy Dual-Bay 40W RF Modules” on page 17. • ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 14 © May 2017 CommScope, Inc. -
Page 19: Single- And Dual-Bay Rf Modules With Classic Or Superdarts
• one Low Noise Amplifier (LNA) – one Power Detector (PD) – one Linear Power Amplifier (LPA) • one Remote DART Interface (RDI) board. • Dual-Band Dual-Bay RF Modules have the following elements: two DARTs • two Duplexers, each of which comprises • one Low Noise Amplifier (LNA) – one Power Detector (PD) – one Linear Power Amplifier (LPA) • one Remote DART Interface (RDI) board. • ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 15... -
Page 20: Hdm Rf Modules
Table 12. Components of PRU HDM RF Modules RF Module Type Duplexer Power Detector Rx Card Tx Card SISO MIMO/Dual Band Module ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 16 © May 2017 CommScope, Inc. -
Page 21: Legacy Dual-Bay 40W Rf Modules
This manual describes how to install the PCS 1900 and AWS 2100 Non-Diversity RF Modules. Figure 4. Legacy Dual-Bay 40W RF Module ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 17... -
Page 22: Rf Module Components
Figure 5. Single-Bay RF Module Components Tx and Rx Cards Duplexers Power Amplifier Moun ng hook Moun ng latch Figure 6. HDM RF Module Components ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 18 © May 2017 CommScope, Inc. -
Page 23: Linear Power Amplifiers
Industry Canada 20 dB Pass Band Model Number FWP-C4MT000MOD Cellular 850 MHz = 26.3 MHz and the PCS 1900 = 66.8 MHz. ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 19... -
Page 24: Duplexer And Low Noise Amplifier
Digital Processing Module The Digital Processing Module (DPM) is found only in the HDM RF Modules. The DPM provides the primary processing and logic functions for the HDM RF Module. It also provides the primary power interface for the HDM RF Module, and conversion of the native 28 Vdc voltage to lower voltages as necessary for functionality. The DPM has a Transmit (Tx) Board and a Receive (Rx) Board: Tx Board—provides band specific filtering for the intended Transmit path. • Rx Board—provides band specific filtering for the intended Receive path. • Cables Always provided at each RF Module shelf are five cables: two High-Speed Data Cables, which in this document are referred to as LVDS (Low-Voltage Differential • Signaling) cables two RF Cables (TX0/RX0) and (TX1/RX1) • one Power (PWR) Cable. • The RF Module cables that are pre-installed in the PRU connect to the corresponding connectors on the RF Module. The RF Module cables correlate to the antenna connectors on the bottom of the Remote Unit chassis. ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 20 © May 2017 CommScope, Inc. -
Page 25: Leds On Narrowband Hdm Rf Modules
Not used. LED is only applicable to the Primary connector; it is not tied to the status of the Secondary DPA connector. ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 21... -
Page 26: Leds On Wideband And Fullband Hdm Rf Modules
One or more synthesizer is unlocked. Overflow on RX. Green All synthesizers are locked. RXB Status Blinking Green One or more synthesizer is unlocked. Overflow on RX. ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 22 © May 2017 CommScope, Inc. -
Page 27: Configuring The System With Rf
DART 3 Bay B DART 4 DART 1 Bay A DART 2 SeRF Module Figure 7. RF Modules Bays in a PRU ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 23... - Page 28 CAUTION! Should your system experience an LPA problem, refer to Table 15 to ensure that you apply new settings or troubleshoot the correct RF Module. The Legacy Dual-Bay 40W RF Module occupies two bays in a PRU. Figure 8 on page 25 shows the main components in a PRU enclosure, with a Legacy 40W RF Module occupying Bays A and B. The controlling DART will always be in the upper bay (B or D), and the second LPA is always in the lower bay (A or C). ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 24 © May 2017 CommScope, Inc.
- Page 29 To accommodate two-bay modules, you need to remove a module bay shelf as described in "Dual-Bay Modules Only—Remove the Module Bay Shelf” on page ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 25...
-
Page 30: Understanding Rf Cable Rules
MOD N TX0/RX0 and MOD N TX1/RX1, where N refers to the top bay of the double-bay installation. For example: For a Dual-Bay installation in a Quad-Bay chassis in which the RF Module is installed in the Bay D and Bay – C combination, the RF cables and connectors are labeled as MOD D TX0/RX0 and MOD D TX1/RX1. For a Dual-Bay installation in a Tri-Bay chassis in which the RF Module is installed in the Bay B and Bay – A combination, the RF cables and connectors are labeled as MOD B TX0/RX0 and MOD B TX1/RX1. Table 16 on page 27 also shows which RF Module type can be installed in which PRU bay or bay combination. • ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 26 © May 2017 CommScope, Inc. -
Page 31: 40W Rf Modules
40W Dual-Bay RF Module is part of the RF Module mix in a PRU chassis. The Single-Bay chassis is not included in Table 17 on page 28. For Dual-Bay installations, the RF cables and connectors are labeled as MOD N TX0/RX0 and MOD N TX1/RX1, where N refers to the top bay of the double-bay installation. For example: For a Dual-Bay installation in a Quad-Bay chassis in which the RF Module is installed in the Bay D and Bay C • combination, the RF cables and connectors are labeled as MOD D TX0/RX0 and MOD D TX1/RX1. For a Dual-Bay installation in a Tri-Bay chassis in which the RF Module is installed in the Bay C and Bay B • combination, the RF cables and connectors are labeled as MOD C TX0/RX0 and MOD C TX1/RX1. ® FWPP-504-02 FlexWave Prism Remote Unit and RF Module Installation Guide © May 2017 CommScope, Inc. Page 27... - Page 32 Install the Legacy Dual-Bay 40W RF Module in the lower-most bay in the chassis. If, however, if two Legacy Dual-Bay 40W RF Modules are present, install the 2100 Module in the lower-most Bay and the 1900 Module in the upper-most Bay. ® FlexWave Prism Remote Unit and RF Module Installation Guide FWPP-504-02 Page 28 © May 2017 CommScope, Inc.
