- Page 1 Wireless Data Terminal Installation Guide Reliance Netconnect+ AC2737 Installation Guide for Linux This Installation Guide is used for Reliance Netconnect+. V 1.0 ZTE Corporation http://www.zte.com.cn...
- Page 2 The setup package will omit the step of compiling the driver after confirming that the system version is Ubuntu9.04; instead, it would modify the system pilot configuration (menu.lst) in order to support different ZTE USB data cards. Note: You need insert USB data card when installing UI software under Ubuntu9.04 system,...
- Page 3 Or add the corresponding setup package from CD after the system is installed. openSUSE: it’s recommended to install with yast setup package manager. Take openSUSE11.1 system for example. The kernel packages installed are listed as below (for reference only): kernel-source-2.6.27.7-9.1 linux-kernel-headers-2.6.27-2.28 kernel-pae-base-2.6.27.7-9.1 kernel-pae-2.6.27.7-9.1 kernel-syms-2.6.27.7-9.1 kernel-pae-extra-2.6.27.7-9.1 ZTE Corporation http://www.zte.com.cn...
- Page 4 This problem occurs as other users(non-admin users) are installing. The installation can’t be completed because there are no enough rights. Please use “sudo” command to install (as shown above) Old version not removed The old version must be removed before installation, otherwise the installation will fail. ZTE Corporation http://www.zte.com.cn...
- Page 5 You could download the relevant deb or rpm to install. Recommended website: http://rpm.pbone.net/index.php3/stat/4/idpl/12245031/com/libaudio2-1.9.2-0.pm.1.i586. rpm.html http://packages.ubuntu.com/hardy/libaudio2 or you could get the relevant compression package of library files, containing libaudio.so, libaudio.so.2, libaudio.so.2.4, etc., directly unzip to /lib directory and run ldconfig command. ZTE Corporation http://www.zte.com.cn...
-
Page 6: Common Problems And Troubleshooting
/dev/ after inserting the data card (1~ 2 seconds). ttyUSB0 corresponds to modem port. If the installation fails, you will not find /dev/ttyUSB0. You are prompted with “Can’t find device” when running UI. ZTE Corporation http://www.zte.com.cn... - Page 7 However, we have built-in the automatic judgment and handling over Ubuntu9.04 in the setup package; if such an error occurs to your system unexpectedly, use the following method to manually pass two parameters to the kernel, and make the kernel support ZTE USB modem.
- Page 8 (the detailed operations might vary according to different Linux system versions and hardware configurations) During the use of UI, if Capture device can’t be used by default, please manually select one (generally select the last one, namely, the second device). See the figure below: ZTE Corporation http://www.zte.com.cn...
- Page 9 For Linux 2.6.31 kernel such as Fedora12, the prompt like “Cannot access serial port.Make sure you ZTE Corporation http://www.zte.com.cn...
- Page 10 Why doesn't the system automatically load CD-ROM and can't install the driver and UI software after the data card is inserted? It's unnecessary to install ZTE driver and UI software since the new version of usb_modeswitch tool integrates the driver of data card. You can directly connect to the Internet through the system's dialer.
