- Page 1 Translation of the Original Operating Manual RI 331 D1,5 / D3 / D4 H IE2 GERMANY Date of Delivery: 2015-12-10 Ringler GmbH Robert-Bosch-Straße 4–8 Fon +49 (0)7171-94 888-0 info@ringler.kaercher.com 73550 Waldstetten [Germany] Fax +49 (0)7171-94 888-28 www.ringler-gmbh.de...
- Page 2 Copyright Copyright by Ringler GmbH Robert-Bosch-Straße 4-8 73550 Waldstetten GERMANY 2/56...
-
Page 3: Table Of Contents
Safety Instructions ..........................7 Terms ..............................7 1.1.1 Operation ............................7 1.1.2 Maintenance ..........................7 1.1.3 Qualified Staff ..........................7 Symbols ............................. 7 General safety information ......................... 9 Delivery, internal transportation, unpacking ..................10 Delivery ............................10 Internal transport ..........................10 2.2.1 Dimensions and weight ........................ - Page 4 Safety instructions ........................... 22 Initial fault elimination measures ..................... 22 Maintenance/Repair..........................24 Maintenance regulations ........................24 Maintenance intervals table ......................25 Cleaning ............................25 Disassembly of the suction turbine ....................26 Disassembly of the bag-type filter ....................27 Changing the filter cloth for the bag-type filter ................. 28 9.6.1 Work steps for pocket filter change .....................
- Page 5 12.22.2 Spare Parts List Suction hose DN 70, all Types ..............53 12.22.3 Spare Parts List Suction hose DN 70, all Types ..............53 12.23 Accessories List ........................... 54 Component documentation ......................... 55 13.1 Documentation for side-channel compressor .................. 55 13.2 Documentation for differential pressure switch - Technical data .............
- Page 6 Safety Instructions Pos : 1.1 /1 Grundl egende Sic her heitshi nweis e/Kapitelüb erschrift 1 Angaben zur Sic her hei t @ 0\mod_1261472663260_131.doc x @ 973 @ 1 @ 1 6/56...
-
Page 7: Safety Instructions
Safety Instructions Safety Instructions Pos : 1.2 /1 Grundl egende Sic her heitshi nweis e/Kapitelüberschrift 2 Begriffe @ 0 \mod_1261472746655_131.doc x @ 980 @ 2 @ 1 Terms Pos : 1.3 /1 Grundl egende Sic her heitshi nweis e/Begriffe-Betri eb @ 0\mod_1261486420512_131.doc x @ 1040 @ 3 @ 1 1.1.1 Operation includes installation, initiation (placing at disposal for usage), operation (handling, connection,... - Page 8 Safety Instructions Community. Pos : 1.19 /1 Gr undleg ende Si cherheits hinweis e/Hinweis Sic her heitssc huhe @ 0 \mod_1261406516446_131.doc x @ 925 @ @ 1 Only use with safety shoes (acc. to EN ISO 20345) Pos : 1.20 /1 Gr undleg ende Si cherheits hinweis e/Hinweis Arbeits handsc huhe @ 0 \mod_1261407294655_131.doc x @ 932 @ @ 1 Only use with work gloves Pos : 1.21 /1 Gr undleg ende Si cherheits hinweis e/Hinweis Atemsc hutz @ 4\mod_1358754071540_131.doc x @ 37562 @ @ 1 Respiratory protection (EN 149:2001)
-
Page 9: General Safety Information
Please arrange for a service immediately, or send the industrial vacuum cleaner for repair to: Pos : 3.17 /1 Gr undleg ende Si cherheits hinweis e/Sic herheitsi nformati onen Wechs elstr om-Geräte/Ser vic e Adress se Ri ngler @ 0\mod_1269505846364_131.doc x @ 3516 @ @ 1 Ringler GmbH Abt. Service Robert-Bosch-Straße 4-8... -
Page 10: Delivery, Internal Transportation, Unpacking
Delivery, internal transportation, unpacking Delivery, internal transportation, unpacking Pos : 4.2 /2 Ver pac kung, Tr ansport, Lager ung/Anli eferung @ 0\mod_1261401230055_131.doc x @ 853 @ 2 @ 1 Delivery Unload the scope of delivery on level ground with sufficiently sized industrial trucks. Pos : 4.3 /2 Ver pac kung, Tr ansport, Lager ung/Inner betrieblicher Trans port @ 0 \mod_1261401337747_131.doc x @ 860 @ 2 @ 1 Internal transport Transport scope of supply to the site of setup secured against movement or tipping with a sufficiently sized... -
Page 11: Dimensions And Weight
Delivery, internal transportation, unpacking Pos : 4.6 /2 Ver pac kung, Tr ansport, Lager ung/Ü bersc hrift: Abmess ung en und Gewic ht @ 0\mod_1269507946238_131.doc x @ 3536 @ 3 @ 1 2.2.1 Dimensions and weight Pos : 4.7 /2 Ver pac kung, Tr ansport, Lager ung/T abelle: Abmess ung en und Gewic ht R I 331 D-H @ 4\mod_1361451601064_131.doc x @ 40119 @ @ 1 Packaging L (mm) approx. -
Page 12: Appliance Description
Appliance description Appliance description Pos : 6.2 /3 Beschr eibung der Maschi ne, Ver wendung/Ü bers chrift: Bes ti mmungsgemäße Verwendung @ 1\mod_1335181714405_131.doc x @ 11500 @ 2 @ 1 Intended Use Pos : 6.3 /1 Grundl egende Sic her heitshi nweis e/Signalwort-F eld "Hi nweis" @ 0\mod_1261404960439_131.doc x @ 905 @ @ 1 NOTICE Pos : 6.4 /3 Beschr eibung der Maschi ne, Ver wendung/Ger ät, das i n betriebs ber eitem Zustand ausg eliefert (Tr oc ken für mobile Geräte) @ 2\mod_1344413911521_131.doc x @ 20207 @ @ 1 •... -
Page 13: Layout And Function
Pos : 7.2 /4 Aufbau und F unktion, Technisc he Daten/Ri ngler Indus tries aug er und fahr bare Entstauber werden in betriebs ber eitem Zustand ausgeliefert. @ 1\mod_1288959524159_131.doc x @ 6987 @ @ 1 Ringler industrial vacuum cleaners and mobile dust collectors are delivered in operational condition Pos : 7.3 /4 Aufbau und F unktion, Technisc he Daten/Ü... -
Page 14: Technical Data D1,5 Ie2
Layout and function Pos : 7.7 /4 Aufbau und F unktion, Technisc he Daten/IE2/AntriebeT ec hnisc he D aten D1,5 IE2 @ 7\mod_1417006083720_131.doc x @ 73299 @ 2 @ 1 Technical Data D1,5 IE2 Power 1,5kW 1,75kW Frequency 50Hz 60Hz Hedging 200-260V / 5,7A Δ... -
Page 15: Main Components
Main components Main components Pos : 8.2 /5 Anl agenbesc hrei bung, Bedi enungs- und Anz eigeel emente, Betri ebs arten/RI/Ü berschrift: Bestandteile R I 331 @ 4\mod_1361455669836_131.doc x @ 40185 @ 2 @ 1 Components RI 331 Pos : 8.3 /5 Anl agenbesc hrei bung, Bedi enungs- und Anz eigeel emente, Betri ebs arten/RI/Z eic hnung Hauptbes tandteil e RI 331-IS-H @ 4\mod_1361455670707_0.doc x @ 40196 @ @ 1 Pos : 8.4 /5 Anl agenbesc hrei bung, Bedi enungs- und Anz eigeel emente, Betri ebs arten/RI/T abell e z u Z eichnung H auptkomponenten R I 331-IS-H @ 4\mod_1361455780848_131.doc x @ 40207 @ @ 1 Chassis Filter container... -
Page 16: Initiation
Initiation Initiation Pos : 9.2 /1 Grundl egende Sic her heitshi nweis e/Hi nweis Sic herheitssc huhe @ 0\mod_1261406516446_131.doc x @ 925 @ @ 1 Only use with safety shoes (acc. to EN ISO 20345) Pos : 9.3 /1 Grundl egende Sic her heitshi nweis e/Signalwort-F eld " Vorsicht" @ 0\mod_1261404898171_131.doc x @ 899 @ @ 1 CAUTION Pos : 9.4 /6 Inbetriebnahme/Ansc hluss an das Stromnetz (Dr ehs trom) ( mobile Geräte) @ 1\mod_1289830710106_131.doc x @ 7127 @ 2 @ 1 Connection to the electric mains... -
Page 17: Potential Equalization Conductors
Initiation Pos : 9.10 /6 Inbetri ebnahme/Bauar t 22/Ü bersc hrift: Potenti alausgleic hsl eitungen @ 2\mod_1345531146199_131.doc x @ 20892 @ 2 @ 1 Potential equalization conductors Pos : 9.11 /6 Inbetri ebnahme/Bauar t 22/Text z u Warns ymbol, Potenti alausgleic hslei tungen prüfe n @ 0\mod_1262875164082_131.doc x @ 1100 @ @ 1 Before commissioning, always check that the potential equalization conductors (earthing conductors) are connected! Pos : 10.1.1 /7 Betri eb, Bedienung/Betri eb, Bedienung, Kapitel übersc hrift @ 0\mod_1263539997200_131.doc x @ 1414 @ 1 @ 1... -
Page 18: Operation
Operation Operation Pos : 10.1.2 /7 Betri eb, Bedienung/Betri eb, Ü bersc hrift 1.1 @ 0\mod_1263544263702_131.doc x @ 1432 @ 2 @ 1 Operation Pos : 10.1.3 /1 Gr undleg ende Sic herheits hinweis e/Sig nal wort-Fel d " Vorsic ht" @ 0\mod_1261404898171_131.doc x @ 899 @ @ 1 CAUTION Pos : 10.1.4 /7 Betri eb, Bedienung/Gerät nur mi t akti vi erten F eststellbrems en akti vi eren @ 6 \mod_1401971694391_131.doc x @ 60511 @ @ 1 •... -
Page 19: Filter Cleaning
Operation Pos : 10.4.1 /7 Betri eb, Bedienung/Ü bersc hrift Filter abr einigung @ 2 \mod_1337326637205_131.doc x @ 13380 @ 2 @ 1 Filter cleaning Pos : 10.4.2 /7 Betri eb, Bedienung/Ü bersc hrift Manuelle Filter abr einig ung @ 2 \mod_1337326667859_131.doc x @ 13387 @ 3 @ 1 7.3.1 Manual filter cleaning Pos : 10.4.3 /1 Gr undleg ende Sic herheits hinweis e/Sig nal wort-Fel d "... -
Page 20: Time Of Dedusting
Operation Time of dedusting Cleaning must take place before the specified red/green transition in order to maintain adequate suction power. If the value is exceeded the air speed in the suction hose drops to below 20 m/sec. If the value cannot be significantly reduced the filter must be changed, or there may be a blockage in the hose or the pipeline! Pos : 10.8.1 /7 Betri eb, Bedienung/Sonder-Zubehör/Ü... - Page 21 Operation Before emptying the dust container, switch off the device and wait for the motor to stop. Additionally, the pocket filter "1" should be shaken off. Then wait for about 60 s until the dust has deposited in the collection container. •...
-
Page 22: Troubleshooting And Fault Elimination
All the errors mentioned in the table below may be eliminated by yourself. In case of major problems or other failures please contact the customer service of Ringler immediately. Tel. ++49-(0)7171-94888-0 Perform maintenance tasks in accordance with the description in the Maintenance/Servicing chapter Pos : 11.12 /8 Störungss uche und Störungs bes eitigung/RI/Tabelle Störungen Spänes aug er Drehstr om @ 1\mod_1290413366922_131.doc x @ 7310 @ @ 1... - Page 23 Troubleshooting and fault elimination Motor switched to triangle instead of star electrician Pos : 12.1 /9 Wartung/Instands etz ung/Wartung/Ins tandsetz ung, Kapitel übersc hrift @ 0\mod_1263808011795_131.doc x @ 1516 @ 1 @ 1 23/56...
-
Page 24: Maintenance/Repair
Pos : 12.11 /9 Wartung/Ins tandsetzung/Hi nweis text H aftung und Garanti e @ 0\mod_1263809657689_131.doc x @ 1540 @ @ 1 • Ringler assumes liability and guarantee only in case of proper use and compliance with the following maintenance instructions. -
Page 25: Maintenance Intervals Table
Maintenance/Repair Pos : 12.18 /1 Grundlegende Sic her hei tshi nweise/Signal wort-F eld " War nung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 12.19 /9 Wartung/Ins tandsetzung/Warntext El ektr ofachkr aft @ 0 \mod_1264055838943_131.doc x @ 1680 @ @ 1 •... -
Page 26: Disassembly Of The Suction Turbine
Maintenance/Repair Pos : 12.27.1 /9 Wartung/Ins tandsetzung/RI/Übersc hrift: Aus bau der Abs augturbi ne @ 0\mod_1269597671546_131.doc x @ 3779 @ 2 @ 1 Disassembly of the suction turbine Pos : 12.27.2 /1 Grundlegende Sic her hei tshi nweise/Signal wort-F eld " War nung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 12.27.3 /9 Wartung/Ins tandsetzung/Warntext El ektr ofachkr aft @ 0\mod_1264055838943_131.doc x @ 1680 @ @ 1 •... -
Page 27: Disassembly Of The Bag-Type Filter
Maintenance/Repair Pos : 12.29.1 /9 Wartung/Ins tandsetzung/RI/Übersc hrift: Aus bau Fl äc henfilter @ 0 \mod_1269607770945_131.doc x @ 3851 @ 2 @ 1 Disassembly of the bag-type filter Pos : 12.29.2 /1 Grundlegende Sic her hei tshi nweise/Signal wort-F eld "Hinweis" @ 0\mod_1261404960439_131.doc x @ 905 @ @ 1 NOTICE Pos : 12.29.3 /1 Grundlegende Sic her hei tshi nweise/Hinweis N etzs tec ker zi ehen @ 0\mod_1261407392098_131.doc x @ 939 @ @ 1 Before starting work remove the plug from the wall socket! -
Page 28: Changing The Filter Cloth For The Bag-Type Filter
Maintenance/Repair Pos : 12.31.1 /9 Wartung/Ins tandsetzung/Ü bersc hrift, Filtertuchwec hsel für Taschenfilter @ 0\mod_1263816608939_131.doc x @ 1582 @ 2 @ 1 Changing the filter cloth for the bag-type filter Pos : 12.31.2 /1 Grundlegende Sic her hei tshi nweise/Signal wort-F eld " War nung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 12.31.3 /1 Grundlegende Sic her hei tshi nweise/Hinweis N etzs tec ker zi ehen @ 0\mod_1261407392098_131.doc x @ 939 @ @ 1 Before starting work remove the plug from the wall socket! -
Page 29: Work Steps For Pocket Filter Change
Maintenance/Repair Pos : 12.31.10 /9 Wartung/Instands etz ung/Filter wec hsel /Übersc hrift Arbeitssc hritte beim Taschenfilterwec hs el @ 1 \mod_1337149436978_131.doc x @ 13306 @ 3 @ 1 9.6.1 Work steps for pocket filter change Pos : 12.31.11 /1 Gr undl egende Sicherheits hi nweis e/Signal wort-F eld " Warnung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 12.31.12 /1 Gr undl egende Sicherheits hi nweis e/Hi nweis Netzstec ker zi ehen @ 0\mod_1261407392098_131.doc x @ 939 @ @ 1 Before starting work remove the plug from the wall socket! - Page 30 Maintenance/Repair Rotate filter cloth with spacer frame by 180° and position on filter insert, Fix retaining band over the filter cloth in the area of the bead, Mount spacer grille with leaf spring, align pockets of filter cloth with holes on spacer grille. Pos : 12.31.18 /------------Seitenumbr uch------------ @ 2\mod_1340970793881_131.doc x @ 18430 @ @ 1 30/56...
- Page 31 Maintenance/Repair Pos : 12.31.19 /9 Wartung/Instands etz ung/Filter wec hsel /Lage des T asc henfil ter @ 3\mod_1353327555446_131.doc x @ 34532 @ @ 1 • At installation, in particular correct position of the fine dust pocket filter in the pre-separator container must be observed! At manual filter shaker:(1) The tab at the filter insert must be inserted into the shaft.
-
Page 32: Change H14-Filter Cartridge
Maintenance/Repair Pos : 12.33.1.1 /9 Wartung/Ins tandsetzung/Filter wec hs el/Ü bersc hrift Filter wec hsel H 14-Filter patrone @ 2\mod_1347279349611_131.doc x @ 26015 @ 2 @ 1 Change H14-filter cartridge Pos : 12.33.1.2 /1 Grundl egende Sic her hei tshi nweis e/Signal wort-F eld "War nung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 12.33.1.3 /1 Grundl egende Sic her hei tshi nweis e/Hi nweis N etzs tec ker zi ehen @ 0\mod_1261407392098_131.doc x @ 939 @ @ 1 Before starting work remove the plug from the wall socket! -
Page 33: Removal H14 Filter
Maintenance/Repair Pos : 12.33.3 /9 Wartung/Ins tandsetzung/Filter wec hs el/Aufzählung Arbeitssc hritte Wechsel H 14-Filter @ 2\mod_1347282774406_131.doc x @ 26043 @ 33 @ 1 9.7.1 Removal H14 filter: • Remove drive unit from the filter container; • Remove two-part tensioning belt (1) by loosening one of the two screws (SW 13). •... -
Page 34: Rotational Direction Identification
Maintenance/Repair 0430193-GB Pos : 12.35.3 /9 Wartung/Ins tandsetzung/Warnhinweise,Eti ketten, Aufkl eber/Kennz eichnung Drehric htung @ 0\mod_1264145280970_131.doc x @ 1910 @ 3 @ 1 9.8.2 Rotational direction identification 0430203 Pos : 12.35.4 /9 Wartung/Ins tandsetzung/Warnhinweise,Eti ketten, Aufkl eber/Kennz eichnung: Staubs auger @ 6 \mod_1392113609587_131.doc x @ 53181 @ 3 @ 1 9.8.3 Marking: Vacuum cleaner 0431024... -
Page 35: Wear Parts List
Maintenance/Repair Pos : 14.1 /9 Wartung/Instands etz ung/Verschl eißteile/Ü berschrift: Verschl eißteilliste @ 4\mod_1359018573095_131.doc x @ 37903 @ 2 @ 1 Wear parts list Pos : 14.2 /9 Wartung/Instands etz ung/Verschl eißteile/Kopfzeil e Versc hleiß teil e @ 4 \mod_1359021297472_131.doc x @ 37953 @ @ 1 Figure Designation Order number... -
Page 36: Decommissioning, Storage
Decommissioning, storage 10 Decommissioning, storage Pos : 15.2 /1 Gr undleg ende Si cherheits hinweis e/Sig nal wort-Fel d " Warnung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 15.3 /10 Außer betriebsetz ung, Lagerung/Auß erbetri ebs etz ung, Lager ung Spänesauger @ 0\mod_1269606630081_131.doc x @ 3830 @ @ 1 •... -
Page 37: Disposal
Disposal 11 Disposal Pos : 16.2 /1 Gr undleg ende Si cherheits hinweis e/Sig nal wort-Fel d " Warnung" @ 0\mod_1261404807286_131.doc x @ 893 @ @ 1 WARNING Pos : 16.3 /11 Ents orgung/vorstehendes Kapitel "Außer betriebsetz ung, Lagerung" beac hten! @ 0\mod_1264080817117_131.doc x @ 1847 @ @ 1 •... -
Page 38: Spare Parts List
Spare Parts List 12 Spare Parts List Pos : 18.1 /12 Ers atzteillisten/ET R I-Kompl ettg eräte/Ü berschrift Indus tries aug er T yp RI 331-D-IS-H @ 4\mod_1361457155209_131.doc x @ 40251 @ 2 @ 1 12.1 Industrial suction unit type RI 331-D-IS-H Pos : 18.2 /12 Ers atzteillisten/ET R I-Kompl ettg eräte/Explosi onszei chnung RI 331-D-IS-H @ 4\mod_1361457153803_0.doc x @ 40229 @ @ 1 Pos : 18.3 /12 Ers atzteillisten/ET R I-Kompl ettg eräte/Ü... -
Page 39: 12.3 Ri-Drive Part Ie2 With Motor Protection Switch Pkzm
Spare Parts List Pos : 20.1 /12 Ers atzteillisten/IE2/ET R I-Antriebsteile IE2/Ü berschrift RI- Antriebsei nheit IE2 mit Motorsc hutzs chalter PKZM @ 8\mod_1422265573653_131.doc x @ 75940 @ 2 @ 1 12.3 RI-Drive Part IE2 with motor protection switch PKZM Pos : 20.2 /12 Ers atzteillisten/IE2/ET R I-Antriebsteile IE2/Explosi onszeic hnung RI- Antriebsei nheit D1,5- 4 IE2 PKZM ( 3401041) @ 8\mod_1421929764687_0.doc x @ 75498 @ @ 1 Pos : 20.3 /12 Ers atzteillisten/IE2/ET R I-Antriebsteile IE2/Ü... -
Page 40: 12.4 Ri-Drive Part Ie2 With Motor Protection Switch Pkzm
Spare Parts List 12.4 RI-Drive Part IE2 with motor protection switch PKZM Pos : 20.4 /12 Ers atzteillisten/Kopfzeil e Ersatzteilliste, Pos-M enge- Einheit-Bauteil nummer-Versi on-Bezeic hnung @ 0\mod_1269006032708_131.doc x @ 2858 @ @ 1 Item Qty. Unit Component number Version DESIGNATION Pos : 20.5 /12 Ers atzteillisten/IE2/ET R I-Antriebsteile IE2/T abell e RI- Antriebsei nheit D1,5- 4 IE2 PKZM ( 3401041) @ 8\mod_1421922107250_131.doc x @ 75470 @ @ 1 zwisc hrun d... - Page 41 Spare Parts List Side-channel condenser IE2; 3kW; 400V, 50Hz, piece 0401015 VSC0315-1MP301-6 Side-channel condenser IE2; 4kW; 400V, 50Hz, piece 0401031 VSC0495-2PP401-7 Muffler blow-out hose ø 76 x 800 mm, grey piece 2600289 Wyrem hose ø63mm for 1.5kW / 3.0kW drive piece 0601019 part, 400mm...
- Page 42 Spare Parts List Retaining plate f. Insulating material housing piece 0211294 0041104, with M4 riveting nuts Plate safety note crane transport piece 0430144 Name plate, silver, mass: 88x53 mm (leeres piece 0431006 Formular) Sticker "Next Check" CE-sign mass 36x53 piece 0430174 Pos : 21 /0 Allgemeines /Seitenumbr uc h @ 0 \mod_1265272007940_0.doc x @ 2191 @ @ 1 42/56...
-
Page 43: Spare Parts List/Drawing Chassis Ri 331 Type (2201100)
Spare Parts List Pos : 22.1 /12 Ers atzteillisten/ET Fahrgestell und Grundkons olen/Ü bersc hrift: Ersatzteilliste/Z eic hnung Fahrgestell T yp R I 331 ( 2201100) @ 2\mod_1343715284148_131.doc x @ 19996 @ 2 @ 1 12.5 Spare parts list/drawing chassis RI 331 type (2201100) Pos : 22.2 /12 Ers atzteillisten/ ET Fahrgestell und Grundkons olen/Expl osi ons zeic hnung Fahrges tell T yp R I 331 ( 2201100) @ 2\mod_1343714955740_0.doc x @ 19970 @ @ 1 Pos : 22.3 /12 Ers atzteillisten/ET Fahrgestell und Grundkons olen/Ü... -
Page 44: 12.7 Locking Device
Spare Parts List Pos : 24.1 /12 Ers atzteillisten/ET Fahrgestell und Grundkons olen/Ü bersc hrift Ers atz teil-Lis te/Zeic hnung Hebeei nrichtung @ 1\mod_1308919653989_131.doc x @ 8596 @ 2 @ 1 12.7 Locking device Pos : 24.2 /12 Ers atzteillisten/ET Fahrgestell und Grundkons olen/Expl osi ons zeic hnung Hebeei nrichtung @ 1\mod_1308919795479_0.doc x @ 8603 @ @ 1 Pos : 24.3 /12 Ers atzteillisten/ET Fahrgestell und Grundkons olen/Ü... -
Page 45: Spare Parts List/Drawing Filter Pocket Filter 1.75M² Cat."L" As Or "M" As, (2350201/2350111)
Spare Parts List Pos : 26.1 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift: Ers atz teilliste/Z eic hnung T asc henfilter 1,75m², Kat. " L" as / "M" as(2350201/2350111) @ 1\mod_1292322269089_131.doc x @ 7911 @ 2 @ 1 12.9 Spare parts list/drawing filter pocket filter 1.75m² cat."L" as or "M" as, (2350201/2350111) Pos : 26.2 /12 Ers atzteillisten/ET Filter und Abrüttlung/Expl osionsz eic hnung Tasc henfilter 1,75m², Kat."L"... -
Page 46: Spare Parts List/Drawing Hand Shaker For Pocket Filter (2380188)
Spare Parts List Pos : 28.1 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift Ers atzteilliste/Z eichnung H andabr üttl ung für T asc henfilter ( 2380188) @ 1\mod_1278576097991_131.doc x @ 6102 @ 2 @ 1 12.11 Spare parts list/drawing hand shaker for pocket filter (2380188) Pos : 28.2 /12 Ers atzteillisten/ET Filter und Abrüttlung/Expl osionsz eic hnung H andabrüttlung für Taschenfilter, ( 2380188) @ 1\mod_1278574463877_0.doc x @ 6048 @ @ 1 Pos : 28.3 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift Ers atzteilliste/Z eichnung H andabr üttl ung für T asc henfilter ( 2380188) @ 1\mod_1278576097991_131.doc x @ 6102 @ 2 @ 1 12.12 Spare parts list/drawing hand shaker for pocket filter (2380188) -
Page 47: Spacer Rake For Pocket Filter 1.75/3.2/5.2M², (2381000), (2381001), (2381002)
Spare Parts List Pos : 30.1 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift Ers atzteilliste Distanzrec hen für Tasc henfilter 1,75/3,2/ 5,2m² ,(2381000), ( 2381001) @ 1\mod_1278576448841_131.doc x @ 6120 @ 2 @ 1 12.13 Spacer rake for pocket filter 1.75/3.2/5.2m², (2381000), (2381001), (2381002) Pos : 30.2 /12 Ers atzteillisten/ET Filter und Abrüttlung/Expl osionsz eic hnung Dis tanzr echen für T asc henfilter 1,75/3,2/5,2m², ( 2381001) @ 1\mod_1278574821786_0.doc x @ 6066 @ @ 1 Pos : 30.3 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift Ers atzteilliste Distanzrec hen für Tasc henfilter 1,75/3,2/ 5,2m²... -
Page 48: Spare Parts List/Drawing H14 Filter Assembly (2350179)
Spare Parts List Pos : 32.1 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift Ers atzteilliste H14-Filterbaugruppe (2350179) @ 2\mod_1347623267359_131.doc x @ 26105 @ 2 @ 1 12.15 Spare parts list/drawing H14 filter assembly (2350179) Pos : 32.2 /12 Ers atzteillisten/ET Filter und Abrüttlung/Expl osionsz eic hnung H 14-Filter baugruppe ( 2350179) @ 2\mod_1347622282108_0.doc x @ 26076 @ @ 1 Pos : 32.3 /12 Ers atzteillisten/ET Filter und Abrüttlung/Übersc hrift Ers atzteilliste H14-Filterbaugruppe (2350179) @ 2\mod_1347623267359_131.doc x @ 26105 @ 2 @ 1 12.16 Spare parts list/drawing H14 filter assembly (2350179) Pos : 32.4 /12 Ers atzteillisten/Kopfzeil e Ersatzteilliste, Pos-M enge- Einheit-Bauteil nummer-Versi on-Bezeic hnung @ 0\mod_1269006032708_131.doc x @ 2858 @ @ 1... -
Page 49: Collection Container 50 Litres, V2A. With 3 Casters (2100349)
Spare Parts List Pos : 34.1 /12 Ers atzteillisten/ET Sammel behälter/Ü berschrift Ersatzteilliste Sammel behälter 50 Liter , V2A @ 1\mod_1278575649946_131.doc x @ 6090 @ 2 @ 1 12.17 Collection container 50 litres, V2A. with 3 casters (2100349) Pos : 34.2 /12 Ers atzteillisten/ET Sammel behälter/Explosi onsz eichnung Sammelbehälter 50 Liter, V2A, (21 00349) @ 1\mod_1278574190813_0.doc x @ 6036 @ @ 1 Pos : 34.3 /12 Ers atzteillisten/ET Sammel behälter/Ü... -
Page 50: Spare Parts List/Drawing Collection Container Type Ri 331 (334)
Spare Parts List Pos : 36.1 /12 Ers atzteillisten/ET Sammel behälter/Ü berschrift: Ersatzteilliste/Zei chnung Sammelbehälter T yp R I 331 / RI 334 @ 2\mod_1343717150303_131.doc x @ 20022 @ 2 @ 1 12.19 Spare Parts List/Drawing Collection Container Type RI 331 (334) Pos : 36.2 /12 Ers atzteillisten/ET Sammel behälter/Explosi onsz eichnung Sammelbehälter T yp R I 331 / RI 334 (2100119) @ 2 \mod_1343716742575_0.doc x @ 20005 @ @ 1 Pos : 36.3 /12 Ers atzteillisten/ET Sammel behälter/Ü... -
Page 51: Spare Parts List Suction Hose Dn 40, All Types (2600484-Z)
Spare Parts List Pos : 38.1 /12 Ers atzteillisten/ET Zubehör/Übersc hrift: Expl osionsz eichnung Saugsc hlauc hei nheit DN 40, all e T ypen @ 0\mod_1269843532586_131.doc x @ 3914 @ 2 @ 1 12.21 Spare Parts List Suction hose DN 40, all Types (2600484-Z) Pos : 38.2 /12 Ers atzteillisten/ET Zubehör/Expl osionsz eic hnung Saugsc hlauc hei nheit DN 40 all e T ypen @ 0\mod_1269845511390_0.doc x @ 3974 @ @ 1 Pos : 38.3 /12 Ers atzteillisten/ET Zubehör/Übersc hrift: Ers atz teilliste Saugsc hlauchei nheit DN 40, all e T ypen @ 0\mod_1269843676164_131.doc x @ 3920 @ 3 @ 1 12.21.1 Spare Parts List Suction hose DN 40, all Types (2600484-Z) -
Page 52: Spare Parts List Suction Hose Dn 50, All Types (2600398-Z)
Spare Parts List Pos : 40.1 /12 Ers atzteillisten/ET Zubehör/Übersc hrift: Expl osionsz eichnung Saugsc hlauc hei nheit DN 50, all e T ypen @ 0\mod_1269843791774_131.doc x @ 3932 @ 2 @ 1 12.22 Spare Parts List Suction hose DN 50, all Types (2600398-Z) Pos : 40.2 /12 Ers atzteillisten/ET Zubehör/Expl osionsz eic hnung Saugsc hlauc hei nheit DN 50 all e T ypen @ 0\mod_1269845365315_0.doc x @ 3968 @ @ 1 Pos : 40.3 /12 Ers atzteillisten/ET Zubehör/Übersc hrift: Ers atz teilliste Saugsc hlauchei nheit DN 50, all e T ypen @ 0\mod_1269843737742_131.doc x @ 3926 @ 3 @ 1 12.22.1 Spare Parts List Suction hose DN 50, all Types (2600398-Z) -
Page 53: 12.22.2 Spare Parts List Suction Hose Dn 70, All Types
Spare Parts List Pos : 42.1 /12 Ers atzteillisten/ET Zubehör/Übersc hrift: Ers atz teilliste Saugsc hlauchei nheit DN 70, all e T ypen @ 2\mod_1346141681479_131.doc x @ 21417 @ 3 @ 1 12.22.2 Spare Parts List Suction hose DN 70, all Types Pos : 42.2 /12 Ers atzteillisten/ET Zubehör/Expl osionsz eic hnung Saugsc hlauc hei nheit DN 70 all e T ypen @ 2\mod_1346133452090_0.doc x @ 21400 @ @ 1 Pos : 42.3 /12 Ers atzteillisten/ET Zubehör/Übersc hrift: Ers atz teilliste Saugsc hlauchei nheit DN 70, all e T ypen @ 2\mod_1346141681479_131.doc x @ 21417 @ 3 @ 1 12.22.3 Spare Parts List Suction hose DN 70, all Types... -
Page 54: 12.23 Accessories List
DN 50 (2610108) Pos : 44.8 /12 Ers atzteillisten/ET Zubehör/Weiter e Z ubehörteile finden sie auf der Internets eite der Fir ma Ringler oder im Zub ehör katal og @ 4\mod_1358841348021_131.doc x @ 37707 @ @ 1 Additional accessories can be found on the website of the company or Ringler in the accessories catalog. -
Page 55: Component Documentation
Component documentation 13 Component documentation Pos : 46 /13 Anhang, Komponentendokumentati on/Dokumentation Seitenkanal ver dic hter @ 0\mod_1268647256807_131.doc x @ 2793 @ 2 @ 1 13.1 Documentation for side-channel compressor comprising the following pdf documents: BA-0001-DE Operating instructions for types 2BH11/12/13/14/15/16/18/19 Pos : 47 /13 Anhang, Komponentendokumentati on/Dokumentation Differ enz druc ksc hal ter - Tec hnische D aten @ 0\mod_1268658841638_131.doc x @ 2799 @ 2 @ 1 13.2 Documentation for differential pressure switch - Technical data comprising the following pdf document:... -
Page 56: Eec-Declaration Of Conformity
Serialnumber: 998xxxxx Year of construction: 12.2015 Pos : 48.5 /14 EG- Konfor mitäts er klärungen/hergestellt von: @ 0\mod_1264157714993_131.doc x @ 1982 @ @ 1 Ringler GmbH Person authorized for the compilation produced by: of technical documents Robert Bosch Straße 4-8...
