Jason International MicroSilk Assembly

"TO BE REMOVED FOR USE BY THE OCCUPANT."
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
MADE IN THE U.S.A.
note: these instructions can also be found in the
Installation, operation and Maintenance manual of the
separately packaged MicroSilk
Wa r n I n g : Sy S t e M U n d e r P r e S S U r e –
never PerforM MaIntenance WhIle SySteM
IS rUnnIng.
MIcroSIlk ® PUMP aSSeMbly
Figure 1
®
The Jason MicroSilk system has been factory assembled
following ETL and IAPMO guidelines. For shipping purposes,
the MicroSilk ® Pump Assembly may be packaged separately
and disconnected from the bath.
note: Verify the MicroSilk
unit that was provided for the bath being installed. The serial
number listed on the label provided on the MicroSilk
Assembly carton should match the serial number of the bath.
WarnIng: any modification to the equipment is
not recommended and will voId the manufacturer's
warranty.
Jason International, Inc. • 501.771.4477
INSTRUCTION MaNUal
MicroSilk
Field Installation
® therapy bath unit.
®
Pump Assembly is the same
®
Pump assembly
®
To install the MicroSilk
following procedures must be followed.
note: Do not install the MicroSilk
than the length of the tubing that is factory installed on the
bath. These tubing lengths have been designed for proper
drainage of the system.
1. Position the bath in the area of intended installation.
2. Before beginning any work, the installer is to determine
the proper location of the MicroSilk
and service access.
3. Do not disconnect the plumbing lines that are secured
to the bath with nylon tie straps (figure 2).
Figure 2
Pump
Page 1 of 2
49-2001-002
Date 11/14
® Pump Assembly to the bath, the
®
Pump Assembly further
® Pump Assembly
Customer Service : 800.255.5766
