Summary of Contents for Jindara Spectre
- Page 1 Spectre Module Spectre Module Operation & Installation Instructions Rev * Please keep these instructions for future reference. 234965 AF Gason Pty. Ltd. reserves the right to modify or alter speci cations, material, etc. in the interest of product improvement.
- Page 2 Spectre Module Spectre Module Removing heater from pallet: • Remove front ll panels on either side of the appliance by backing o 2x retaining screws and lifting up. Troubleshooting (Continued) • Remove 4x tek-screws holding appliance to transport pallet. Read and follow these instructions carefully before installing and •...
- Page 3 Flue requirements 10% moisture As per the dimensions in Figure 1, the Jindara Spectre can be installed with a Perforated 7” Default Flue Kit, or Figure 2, 88% thermal e ciency a Solid 7” Default Flue Kit. In both instances, an additional 8” solid ue must be tted between the inner ue and outer ue, to the height of the ceiling if any part of the unit is to be installed less than 1200mm from a heat sensitive surface.
-
Page 4: Troubleshooting
(dimensions in mm) Squeeze locator tabs together on the rear of the thermostat switch and push through outside of pedestal. Disconnect the wiring from the power lead and remove the fans. Convey the same to the authorised Jindara dealer from Minimum whom you purchased your unit for service. - Page 5 All installations must conform as per dimensions on page 4, when installing on or adjacent to combustible materials. Under all circumstances, if installing the Jindara Spectre Module on a bench above a oor comprising of combustible material, a minimum 6mm thick non-combustible...
- Page 6 Spectre Module Spectre Module Installation Maintaining & Servicing your Jindara (continued) (continued) Ba e System Figure 11 WARNING If the ba e system is damaged, burnt out, discarded or not installed as per these instructions, high ue temperatures, losses in combustion e ciency and excess smoking can occur.
- Page 7 The ue pipe shall extend not less than 4.6m above the top of the oor protector. Note: Installation must be ue brush from your local Jindara Dealer and proceed to the top of the ue. Remove the ue cowl. Slowly push the carried out by a licensed installer in accordance with AS/NZS 2918:2001.
- Page 8 Operating your Jindara (continued) Fan operation Your Jindara Spectre is equipped with a temperature-sensitive thermostat switch located within the heater’s pedestal beneath DO NOT ATTEMPT TO OPERATE THIS APPLIANCE WITHOUT READING AND WARNING the rebox, which when selected will turn the fan on and o depending on the temperature of the rebox.
