amiGO!
#1
PRODUCT
dash cam
LEADER
YOUR FRIEND ON THE ROAD!
Developed with
professional truckers
for the highest quality
dash camera!
· DASH CAMERA INSTALL QUICK START GUIDE
High De nition Dash Camera
with GPS Tracking, G-Sensor
· DASHCAM VIEWER SOFTWARE INSTALL
& Viewing Software
QUICK START GUIDE
Model# DC711
· DASH CAMERA USER MANUAL
Advertisement
Table of Contents
Related Manuals for Amigo DC711
Summary of Contents for Amigo DC711
- Page 1 · DASH CAMERA INSTALL QUICK START GUIDE High De nition Dash Camera with GPS Tracking, G-Sensor · DASHCAM VIEWER SOFTWARE INSTALL & Viewing Software QUICK START GUIDE Model# DC711 · DASH CAMERA USER MANUAL...
-
Page 2: Table Of Contents
Table of Contents Dash Camera Install Quick Start Guide ..............Page 3-6 • Camera Installation ........Page 3 • Time Zone & Date/Time Settings .... Page 4 • Bracket Rotation/Angle Adjustment ..Page 3 • Hardwiring ..........Page 5 • GPS Cable Module ........Page 4 •... -
Page 3: Dash Camera Install Quick Start Guide
DASH CAMERA INSTALL QUICK START GUIDE Bracket rotation/angle adjustment: Installation: Camera installation Front of Right side of camera camera Install Remove Windshield Up and Down Rotation: Loosen the bracket nut on the side plate of the bracket then adjust up and down to the appropriate angle (the maximum is 135). -
Page 4: Time Zone & Date/Time Settings
GPS Cable Module: installation, removal Power Cable: installation, removal Back of Right side of camera and camera vehicle accessory port GPS module: Insert the GPS cable into the top-left side of Power cable: Insert the Data cable end into the power port the camera bracket to receive GPS signals. -
Page 5: Hardwiring
HARDWIRING CONNECTION TO 24V/18V/12V VEHICLE CHARGER Connecting to a vehicle’s accessory port, the dash camera will begin to record automatically upon receiving power: • Always-on accessory port: Camera on, will continuously record. • Ignition-based accessory port: Camera will turn on/record and stop recording/turn off based on the vehicle’s ignition. If hardwiring (kit not included), please note camera operation above and wire according to desired recording style. -
Page 6: Changing The Micro Memory Card
By default, this camera is set up to automatically begin recording upon starting the vehicle. Camera will stop recording a duration after turning off the vehicle unless plugged into an always-on accessory port, in which case it will continue recording. For full instructions, please refer to the Dash Camera User Manual. ! IMPORTANT ! CHANGING THE MICRO MEMORY CARD Your camera is pre-loaded with a Micro Memory Card. -
Page 7: Dashcam Viewer Software Install Quick Start Guide
DASHCAM VIEWER SOFTWARE INSTALL QUICK START GUIDE Your dash camera is preloaded with Dashcam Viewer software that allows you to watch video footage, track your route and more on your computer. See below for full installation instructions (Windows only). Recommended system requirements: Windows 10, 64-bit, i7 processor, Nvidia or AMD video adapter. - Page 8 For full Dashcam Viewer instructions, please refer to the PDF manual located in the Dashcam Viewer installation folder on your PC or go to Help > User Manual in the Dashcam Viewer program. (A PDF reader program is required - not included.) For technical questions about the amiGO! Dash...
-
Page 9: Dash Camera User Manual
DASH CAMERA USER MANUAL Instructions before use This User Manual will describe the usage of this product in detail and at the same time provide comprehensive information including operation and specifications, etc. Please read the manual carefully and keep it in a safe location for future reference. CHECK PRODUCT ACCESSORIES Please check whether the following accessories are present before use: •... -
Page 10: Button Operation
BUTTON OPERATION LED INDICATORS 1. POWER BUTTON (PD Icon 9): 1. RED LIGHT - CHARGING (PD Icon 4): • Press to turn the power on. • When the battery requires charging, the light will be solid red. • During normal camera operation, press and hold to turn off. •... -
Page 11: Viewscreen Icons
GETTING TO KNOW YOUR DASH CAMERA VIEWSCREEN ICONS: Record Time: Shows amount of time camera has been recording Recording: Red dot will blink on and off when recording GPS: External GPS cable/module required. A red “G” and an “X” will show when no GPS signal is received. A green “G” will appear when a GPS signal is achieved. -
Page 12: Normal Camera Operation
NORMAL CAMERA OPERATION By default, this camera is set up to automatically begin recording upon starting the vehicle. This will happen with the following conditions: 1) Micro Memory Card is correctly installed, 2) the vehicle power cable is plugged in via the power port on the top of the camera (PD icon 1) and the car charger plug is 3) inserted into the accessory port in the vehicle or 4) hardwired to the vehicle. -
Page 13: Menu Selections (P2/5Cont - P3/5)
Image Quality Select the quality of image that will be taken. S.Fine (Super Fine) will take the most pixels; Normal will take the least. More pixels means a higher quality image. MENU Button 【Image Quality】 【S.Fine】/【Fine】/【Normal】 EV (Auto Exposure) If EV is adjusted to + (right) side, you can avoid under-exposure or dark objects as shooting against a bright background. If EV is adjusted to – (left) side, then you can avoid over-exposure or bright objects as shooting against a dark background or at night. -
Page 14: Menu Selections (P4/5 - P5/5)
MENU (P 4/5): Record Interval The dash camera is set to record in segments of 3 or 5 minutes. These videos will record to the full limit of the memory card. Upon writing the full memory available, the new videos will overwrite the old data in order to achieve non-interrupted recording. -
Page 15: Micro Memory Card Maintenance
MICRO MEMORY CARD MAINTENANCE Your camera is pre-loaded with a Class 10, MLC Micro Memory Card. The card has been pre-formatted to optimize performance on the dash camera. As large files are constantly being written and over-written, proper maintenance may be required regularly to optimize the Micro Memory Card’s performance. Without doing so, this may lead to fragmentation, slower write speeds, file corruption or card failure. - Page 16 DC711 IIC Inc. Instant Imaging Corporation 1935 Stonebridge Rd West Bend, WI 53095 InstantImagingCorp.com | (262) 334-7777 | info@instantimagingcorp.com Camera made in China. Bundled Dashcam Viewer software made in the U.S.A. © Instant Imaging Corporation (IIC Inc.)
