PRODUCT
LEADER
Developed with
professional truckers
for the highest quality
dash camera!
Included
in this
32GB
Package
Micro
Quick Start Guide/
Memory Card
User Manual
Micro Memory
GPS Viewer
Card Reader
Software (PC/Mac)
amiGO!
dash cam
· DASH CAMERA INSTALL QUICK START GUIDE
· DASHCAM VIEWER SOFTWARE INSTALL
QUICK START GUIDE
· DASH CAMERA USER MANUAL
Data/Power
GPS
Cable
Module
DC710
1296P
UP TO
HD
REC
170° Wide Angle Lens
GPS and G-Sensor
Motion Detection/Always-On
UP TO
33-hour Loop-Recording
miniTV-Out
Vehicle Power
Windshield
Cable
Plate
*
Windshield
Suction Cup
Advertisement
Related Manuals for Amigo DC710
Summary of Contents for Amigo DC710
- Page 1 PRODUCT LEADER dash cam DC710 Developed with professional truckers for the highest quality dash camera! · DASH CAMERA INSTALL QUICK START GUIDE · DASHCAM VIEWER SOFTWARE INSTALL QUICK START GUIDE · DASH CAMERA USER MANUAL 1296P UP TO 170° Wide Angle Lens...
- Page 3 Table of Contents Dash Camera Install Quick Start Guide .......... Page 4-6 Dashcam Viewer Software Install Quick Start Guide ....Page 7-8 Dash Camera User Manual .............. Page 9-14 Micro Memory Card Maintenance ..........Page 15 Questions? Comments? Contact Instant Imaging Corporation (IIC Inc.): (262) 334-7777 / info@instantimagingcorp.com Product Guarantee and Limitation of Liability This product is approved by ISO9001:2000 International Quality Standard and certified with FCC, CE and SGS.
-
Page 4: Dash Camera Install Quick Start Guide
Turn the camera on Press Menu > TimeZone then adjust with the Up and Down arrows based on the TimeZone table below. DC710 Confirm with the OK button. Set the date/time: Press Menu > Dash Camera Settings (gear icon) > Time Setup then adjust the time accordingly. - Page 5 Bracket rotation/angle adjustment: If the recording position is not appropriate, it can be adjusted up, down, left and right. Right side of Right side of camera camera Up and Down Rotation: Loosen the bracket nut on the right Left and Right Rotation: You can rotate the angle of the side of the bracket then adjust up and down to the appropriate device directly (the maximum angle is 200) without angle (the maximum is 180).
- Page 6 By default, this camera is set up to automatically begin recording upon starting the vehicle. Camera will stop recording a duration after turning off the vehicle unless plugged into an always-on accessory port, in which case it will continue recording. For full instructions, please refer to the Dash Camera User Manual. ! IMPORTANT ! CHANGING THE MICRO MEMORY CARD Your camera is pre-loaded with a Micro Memory Card.
-
Page 7: Dashcam Viewer Software Install Quick Start Guide
DASHCAM VIEWER SOFTWARE INSTALL QUICK START GUIDE Your dash camera is pre-loaded with Dashcam Viewer software that allows you to watch video footage, track your route and more on your computer. See below for full installation instructions (Windows or Mac). Recommended system requirements: Windows 10, 64-bit, i7 processor, Nvidia or AMD video adapter. - Page 8 For full Dashcam Viewer instructions, please refer to the e-manual located in the Dashcam Viewer installation folder on your PC/Mac or go to Help > User Manual in the Dashcam Viewer program. (E-manual reader program is required - not included.) For technical questions about the amiGO! Dash Cam or Dashcam Viewer software, please contact (262) 334-7777 or email info@instantimagingcorp.com.
-
Page 9: Dash Camera User Manual
DASH CAMERA USER MANUAL Instructions before use This User Manual will describe the usage of this product in detail and at the same time provide comprehensive information including operation and specification, etc. Please read the manual carefully and keep it in a safe location for future reference. CHECK PRODUCT ACCESSORIES Please check whether the following accessories are present before use: 32GB Micro Memory Card (High Speed 10) x 1... - Page 10 GETTING TO KNOW YOUR DASH CAMERA VIEWSCREEN ICONS: Movie Camera Icon: Indicates camera is in Video Recording Mode. Camera Icon: Indicates camera is in Photo Mode. Battery: Indicates the remaining power for the device. Charge your camera when the power is low. Plug icon shows while charging and top red LED lights.
- Page 11 ACCESSING FILES VIA A PC OR MAC: 1) Connect the dash camera to a PC or Mac with the included Data cable via the Data Port on the right side of the camera. (PD Icon 15). DO NOT use the DC IN port at the right side of the camera bracket.
- Page 12 *** UNDERLINE DENOTES DEFAULT FACTORY SETTINGS *** VIDEO RECORDING MODE (MOVIE CAMERA ICON): By default, this camera is set up to automatically begin recording upon starting the vehicle. This will happen with the following conditions: 1) Micro Memory Card is correctly installed, 2) the Vehicle Power cable is plugged in via the DC IN port on the camera bracket and the car charger plug is 3) inserted into the accessory port in the vehicle or 4) hardwired to the vehicle.
- Page 13 Loop Setting The dash camera is set to record in segments of 1, 3, or 5 minutes. These videos will record to the full limit of the memory card. Upon writing the full memory available, the new videos will overwrite the old data in order to achieve non-interrupted recording. MENU Button【Loop Setting】/【1 minute】/【3 minutes】/【5 minutes】...
- Page 14 Image Quality Select the quality of image that will be taken. S.Fine (Super Fine) will take the most pixels; Normal will take the least. More pixels means a higher quality image. MENU Button 【Image Quality】 【S.Fine】/【Fine】/【Normal】 Stamp Setting When Stamp is set ON, date/time/plate number (preset) will appear on images. MENU Button 【Date Stamp Setting】...
-
Page 15: Micro Memory Card Maintenance
MICRO MEMORY CARD MAINTENANCE Your camera is pre-loaded with a High Speed 10, MLC Micro Memory Card. The card has been pre-formatted to optimize performance on the dash camera. As large files are constantly being written and over-written, proper maintenance may be required regularly to optimize the Micro Memory Card’s performance. Without doing so, this may lead to fragmentation, slower write speeds, file corruption or card failure. - Page 16 DC710 IIC Inc. Instant Imaging Corporation 1935 Stonebridge Rd West Bend, WI 53095 InstantImagingCorp.com | (262) 334-7777 | info@instantimagingcorp.com Camera made in China. Bundled Dashcam Viewer software made in the U.S.A. © Instant Imaging Corporation (IIC Inc.)
