Kenwood VGS-1 Service Manual

Voice guide & storage unit.
Hide thumbs


Advertisement

VOICE GUIDE & STORAGE UNIT
VGS-1
SERVICE MANUAL
SUPPLEMENT
DISASSEMBLY FOR REPAIR .................................................................... 2
CIRCUIT DESCRIPTION ............................................................................ 2
COMPONENTS DESCRIPTION ................................................................. 3
PARTS LIST ............................................................................................... 3
PC BOARD
ACCESSORY UNIT (X42-3250-60) ........................................................ 5
SCHEMATIC DIAGRAM ............................................................................ 6
TERMINAL FUNCTION ........................................................ BACK COVER
This product complies with the
RoHS
This service manual has been revised due to the modifi cation of the
PC board and issues it as a supplemental manual.
Refer to the VGS-1 service manual (B51-8669-00) for any informa-
tion which has not been covered in this VGS-1 service manual.
CONTENTS
directive for the European market.
© 2009-5 PRINTED IN JA PAN
B51-8873-00 ( N ) PDF
This product uses Lead Free solder.
