SERVICE MANUAL V1.0
MWS-808PMO Wire Stripper
Removing/Replacing Electric Motor
CAUTION!! IMPORTANT!! DANGER!! WARNING!!
DISCONNECT MACHINE FROM POWER BEFORE PROCEEDING!!
PROCEDURE SHOULD BE PERFORMED BY A QUALIFIED
ELECTRICIAN
Estimated Completion Time: 30 Minutes
Tools Required
8mm Hex Wrench
14mm Wrench
Adjustable Wrench
#2 Phillips Screwdriver
© THE NEWMAN TRADING COMPANY LLC DBA BLUEROCK® TOOLS 2018
1100 SW 16 St • Suite D Renton, WA 98057
Phone 206.604.8363 • Fax 425.572.5167
www.bluerocktools.com
Advertisement
Table of Contents
Related Manuals for Bluerock Tools MWS-808PMO
Summary of Contents for Bluerock Tools MWS-808PMO
- Page 1 SERVICE MANUAL V1.0 MWS-808PMO Wire Stripper Removing/Replacing Electric Motor CAUTION!! IMPORTANT!! DANGER!! WARNING!! DISCONNECT MACHINE FROM POWER BEFORE PROCEEDING!! PROCEDURE SHOULD BE PERFORMED BY A QUALIFIED ELECTRICIAN Estimated Completion Time: 30 Minutes Tools Required 8mm Hex Wrench 14mm Wrench Adjustable Wrench #2 Phillips Screwdriver ©...
- Page 2 1. Locate the capacitor box on the back side of the machine and remove the 4 screws holding the cover using a Phillips #2 screwdriver. 2. Take note of the wiring arrangement inside the capacitor box and take pictures for use during reassembly.
- Page 3 4. Use an adjustable wrench to loosen the cord grip located on the top of the capacitor box and pull the power cord out. 5. Use a 14mm wrench to loosen 2 bolts under the motor controller and remove it from the machine.
- Page 4 6. Use an 8mm hex wrench to remove 4 bolts from the base of the motor. Note: The nuts may fall from the lower side of the flange when removing the bolts. 7. Lift the motor away from the machine. Important: Be sure to remove the key if it does not come out with the motor.
- Page 5 Reassembly 8. Insert key in keyway slot of the motor shaft. Note: If the key does not stay in the slot, use a dab of grease to help it stick during reassembly. 9. Align the motor and transmission keyways. Slowly slide the motor down until the motor flange is flush with the transmission.
- Page 6 13. Reference step 3 to wire the motor. Be sure to tighten all electrical connections. 14. Tighten the cord grip using an adjustable wrench until it is tight around the cord. 15. Install capacitor cover and tighten the 4 screws with a #2 Phillips screwdriver. 16.
