Iron & Bronze Booster Pumps
INSTALLER: PLEASE LEAVE THIS MANUAL FOR THE OWNER'S USE.
DESCRIPTION
Bell & Gossett Booster Pumps feature oil lubricated sleeve
bearings, a carbon/ceramic seal and a noise dampening spring
coupler. Bell & Gossett Booster Pump motors are designed
specifically for quiet operation and are built with thermal pro-
tection and drip-proof construction. The motor is non-
over-loading at any point on the pump curve.
This pump is nonsubmersible, for indoor use only.
PUMP APPLICATION
Bell & Gossett Pumps may be used for water circulating appli-
cations in hydronic, solar and chilled water systems. Bell &
Gossett recommends that bronze constructed pumps be used
for pumping potable water. For other applications contact your
local Bell & Gossett Representative. Note that some local
codes require using a check valve in the supply line when recir-
culating potable water.
It has not been investigated, nor is it intended for use in swim-
ming pool and marine areas.
OPERATIONAL LIMITS
These pumps are designed to pump liquids compatible with
their iron or bronze body construction. Unless special provi-
sions have been made by ITT Bell & Gossett, the operational
limits for Series 100, HV, PR and 2" Pumps are listed below.
Do not exceed these values.
Maximum Working Pressure:
Maximum Operating Temperature: 225ºF
Electrical Rating:
Motors with special electrical characteristics are available on
request. Contact your local Bell & Gossett Representative for
details.
125 psi
115V, 60 Hz, 1PH
INSTRUCTION MANUAL
Series 2"
SAFETY
INSTRUCTIONS
This safety alert symbol will be used in this manual and on the
pump instructions decal to draw attention to safety related
instructions. When used, the safety alert symbol means
ATTENTION! BECOME ALERT! YOUR SAFETY IS INVOLVED!
FAILURE TO FOLLOW THE INSTRUCTIONS MAY RESULT IN
A SAFETY HAZARD.
WARNING
BEFORE INSTALLING, USING OR
SERVICING THIS PRODUCT,
READ THE WARNING NOTES
AND INSTRUCTIONS IN
INSTRUCTION MANUAL.
FAILURE TO DO SO MAY
RESULT IN SERIOUS INJURY
OR PROPERTY DAMAGE
V56845
Your Booster Pump should have these warning labels affixed
near the conduit box cover. If these warnings are missing or
illegible, contact your local Bell & Gossett Representative for
replacement labels.
P81748F
WARNING
RISK OF ELECTRIC SHOCK;
THIS PUMP HAS NOT
BEEN INVESTIGATED FOR
USE IN SWIMMING POOL
AND MARINE AREAS.
-NONSUBMERSIBLE PUMP-
