Baldwin 5080 Series Installation Instructions

PK.2716
Interior Latchset

Installation Instructions

Passage, Privacy, Full & Half Dummy
DOOR PREPARATION: PASSAGE & PRIVACY LATCHSETS ONLY
2. Caution: Recheck
1. Fold the template
bore hole locations
on the line and
before drilling. Drill
locate on at desired
the 2-1/8" Face Bore
height (about 40"
through the door first.
from floor). Place
Drill the 1" diameter
folded edge on low
Edge Bore through
side of door bevel.
to the inside of the
Mark holes on door
2-1/8" Face Bore.
for appropriate
For 5" & 10" rose
backset, rose style
styles, mark but do
and size.
not drill pilot holes
for #8 surface mount
screws. This will be
done in a later step.
TEMPLATE 1" DIA.
EDGE
BORE
HALF DUMMY INSTALLATION
BACKPLATE
FLAT HEAD
SCREWS
RETAINER
*Note: #8 Oval Head Screws are not required on 3" rose styles.
SET SCREW
STRIKE
PLATE
4. Chisel out the
3. Insert the latch
area marked in step
into the edge of
3 to a depth of 5/32"
the door. Trace
an outline of the or until faceplate
is flush with door
faceplate onto the
edge. Proceed to
door edge. Mark
Passage or Privacy
screw hole center
locations and drill installation.
1/8" pilot holes.
2-1/8"
FACE
BORE
1. Locate the posi-
tion for hole in door.
If not used with a
ROSE
double door, the
hole location should
be approx. 40" from
#8 X 3/4" OVAL
floor. Drill a 5/8"
HEAD SCREWS
hole ¼" deep one
(*See note.)
side of the door
DO NOT DRILL
KNOB THROUGH DOOR.
SET SCREW
KNOB
ROSE
OUTSIDE
ADAPTOR
#8 X 3/4"
COMBINATION
SCREWS
FACE
PLATE
ALIGNMENT
BUSHING
STRIKE PREPARATION: PASSAGE & PRIVACY LATCHSETS ONLY
1. Using the strike
portion of the
marking template,
locate and mark
strike mounting
screws and
centering points for
your door thickness.
2. Place backplate on door so that the flat
surface is toward the floor. The flat surface
should be parallel to the floor and perpen-
dicular to the door edge. A builder's square
should be used for best results. Using the
backplate as a template, mark center locations
for (3) screw holes.
Remove backplate and pre-drill (3) holes for
screws ½" deep using a 1/16" drill bit. Install
backplate with (3) flat head screws provided.
MARK LOCATION
OF 3 SCREW HOLES
BACKSET DIMENSION
(2-3/8" OR 2-3/4")
*Note: #8 Oval Head Screws are not required on 3" rose styles.
1-1/4"
FLAT HEAD
INSIDE
LATCH
SCREWS
ADAPTOR
ROSE
THREADED STUD
(Privacy Version)
PRIVACY
BUTTON EXTENSION
(PRIVACY VERSION)
EMERGENCY KEY
(PRIVACY VERSION)
2. Align the strike
3. At the screw
and trace outline
marks, drill (2) 1/8"
onto the door frame
dia. pilot holes for
using mounting the screws. Bore
screw marks for
7/8" dia. X 3/4"
location.
deep hole.
EDGE BORE
1/8" PILOT HOLES
FOR #8 SCREWS
3. Attach the roses
by screwing the
threaded retainer
onto the adaptors.
Orient the rose as
desired and securely
tighten by using the
spanner tool.
For 5" & 10" roses,
ensure rose is paral-
lel with door edge
and drill 3/32" x 1/2"
deep pilot holes at
marked locations.
Install #8 oval head
screws into door.
SPANNER TOOL
5" & 10" roses may
be installed as shown.
#8 X 3/4" OVAL
HEAD SCREWS
(*See note.)
RETAINER
NYLON WASHER
PRIVACY BUTTON
ALLEN
(PRIVACY VERSION)
WRENCH
4. Chisel out the
area marked in
step 2 to a depth of
1/16" or until strike
is flush with door
frame.
Install strike using
(2) #8 Flat Head
combination screws.
7/8"
4. Orient the
knob or lever so
the set screw is
pointed down
& toward the
hinges of the
door. Slide the
knob or lever
onto the end
of the spindle
until it touches
the adaptor and
secure with set
screw.
