QUICK-START

1. POWER OVERVIEW

Striker operates on the internal 3.0V watch type battery
(#CR2032). If possible, install Striker to the vehicle's
electrical system. Striker is polarity independent and has
safeguards to avoid draining the vehicle battery. See the
Power Connection section for more info.
Installing the power wire enables a brighter backlight,
longer sleep timer, and the voltage and
Aluminum
temperature indicator LED's.
Included
Protector Mount
Handlebar
(optional)
Mount

2. MOUNT STRIKER:

Striker is made to be bolted to the vehicle. Use
the included handlebar mounts, or refer to the
manual.

3. VEHICLE SENSORS:

Refer to the sensor installation sections.
You should install the wheel sensor,
engine temperature sensor, and
vehicle power connection.
Power Wire Temperature Wheel Speed
Sensor (varies) Sensor (varies)

4. INDICATOR LIGHTS:

Striker has two colored LED lights at the top. They are activated when temperature goes above the threshold, or voltage goes below threshold,
to warn you about potential problems with your vehicle. The left LED is yellow, the right LED is red. When the voltage is low the LED will flash, if
the temperature is high then the LED will turn on solid. Set custom thresholds in the DATA SETTING MODE.
Set the thresholds to 0 to turn them off.

5. SLEEP MODE:

If Striker sees no activity (either wheel movement or a button press) for 5 minutes, it will enter sleep mode and only display the clock. Sleep
mode will end when any activity is noticed. During sleep mode Striker is using the internal battery and will not draw down vehicle power.

6. MAINTENANCE ICONS AND LO BATTERY:

There are two separate maintenance timers: a WRENCH and an OIL CAN. Set the mileage in DATA SETTING MODE, then Striker will
countdown the miles. When the mileage countdown reaches 0, the icon is displayed. If the internal watch battery voltage gets too low, then
Striker displays a LO icon.
