- Page 1 AcuPower-120CDZ IP67 Rated Rugged Power Supply User Guide Published: November 2018 Version 1.0...
-
Page 2: Copyright
All Rights Reserved – Printed in Acura Embedded Systems Inc. Disclaimer Acura Embedded Systems Inc shall not be liable for technical or editorial errors or omissions contained here; nor for incidental or consequential damages resulting from using this material, or the performance or use of this product. -
Page 3: Table Of Contents
Technical Specification .......................... 5 Physical Dimensions ..........................6 System Setup ..............................8 Exploring AcuPower-120CDZ ........................8 I/O Connector ............................8 AC Input (100 – 120V AC) – 3pin male ....................8 DC Output (24V 5A) – 4pin female ......................9 I/O Connection ............................ -
Page 4: General Information
General Information Introduction AcuPower-120CDZ is a AC-DC/DC-DC Power Supply that supplies 24-28 V and 120W outputs. It is a Class 1 Division 2 Approved Power Supply and is certified for use in hazardous locations where fire or explosion hazards may exist due to flammable gases or vapors, flammable liquids, combustible dust, or ignitable fibers. -
Page 5: Technical Specification
AcuPower-120CDZ Technical Specification System Size / Type 120W Switching Power Supply DC Output Voltage 24V/5A Input Voltage Range 100-240V 2.6/1.4A Efficiency Environment Operating Temp. -30ºC to 70ºC (-22ºF to 158ºF) Storage Temp. -40ºC to 85ºC (-40ºF to 185ºF) Relative Humidity <90% (Non-Condensing) -
Page 6: Physical Dimensions
AcuPower-120CDZ Physical Dimensions... - Page 7 AcuPower-120CDZ...
-
Page 8: System Setup
System Setup Exploring AcuPower-120CDZ AcuPower-120CDZ is a high efficiency, rugged power supply with an Input Voltage range 100-240V, 2.6/1.4A and supplies 24V DC output. It is also tested and certified to the NEMA6 and IP67 standard, and it is the ideal solution to provide power in harsh conditions or locations. -
Page 9: Dc Output (24V 5A) - 4Pin Female
AcuPower-120CDZ DC Output (24V 5A) – 4pin female Detail Wire Color Black Green... -
Page 10: I/O Connection
AcuPower-120CDZ I/O Connection To device (4pin female) DC Cable AC Cable From AC To DC To AC Source Output Input (4pin male) (3pin female) -
Page 11: Dc Cable
AcuPower-120CDZ DC cable Detail Wire Color Black Green 4pin female 4pin male (to (to computer) AcuPower) AC cable Detail Wire Color Line Black Ground Green Neutral White 3pin female AC Plug (to AcuPower) - Page 12 With the unique set of products, Acura Embedded Systems remains committed to its goal of providing trouble-free and customer-friendly service. A special customer service unit has been set up specifically to cater to our esteemed customers' needs. Technical Support: For technical support contact your Salesperson support@acuraembedded.com...
