MAINTENANCE:
requires no maintenance.
Your MC-10
Product Limited Warranty
All Labelmate Products are warranted to the original end-user customer to be free from defects in
materials and workmanship. If it is determined by Labelmate that a product has failed under the terms of
this warranty, the product will be repaired or replaced at no charge to the customer. Labelmate reserves
all rights to determination of coverage and liability under this warranty. The warranty period for all new
Labelmate products is outlined below:
Warranty Period
5 years
3 years
1 year
The warranty period for all products starts on the date purchased by the original end-user customer.
Warranty coverage is not transferable with ownership and will terminate immediately upon rental, resale
or any other change in ownership. This warranty does not cover repair to any product which is damaged,
has been modified, is missing parts, or has been opened or repaired by any unauthorised person. Use of
any unauthorised accessory or attachment will void coverage. Purchase documentation should be
retained for coverage verification.
In the event your product requires service, please contact the distributor you bought the product from.
The customer assumes responsibility for all cost and risk incurred in transport for service.
Labelmate makes no other warranty of any kind expressed or implied, or to suitability or fitness for a
particular purpose. No other person, agent or reseller is authorised to give any warranties on behalf of
Labelmate. Any obligation to warranty other than that specifically addressed above is hereby disclaimed.
© LABELMATE – User_MC-11-CE – 01/18 – Original user manual.
Products Covered
Label Rewinders
Label Unwinders
Label Counters (mechanical parts
only)
Label Slitters (mechanical parts
only)
Label Dispensers
Printer Mechanisms
Power Supply Modules
Counter modules
Encoders
Any products not specified above.
MC-10
MINI-CAT Label Rewinder
•
Switched Bi-Directional Control.
•
Constant Adjustable Torque™ "CAT"
Technology.
Remove all parts from the shipping container and verify contents.
PACKAGE CONTENTS:
•
User Manual (this document)
•
MC Rewinder Unit
•
Shaft Assembly with Flange, Vanes and Bail
•
Power Supply Module
Retain the Shipping Container and Packaging for Storage and Transport
SPECIFICATIONS:
Weight of the machine:
5,6Kg
Max. Label Roll Weight:
3Kg.
Max. Label Roll Diam.:
220mm.
Start/Stop:
ON/OFF/ON Direction Switch
Power Supply:
Input: 220-240VAC – 50-60Hz.
Output: 15VDC.
● KEEP MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE ●
